Earthworks IMBL30 Omni Semisphere Boundary Layer Microphone with LumiComm Touch Ring for Conference Rooms & Fixed Sound Installations, 60Hz to 30kHz, Silver

SKU: EWIMBL30S MFR: IMBL30-S
Earn VIP Reward Points

Key Features

  • Experience pristine audio with this Earthworks boundary microphone, ideal for clear conference calls.
  • Capture every detail: This omnidirectional microphone offers a wide pickup for group discussions and presentations.
  • Enjoy low noise recording; the Earthworks microphone ensures clear sound even in less-than-ideal environments.
  • Rely on robust durability; this boundary microphone is built to last in demanding professional settings.
  • Achieve seamless connectivity with XLR output; integrate this microphone effortlessly with existing systems.
  • Get exceptional sound quality; its wide frequency response delivers natural, accurate audio for any application.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

5 Year

$269.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Earthworks IMBL30 Specifications

  • Compatibility

    Conference Rooms & Fixed Sound Installations

  • Frequency Response

    60Hz to 30kHz +/-2dB at 45 degree incidence to the surface

  • Integrated Low Cut Filter

    -15dB at 60Hz

  • Polar Pattern

    True Semisphere

  • Sensitivity

    70 mV/Pa at 1kHz

  • Power requirements

    48V Phantom, 10mA

  • Max Acoustic Input

    136dB SPL

  • Output

    XLR-3 (pin 2+)

  • Min. Output Load

    1K between pins 2 & 3

  • Noise

    19.5dB SPL (A weighted)

  • IMBL Light Ring LED Colors

    Dual Red or Green

  • IMBL Light Ring Connector

    Phoenix or RJ45

  • IMBL Light Ring Voltage

    8-28VDC at 85-170mA

  • IMBL Light Ring Activation

    Momentary Digital Pulse

  • Dimensions (Diax L)

    1.4 x 7" / 3.56 x 17.78cm

  • Weight

    0.28lbs / 0.13kg

  • UPC Code

    00827517254289

About Earthworks IMBL30

A high-quality and professional solution for your audio needs, the Earthworks IMBL30 Omni Semisphere Boundary Layer Microphone is a versatile and innovative addition to any conference room or fixed sound installation. This durable microphone, available in a sleek silver color, is designed by Earthworks, a reputable brand renowned for its superior audio equipment.

The IMBL30 microphone boasts an omnidirectional polar pattern, capable of capturing sound from all directions, making it an ideal choice for environments where sound needs to be picked up from various angles. Its impressive frequency range of 60Hz to 30kHz ensures a broad spectrum of sound is captured, enhancing the clarity and quality of audio recordings.

A standout feature of this microphone is the LumiComm Touch Ring. This touch-sensitive LED ring, with dual-color LEDs in red and green, offers a user-friendly interface for controlling the microphone. It can be programmed to perform various functions, such as turning the microphone on or off, simply by touching the light ring.

The IMBL30 microphone also features a fast diaphragm settling time, allowing for the subtle details of the human voice to be reproduced with amazing clarity and intelligibility. This, coupled with the extended high-frequency response and True Semisphere polar response, ensures that those speaking maintain the same intelligibility at the front and sides of the microphone without a loss of high frequencies.

The microphone's near-perfect polar response, a result of innovative technology by Earthworks founder David Blackmer, ensures uniform frequency response at various off-axis angles. This results in fewer phase problems and higher intelligibility at the sides of the microphone.

Designed for fixed installations, the IMBL30 microphone can be easily installed in conference tables and comes with a lock nut for secure placement. It also features RF shielding against cell phones and other RF devices, ensuring uninterrupted, high-quality sound capture.

Please note, this microphone requires 48V phantom power for operation. Choose the Earthworks IMBL30 Omni Semisphere Boundary Layer Microphone for exceptional sound quality and high intelligibility in your conference rooms and fixed sound installations.

Earthworks IMBL30 Features

  • High-quality omnidirectional microphone for conference rooms and fixed sound installations
  • Extended frequency range of 60Hz to 30kHz for superior sound capture
  • Innovative LumiComm Touch Ring with dual-color LEDs for easy control
  • Fast diaphragm settling time for enhanced voice clarity and intelligibility
  • Near-perfect polar response for uniform frequency response at various angles
  • RF shielding for protection against cell phones and other RF devices

Warranty Information

This product has a limited warranty of 180 months.

Product Documents

User Manual

Key Features

  • Experience pristine audio with this Earthworks boundary microphone, ideal for clear conference calls.
  • Capture every detail: This omnidirectional microphone offers a wide pickup for group discussions and presentations.
  • Enjoy low noise recording; the Earthworks microphone ensures clear sound even in less-than-ideal environments.
  • Rely on robust durability; this boundary microphone is built to last in demanding professional settings.
  • Achieve seamless connectivity with XLR output; integrate this microphone effortlessly with existing systems.
  • Get exceptional sound quality; its wide frequency response delivers natural, accurate audio for any application.

What's in the box:

  • Earthworks IMBL30 Omni Semisphere Boundary Layer Microphone
  • Lock Nut
  • Phoenix Connector
  • Earthworks 15 Year Limited Warranty
