Electro-Voice Dynacord V600:4 4-Channel 600W Power Amplifier

SKU: EVV6004US MFR: V600:4-US
Earn VIP Reward Points

Key Features

  • Experience pristine audio with this Electro-Voice power amplifier's low THD, ensuring clear sound.
  • This 4-channel power amplifier delivers 600W per channel at 8 ohms, perfect for live sound reinforcement.
  • Enjoy superior signal-to-noise ratio in your PA system, thanks to this amplifier's advanced circuitry.
  • The Dynacord V600:4 amplifier features comprehensive protection circuits, safeguarding your valuable equipment.
  • Optimize sound with selectable HPF/LPF; tailor frequencies using this versatile power amplifier for clarity.
  • Use this power amplifier for multi-zone audio; its input impedance ensures compatibility with various sources.
See More Product Details
Special Order?Estimated to Ship: 08/15/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$139.99

3 Year

$184.99

5 Year

$339.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Electro-Voice V600:4-US Specifications

Electrical

Electrical

Jump to...
  • Output power

    4 Ohm / 8 Ohm / 70 V / 100 V

  • Maximum output power per channel

    4 Ohm: 500 W
    8 Ohm: 600 W
    70 V: 500 W
    100 V: 600 W ((power sharing) at minimum impedance)

  • Total rated output power

    600 W

  • Number of channels

    4x

  • Output voltage RMS rated power

    4 Ohm: 24.5 V
    8 Ohm: 34.6 V
    70 V: 70.7 V
    100 V

  • Maximum RMS output voltage

    4 Ohm: 40.0 V
    8 Ohm: 56.0 V
    70 V: 70.7 V
    100 V

  • Rated impedance per channel

    4 Ohm
    8 Ohm
    70 V: 33.3 Ohm
    100 V: 66.7 Ohm

  • Minimum impedance per channel

    4 Ohm: 2.6 Ohm
    8 Ohm: 4 Ohm
    70 V: 10 Ohm
    100 V: 16.7 Ohm

Amplifier

Jump to...
  • Nominal Gain

    4 Ohm: 24.0 dB
    8 Ohm: 27.0 dB
    70 V: 33.2 dB
    100 V: 36.2 dB (+6 dBu input sensitivity, LEVEL 0 dB)

  • Maximum Gain

    4 Ohm: 30.0 dB
    8 Ohm: 33.0 dB
    70 V: 39.2 dB
    100 V: 42.2 dB (0 dBu input sensitivity, LEVEL +6 dB)

  • THD+N

    < 0.1 % (1/8 rated output power,1 kHz)

  • Crosstalk

    4 Ohm: < -70 dB
    8 Ohm: < -75 dB
    70 V: < -90 dB
    100 V: < -95 dB (ref. 1 kHz, 12 dB below maximum)

  • Frequency response

    HP: 30/100/150 Hz to 20 kHz
    LP: 30 Hz to 150 Hz

    HP: 50/100/150 Hz to 20 kHz
    LP: 50 Hz to 150 Hz
    (ref. 1 kHz, analog in to speaker out, -3 dB)

  • Damping factor

    4 Ohm: > 80
    8 Ohm: > 160
    70 V: > 500
    100 V: > 1000 (30/50 Hz to 1 kHz, ref. to rated impedance)

  • Output stage topology

    Class D, fixed frequency

  • Signal to noise ratio

    4 Ohm: > 98 dB
    8 Ohm: > 100 dB
    70 V: > 101 dB
    100 V: > 103 dB (A-weighted, ref. to rated output power, LEVEL 0 dB)

  • Output noise

    4 Ohm: < -68 dBu
    8 Ohm: < -67 dBu
    70 V: < -62 dBu
    100 V: < -61 dBu (A-weighted, LEVEL 0 dB)

Connectivity

Jump to...
  • Analog audio input

    Type: 2x 6-pin Euroblock, 3.81 mm, male, parallel 1x RJ45 (AES72-1E)
    Maximum input level: +18 dBu (LEVEL 0 dB)
    Input impedance, active balanced: 20 k Ohm

  • Mains Input

    IEC C14

  • Loudspeaker output

    2x 4-pin Euroblock, 5.08 mm, female

  • Control port

    Type: 1 x 5-pin Euroblock, 3.81 mm, male
    Remote ON: Remote On / Standby contact (overrides power button on front panel)
    Ready/Fault: Galvanic isolated relay, max.30 VDC / 500 mA

Environmental

Jump to...
  • Climatic conditions

    Cooling concept: Convection cooling in tabletop application and rack application with spacing between units. Forced cooling (side to rear) in rack application without spacing between units and in extreme thermal conditions.

