What makes the Electro-Voice ZXA1-90 8' 2-Way 120V Powered Full-Range Loudspeaker stand out?

The ZXA1-90 stands out due to its high-quality sound production, powerful 800W amplifier module, and versatile connectivity options. It's designed by Electro-Voice, a reputable brand known for its superior audio equipment.

What are the connection options for the ZXA1-90 Loudspeaker?

The ZXA1-90 Loudspeaker offers versatile connectivity with both 1/4' and XLR connections, making it suitable for a variety of applications.

Is the Electro-Voice ZXA1-90 Loudspeaker suitable for professional use?

Yes, the Electro-Voice ZXA1-90 Loudspeaker is a professional-grade audio equipment piece, designed to deliver superior sound quality. It's ideal for live sound production.

What is the power of the amplifier module in the ZXA1-90 Loudspeaker?

The ZXA1-90 Loudspeaker is equipped with an 800W power amplifier module, derived from Electro-Voice's world-tour-class Tour Grade series.

What is the color of the ZXA1-90 Loudspeaker?

The ZXA1-90 Loudspeaker comes in a sleek white exterior, adding a touch of elegance to any setup.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Electro-Voice ZXA1-90 Specifications

  • Freq. Response (-3dB)

    60Hz-20kHz

  • Freq. Range (-10dB)

    48Hz-20kHz

  • Max. Measured SPL

    126dB

  • Coverage (Horiz. x Vert.)

    90 deg. x 50 deg.

  • Power Rating

    800W

  • LF Transducer

    (1) EV-8L, 204mm (8") Woofer

  • HF Transducer

    DH-2005, 25mm (1") Exit Compression Driver

  • Crossover Frequency

    1.8kHz

  • Connectors

    (1) XLR Mic Input with Gain Control, (1) XLR/TRS Combo Jack, (1) XLR Link Output

  • Enclosure Material

    ABS

  • Grille

    18GA Steel with Black Powdercoat

  • Mains Requirements

    95V-132V, 0.6A, 50-60Hz

  • Dimensions (HxWxD)

    457 x 282 x 264mm (17.99 x 11.10 x 10.39")

  • Weight

    8.6kg (18.96 lbs)

  • UPC Code

    800549682794

About Electro-Voice ZXA1-90

Make your live sound production stand out with the Electro-Voice ZXA1-90 8" 2-Way 120V Powered Full-Range Loudspeaker. This high-quality, durable and reliable loudspeaker is a self-powered version of the best-selling ZX1 compact two-way loudspeaker, a testament to Electro-Voice's commitment to superior audio technology.

The ZXA1-90 is equipped with an impressive 800W power amplifier module, a feature derived from Electro-Voice's esteemed Tour Grade series. This series is renowned for its world-class audio quality and reliability, making it a trusted choice for professionals worldwide.

This powerful loudspeaker is designed to deliver exceptional sound quality, making it an ideal choice for live sound production. It's not just about power, though. The ZXA1-90 also offers versatility with its 1/4" and XLR connection options, accommodating different applications with ease.

Encased in a sleek white exterior, this professional-grade loudspeaker not only performs well but also adds a touch of elegance to your setup. Experience the difference in audio quality with the Electro-Voice ZXA1-90 8" 2-Way 120V Powered Full-Range Loudspeaker.

Electro-Voice ZXA1-90 Features

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8" high-output LF transducer
  • DH2005 1" exit true compression driver
  • 90 deg. x 50 deg. coverage pattern
  • Rotatable horn design
  • 126 dB maximum SPL
  • Selectable high-pass filter for use with subwoofers
  • Line and microphone inputs
  • Integral monitor angle on enclosure
  • Built-in pole mount
  • Lightweight (less than 20 lbs) with integral handle for easy carrying

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • High-quality 8" 2-Way 120V Powered Full-Range Loudspeaker, perfect for live sound production
  • Versatile connectivity options with both 1/4" and XLR connections
  • Durable and reliable, designed by reputable audio equipment manufacturer, Electro-Voice
  • Professional-grade audio equipment, offering superior sound quality
  • Sleek white exterior, adding a touch of elegance to any setup
