EtherWAN EW75200-1308 IP67 Wireless Access Point with 5GHz/8dBi Omni Antenna
See all EtherWAN items
New Arrival

EtherWAN EW75200-1308 IP67 Outdoor Hardened Wireless Access Point with 5GHz/8dBi Omni Antenna

SKU: EWEW75200130 MFR: EW75200-1308
Be the first to review this itemAsk a Question
$1,683.33
OR
$141/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Experience reliable outdoor wireless access with the IP67 hardened design, ensuring durability.
  • Achieve fast 5GHz wireless speeds up to 867Mbps for seamless connectivity and productivity.
  • Benefit from enhanced network security features, including WPA2 encryption and robust firewall.
  • Enjoy versatile installation options with pole/wall mounting for optimal placement and coverage.
  • Ensure broad compatibility with IEEE 802.11a/n/ac standards for diverse network environments.
  • Simplify management with a user-friendly web interface, offering easy configuration and monitoring.
See More Product Details
New Item?
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

2 Year

$209.99

3 Year

$299.99

4 Year

$359.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

EtherWAN EW75200-1308 Specifications

Software

Software

Jump to...

  • Interface

    Web Browser
    SNMP v1/v2/v3

  • Management

    Firmware and configuration upgrade and backup via Web Browser
    Supports DHCP Server/Client/Relay
    DNS cache and Web Proxy
    System health monitoring including temperature and voltage
    Local system log, e-mail and remote log service
    SNTP Client
    Useful tools such as Bandwidth Test, E-mail, Ping, Traceroute, Packet Sniffer and Traffic Generator

  • Wireless

    Encryption: WPA, WPA2, WEP, AES
    Dynamic Frequency selection
    Proprietary Nstreme and Nv2 protocols for long distance transmission

  • Routing

    Static routing, RIP v1/v2 and OSPF v2
    Bidirectional Forwarding Detection
    Prefix List to filter and control the routing

  • Security

    RADIUS client

    Powerful Firewall
    Stateful packet inspection
    Layer-7 protocol detection
    Peer-to-peer protocols filtering

    Traffic classification by:
    Source MAC address
    IP addresses (network or list) and address types (broadcast, local, multicast, unicast)
    Port or port range
    IP protocols
    Protocol options (ICMP type and code fields, TCP flags, IP options and MSS)

  • Security (Contd.)

    Interface the packet arrived from or left through
    Internal flow and connection marks
    DSCP byte
    Packet content
    Rate at which packets arrive and sequence numbers
    Packet size
    Packet arrival time

Technology

Jump to...

  • Standards

    IEEE 802.3 10BASE-T
    IEEE 802.3u 100BASE-TX
    IEEE 802.3ab 1000BASE-T
    IEEE 802.11a/n/ac Wireless LAN

  • Performance

    Wireless transmission rate 5GHz:
    11a: 108Mbps
    11n: 300Mbps
    11ac: 867Mbps

    Ethernet data rate:
    Up to 540Mbps (LAN to wireless 11ac)

  • Wireless

    RF channels: Non-overlapping

    Frequency range:
    5GHz: 5150-5250MHz and 5725-5850MHz

    Channel width:
    5GHz: 10MHz, 20MHz, 40MHz, 80MHz
    Data security:
    256-bit AES-CCM

Power

Jump to...

  • Input

    PoE 802.3at/bt

  • Power Consumption

    17W Max.

Interface

Jump to...

  • Ethernet Port

    10/100/1000BASE-TX PoE

Environment

Jump to...

  • Operating Temperature

    -40 to 167 Degree F (-40 to 75 Degree C)

  • Storage Temperature

    -49 to 185 Degree F (-45 to 85 Degree C)

  • Ambient Relative Humidity

    5% to 95% (non-condensing)

Regulatory Approvals

Jump to...

  • ISO

    Manufactured in an ISO 9001 facility

  • EMI

    FCC Part 15B Class A
    FCC Part 15C

  • Environmental Test Compliance

    IEC 60068-2-6 Fc (Vibration Resistance)
    FED STD 101C Method 5007.1 (Free fall w/package)

Physical

Jump to...

  • Casing

    UV Protected Polystyrene case

  • Installation

    Pole/Wall Mounting

  • Dimensions (Antennas Attached)

    10.63 x 19.88 x 3" (270 x 505 x 76mm)

  • Weight

    4.2 lbs (1.9kg)

About EtherWAN EW75200-1308

The eWAV EW75200-1308 is a hardened IP67 outdoor wireless access point (WAP) providing high speed wireless connectivity for harsh and demanding environments. Comprised of high-power, long-range IEEE 802.11ac MIMO wireless radios with gigabit IEEE 802.3at PoE connectivity, the EW75200-1308 is hardened against extreme temperatures and water ingress.

eWAV delivers the power and range (up to 20 miles) to wirelessly connect remote networks or extend existing networks in an efficient and cost-effective way. The EW75200-1308 supports two 5GHz 802.11a/n/ac Radios for long-distance Point-to-Point/Point-to-Multi-Point data transmission and local device access such as laptops, wireless IP cameras, or mobile devices. Maximum transmission speeds are up to 867Mbps on each 5GHz radio.

High Bandwidth Wireless Connectivity
Designed for Point-to-Point and Point-to-Multipoint wireless backhaul applications IEEE 802.11a/n/ac providing high throughput data transmission on 5GHz up to 867Mbps

• 1x dual polarization, high gain panel antenna
• 2x high gain omnidirectional antennas

Hardened Grade with IP67 Protection
• Wide operating temperature range for extreme environments
• Fanless and ruggedized outdoor IP67 enclosure

Comprehensive and Advanced Software Features
• Static routing, RIP v1/v2 and OSPF v2
• Built in Stateful Firewall and RADIUS for security control
• RF strength LEDs and Bandwidth Tester to ease installation effort

EtherWAN EW75200-1308 Features

  • Omni & Directional Antennas
  • IEEE 802.11a/n/ac providing high throughput data transmission on 5GHz up to 867 Mbps
  • Hardened grade with IP67 protection
  • Static routing, RIPv1 & v2 and OSPFv2

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience reliable outdoor wireless access with the IP67 hardened design, ensuring durability.
  • Achieve fast 5GHz wireless speeds up to 867Mbps for seamless connectivity and productivity.
  • Benefit from enhanced network security features, including WPA2 encryption and robust firewall.
  • Enjoy versatile installation options with pole/wall mounting for optimal placement and coverage.
  • Ensure broad compatibility with IEEE 802.11a/n/ac standards for diverse network environments.
  • Simplify management with a user-friendly web interface, offering easy configuration and monitoring.

What's in the box:

  • EtherWAN EW75200-1308 IP67 Outdoor Hardened Wireless Access Point
  • EtherWAN 1 Year Limited Warranty
