EtherWAN EPOW-54-240 240W 54V Hardened NEMA TS2 Power Supply

SKU: EWPOW5424 MFR: EPOW-54-240
Earn VIP Reward Points

Key Features

  • Ensure reliable power for your network switches with this 240W hardened power supply.
  • This EtherWAN power supply supports a wide 100-277VAC input for versatile network setups.
  • With an IP67 rating, this power supply offers superior protection against dust and water.
  • Operate confidently in extreme conditions with a temperature range of -40 to 75 degrees C.
  • Enjoy easy installation with options for wall or panel mounting for your network equipment.
  • Benefit from robust network protection with short circuit and over-voltage safeguards built-in.
See More Product Details
Special Order?Estimated to Ship: 08/18/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$44.99

2 Year

$79.99

3 Year

$109.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

EtherWAN EPOW-54-240 Specifications

Output
  • Voltage

    54 VDC

  • Precision

    +/- 0.5V

  • Current

    4.4A

  • Power

    240W max. @ up to 167 Degree F (75 Degree C)

  • Line Regulation

    1%

  • Voltage

    100-277VAC

  • Current

    2.56A @ 110VAC, 1.28A @ 220VAC

  • Frequency

    50/60Hz

  • Inrush Current

    9A@230V

  • Power Factor (Typ)

    >0.95 at full load

  • Full Load Efficiency

    >88%

Protection

Jump to...
  • Short Circuit

    SCP / Over-Voltage Protection

  • Over-Voltage

    <305VAC

Environmental

Jump to...
  • Operating Temp.

    -40 to 167 Degree F (-40 to 75 Degree C)

  • Storage Temp.

    -40 to 185 Degree F (-40 to 85 Degree C)

  • Relative Humidity

    10% to 95% (non-condensing)

  • Operation Humidity

    20-90%

  • Vibration Resistance

    10-500Hz, 2G 10Min/cycle, 1hr each XYZ axis

Regulatory

Jump to...
  • Standard

    EN 61347-1
    EN 61347-2-13
    EN 62493

  • EMC Emission

    EN 55015
    EN 61000-3-2

  • EMC Immunity

    EN 55015
    EN 61000-4-2,3,4,5,6,8,11

Physical

Jump to...
  • Casing Material

    Aluminum

  • IP Rating

    IP67 (Dust Tight and Water-resistant)

  • Installation Type

    Wall/Panel mounting

  • Dimensions (W x D x H)

    9.69 x 2.68 x 1.54" (246 x 68 x 39mm)

  • Weight

    2.86 lbs (1.3kg)

  • UPC Code

    850047425249

About EtherWAN EPOW-54-240

With a wide operating temperature range of -40 to 75 Degree C (-40 to 167 Degree F) and built with an aluminum fanless design, EtherWAN's EPOW-54-240 is a 54V 240W hardened power supply designed to operate in the most extreme environments. The EPOW-54-240 has a 240W power budget and built-in over-voltage and short-current protection, making it a perfect and reliable solution for PoE applications.

Reliable Power Delivery
• Active built-in PFC for max power distribution efficiency
• Constant voltage across output terminal

Hardened-Grade for Non-Ventilated & Harsh Environments
• Wide operating temperature range -40 to 75 Degree C (-40 to 167 Degree F)
• Fanless operation
• IP67 total dust protection and water resistance

NEMA TS2
• Complies with NEMA TS1 & TS2 electrical and temperature requirements for traffic control equipment
• High impact, thermal shock, and electrical noise resistance

Easy Install
• AC and DC cables pre-attached
• Mounting holes to install outdoors and or in cabinets

EtherWAN EPOW-54-240 Features

  • Active built-in PFC for max power distribution efficiency
  • NEMA TS1 & TS2 compliant for electrical and temperature requirements
  • Easy installation with pre-attached cables and mounting holes

Key Features

  • Ensure reliable power for your network switches with this 240W hardened power supply.
  • This EtherWAN power supply supports a wide 100-277VAC input for versatile network setups.
  • With an IP67 rating, this power supply offers superior protection against dust and water.
  • Operate confidently in extreme conditions with a temperature range of -40 to 75 degrees C.
  • Enjoy easy installation with options for wall or panel mounting for your network equipment.
  • Benefit from robust network protection with short circuit and over-voltage safeguards built-in.

What's in the box:

  • EtherWAN EPOW-54-240 240W 54V Hardened NEMA TS2 Power Supply
  • EtherWAN 3 Year Limited Warranty
