Telex EVF-1121S-FG Specifications

  • Coverage (Nominal -6 dB)

    Omnidirectional in normal operating range

  • Environmental Specs

    IEC 60529 IP55

  • Input Connections

    Phoenix/Euroblock style screw terminals

  • Internal Passive Low-Pass Filter

    100Hz 12dB per octave

  • Frequency Response

    -3 dB: 70-98Hz
    -10 dB: 48-120Hz

  • Recommended High-Pass Frequency

    50Hz

  • Sensitivity 1 W/1 m

    99dB

  • Max. SPL/1m (calc)

    131dB

  • System Power Handling

    400, 800, 1600 Watts (Continuous/Program/Peak)

  • LF Transducer

    EVS12SB, 12" (30.48cm) Driver

  • Nominal Impedance (Passive)

    Passive: 4 Ohms
    Biamp: 8 Ohms

  • Minimum Impedance

    Passive: 3.4 Ohms
    Biamp: 5.5 Ohms

  • Enclosure Material

    13 Ply Weather Resistant Birch

  • Grill

    18-ga Stainless, Powdercoat, with hydrophobic cloth behind

  • Suspension

    (22) M10 Threaded Points

  • Dimensions ( W x D x H)

    406 x 413.3 x 768.6mm (15.98 x 16.27 x 30.25")

  • Weight

    26.2kg (57.76lbs)

About Telex EVF-1121S-FG

The Electro-Voice EVF-1121S-FG is a fully-weatherized, fiberglass-coated, high power, front-loaded white bass element that can be used in a variety of applications where high quality sound reinforcement is required in a lightweight package. The EVF-1121S-FG utilizes the EVS12SB 12" woofer used FEA optimization for motor, suspension and electrical design for very low distortion and maximum intelligibility at high SPL levels. The EVF-1121S-FG features make it ideal for many fixed install applications, including applications with full exposure to outdoor elements. The trapezoidal enclosure is constructed out of weather resistant birch and coated with fiberglass for maximum protection from extreme outdoor elements.

The unique acoustic and rigging design allows for vertical and horizontal clusters to be built using any combination of loudspeakers from the entire EVF & EVH Series, with an assortment of Full-Range, Low Frequency and Subwoofer loudspeakers, it gives you the tools to maximize flexibility of system design, no matter what the application and budget. The innovative input panel provides phoenix style connectors and gland nut cover plate (for weatherizing applications). An available 70.7/100 Volt transformer kit simply mounts to the input panel for use in distributed systems. All these features give you the flexibility to do a large range of venues with fewer items in inventory and quickly support your customer's requirements.

What's in the box:

  • Electro-Voice EVF-1121S 12 " Front-Loaded Bass Element Subwoofer
  • Electro-Voice 3 Year Warranty