  • Ambient temperature limits

    (+23 to +113 Degree F) -5 to +45 Degree C

  • Altitude (Operating)

    -1614 to 16404' (-500 to 5000m)

Mechanical

Jump to...
  • IEC Protection class

    Class I (grounded)

General

Jump to...
  • Standby mode (APD active)

    < 1 W

  • Power supply topology

    Switching power supply with power factor correction

  • Protections

    Audio limiters, high temperature, DC, HF, short circuit, back-EMF, peak current limiters, inrush current limiters, mains over/under voltage protection

  • Front status LEDs

    Signal, limit, fault LEDs per channel; power LED

  • Signal processing

    Input routing, HPF 24 dB/Oct. selectable 100/150 Hz, LPF 24 dB/Oct. selectable 150 Hz, Flat, Peak limiter

  • Power requirements

    100 V to 240 V, 50 Hz to 60 Hz AC

  • Power consumption

    Consumption at 1/8 rated output power: 115 W
    Idle mode (ecoRAIL with no input signal): <12 W
    Standby mode (APD active): <1 W

Physical

Jump to...
  • Dimensions (H x W x D)

    1.74 x 8.6 x 10.6" (44.2 x 218 x 269.5mm)

  • Weight

    4.6 lbs (2.1 kg)

  • UPC Code

    800549371568

About Electro-Voice V600:4-US

Become the master of sound with the Dynacord V600:4, a 4-Channel 600W Power Amplifier designed for a variety of installation scenarios. Ideal for educational institutions, hospitality venues, retail spaces, and houses of worship, this versatile power amplifier is the preferred choice for consultants, installers, and specifiers seeking a robust and adaptable solution.

The V600:4 boasts a compact 1RU form factor, requiring minimal rack space, and is powered by a total of 600 Watts. This powerhouse amplifier is equipped with innovative Dynacord technologies and best-in-class features, offering an optimal blend of professional performance and resource-efficient power consumption.

One of the standout features of the V600:4 is the newly developed Dynacord powerTANK technology. Acting as a power reservoir, it provides direct access to the total power of 600 Watts, enabling the amplifier to deliver asymmetric power across all channels as required. This ensures no energy is wasted, providing exceptional flexibility when powering multiple audio zones with varying loads.

The V600:4 can serve multiple purposes, from driving compact loudspeakers in smaller zones like a kitchen area to powering larger loudspeakers in an auditorium. This feature requires no special configuration skills as the powerTANK engages automatically.

When paired with a DSP matrix like the Dynacord MXE5 Matrix Mix Engine, the V600:4 can also function as a distribution amplifier for smaller zones in larger distributed installations. This makes it an ideal solution for background music and clear voice announcement applications in bars, restaurants, retail outlets, educational institutions, houses of worship, museums, galleries, transport hubs, and conference centers.

The V600:4 also features Variable Load Drive (VLD) for efficient utilization of the powerTANK capacity, providing consistent power to any channel with any impedance. The dualCOOL thermal design ensures maximum performance and reliability under any conditions, while the ecoRAIL's power consumption is similar to a regular standby level, further reducing power consumption when there is no signal present for extended periods.

Equipped with a PFC power supply and protection features typically found in professional power amplifiers, the V600:4 resists complete shutdown situations, ensuring peak performance under all conditions. The single cable installation feature, compatible with AES72-1E (RJ45 connectors) wired devices, simplifies the installation process for all four channels.

In summary, the Dynacord V600:4 4-Channel 600W Power Amplifier is a versatile, efficient, and powerful solution for all your audio needs.

Electro-Voice V600:4-US Features

  • Versatile, lightweight four-channel power amplifier at an attractive price point, recommended for background music and announcements in small to mid-sized commercial installations
  • Unique Dynacord technologies for reduced cost of ownership, with low energy consumption and flexible power-load allocation
  • Easy handling and trouble-free amplifier operation - even under demanding power conditions - in a compact 1RU form factor
  • 4-Channel amplifier, with a total powerTANK capacity of 600 W
  • Variable Load Drive (VLD) providing the same power into 4 Ohm, 8 Ohm, 70 V or 100 V
  • EcoRAIL and APD deliver significant reduction in power consumption
  • DualCOOL convection cooling with additional intelligent fan in case of extreme thermal conditions
  • Comprehensive protection package for reliable operation

Warranty Information

This product has a limited warranty of 36 months.

Product Documents

User Manual

Key Features

  • Experience pristine audio with this Electro-Voice power amplifier's low THD, ensuring clear sound.
  • This 4-channel power amplifier delivers 600W per channel at 8 ohms, perfect for live sound reinforcement.
  • Enjoy superior signal-to-noise ratio in your PA system, thanks to this amplifier's advanced circuitry.
  • The Dynacord V600:4 amplifier features comprehensive protection circuits, safeguarding your valuable equipment.
  • Optimize sound with selectable HPF/LPF; tailor frequencies using this versatile power amplifier for clarity.
  • Use this power amplifier for multi-zone audio; its input impedance ensures compatibility with various sources.

What's in the box:

  • Electro-Voice Dynacord V600:4 4-Channel 600W Power Amplifier
  • Mains Cord
  • 2x Euroblock Input Connector 6-Pole
  • Euroblock Remote Connector 5-Pole
  • 2x Euroblock Output Connector 4-Pole
  • 4x Rubber Feet
  • 2x 19"-Rack Mounting Brackets (Pre-Mounted)
  • User Manual
  • Electro-Voice 3 Year Limited Warranty
