Electro-Voice Zx5-60PI 600W 15" 2-Way Full-Range Loudspeaker, 60x60deg., 8 Ohms Nominal Impedance, 98 dB Sensitivity, 58Hz-18kHz, 2x Neutrik Speakon, Single, Black

SKU: EVZX560PI MFR: F.01U.265.569
Earn VIP Reward Points

Key Features

  • Experience powerful sound with this 600W Electro-Voice PA speaker for live performances.
  • Achieve crystal-clear audio with a frequency response of 58 Hz - 18 kHz in any venue.
  • The rugged polypropylene enclosure ensures durability for reliable PA speaker use, indoors or out.
  • Enjoy flexible setup options with multiple suspension points for easy rigging of your PA system.
  • This 15" 2-way loudspeaker delivers exceptional sound quality and wide 60° x 60° coverage.
  • Connect with ease using Neutrik Speakon connectors, perfect for professional PA setups.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$219.99

3 Year

$349.99

5 Year

$689.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Electro-Voice Zx5-60PI Specifications

  • Frequency Response (-3 dB)

    58 Hz - 18 kHz

  • Frequency Response (-10 dB)

    39 Hz - 20 kHz

  • Recommended Hi-pass Frequency

    36 Hz

  • Axial Sensitivity

    98 dB (1W/1m)

  • Max. Calculated SPL

    132 dB

  • Horizontal Coverage

    60 deg.

  • Vertical Coverage

    60 deg.

  • Power Handling (Passive)

    600W Continuous, 2400W Peak

  • LF Power Handling (Biamp)

    500W Continuous, 2000W Peak

  • HF Power Handling (Biamp)

    40W Continuous, 160W Peak

  • LF Transducer

    DVX3150, 15" (381mm) Driver

  • HF Transducer

    ND2, 1" (25.4mm) exit Neodymium Compression Driver

  • Crossover Frequency

    1.5 kHz

  • Nominal Impedance

    8 Ohms

  • Minimum Impedance

    6.5 Ohms

  • Connectors

    (2) Neutrik Speakon NL4's

  • Enclosure Material

    Polypropylene Structural Foam

  • Suspension

    Enclosure has locations for 5 Single-Stud Attachment Plates and 10 Forged Steel Eyebolts - 2 on Top, 2 on Bottom, 2 on Side, and 4 on Rear of Enclosure

  • Grille

    Polyester Powder Coated, 16GA Galvanized Steel, with Rotatable Logo

  • Environmental

    IP44

  • Dimensions (H x W x D)

    692 x 446 x 411mm (27.24 x 17.55 x 16.18")

  • Weight

    22.2 kg (49.0 lbs)

About Electro-Voice Zx5-60PI

It's clear that the Electro-Voice ZX5-60PI 600W 15" 2-Way Full-Range Loudspeaker represents the pinnacle of audio engineering, offering unparalleled sound quality and versatility in a compact, user-friendly design. At the core of this acoustic marvel lies the DVX3150 high-performance low-frequency transducer, meticulously crafted using advanced computer-aided design to ensure efficient voice coil cooling through forced air directionality. This innovative approach allows for high power handling and efficiency, while finite element analysis has refined the suspension and magnetic structure for extended low-frequency response and minimal distortion.

The power and precision of the ZX5-60PI are further enhanced by the ND2 neodymium-based compression driver, featuring a 2" voice coil that achieves maximum output with minimal size and weight. Its meticulously engineered phasing plug and titanium diaphragm contribute to superior high-frequency performance, and an integrated heatsink ensures effective cooling during high-output scenarios.

Encased in a high-tech, injection-molded enclosure crafted from high-impact polypropylene structural foam, the ZX5-60PI is built to withstand the rigors of live performance environments. The enclosure's design not only maximizes durability but also enhances rigidity and bass response. This loudspeaker is ingeniously designed to double as a stage monitor, offering two distinct angles (45 degrees or 55 degrees) for optimal positioning without the need for additional accessories.

For installation versatility, the ZX5-60PI comes equipped with three anchor plates for single stud-fittings rigging, complemented by two additional anchor plate attachment points on the bottom. Permanent suspension or bracket attachment is facilitated by ten strategically placed M8 inserts - two on the top and bottom, two under the handle, and four on the back of the enclosure.

Whether it's for live performances, events, or professional installations, the Electro-Voice ZX5-60PI loudspeaker delivers a powerful 600W output, a broad frequency range of 58Hz-18kHz, and a 60x60 degree coverage angle, ensuring a high-quality audio experience for audiences and performers alike. With a sensitivity of 98 dB and an 8 Ohms nominal impedance, this loudspeaker is compatible with a wide array of amplifiers and sound systems, making it a top choice for audio professionals seeking a reliable, high-quality, and versatile audio solution.

Electro-Voice Zx5-60PI Features

  • DVX3150 15" LF Transducer with Forced Air Cooling
  • ND2 2" Voice Coil, 1" Exit Neodymium Compression Driver
  • 60deg. x 60deg. Coverage Pattern
  • 600W Continuous (2400W) Power Handling
  • High Sensitivity, 132 dB Maximum SPL
  • Adjustable Monitor Angle (45deg. or 55deg.)
  • 3 Anchor Plates for Single Stud Fittings and 10 Integral Suspension Points
  • Passive/Biamp Selectable

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience powerful sound with this 600W Electro-Voice PA speaker for live performances.
  • Achieve crystal-clear audio with a frequency response of 58 Hz - 18 kHz in any venue.
  • The rugged polypropylene enclosure ensures durability for reliable PA speaker use, indoors or out.
  • Enjoy flexible setup options with multiple suspension points for easy rigging of your PA system.
  • This 15" 2-way loudspeaker delivers exceptional sound quality and wide 60° x 60° coverage.
  • Connect with ease using Neutrik Speakon connectors, perfect for professional PA setups.

What's in the box:

  • Electro-Voice Zx5-60PI 600W 15 " 2-Way Full-Range Loudspeaker
  • 3x Anchor Plates
  • 10x M8 Metric Suspension Insert Points
  • Electro-Voice 5 Year Limited Warranty
