Electro-Voice TM60 60 Watt 25/70.7/100V Line Matching Transformer, 60/30/15/7.5 Watts Taps, 1 dB Insertion Loss

The Electro-Voice TM60 60 Watt 25/70.7/100V is a high quality, universal, line matching transformers designed specifically to allow efficient matching of Electro-Voice public address speakers in virtually any sound distribution application using 25, 70.7 or 100-volt lines. The TM Series transformers feature the latest in transformer design techniques. Each unit features a uniform frequency response, +/-1 dB from 60 to 10,000 Hz, with better than .1% THD at 1,000 Hz and a maximum THD of 5% at 60 Hz, so that the sound quality does not change when a transformer is used. Each unit is conservatively rated for its respective power handling capacity. Insertion loss is less than 1.5 dB for best use of amplifier power and driver efficiency.
