For.A 32x16 Routing Switcher, Supports 3G/HD/SD/ASI, 2RU

For.A 32x16 Routing Switcher, Supports 3G/HD/SD/ASI, 2RU

SKU: FAMFR3216RPS
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

For.A Routing Switcher Specifications

  • Video Formats

    3G: 1080/60p, 1080/59.94p, 1080/50p
    HD: 1080/60i, 1080/59.94i, 1080/50i, 1080/30p, 1080/30PsF, 1080/29.97p, 1080/29.97PsF, 1080/23.98p, 1080/23.98PsF, 1080/25p, 1080/25PsF, 1080/24PsF, 1080/24p, 720/60p, 720/59.94p, 720/50p
    SD: 525/60, 625/50

  • Input x Output

    32 x 16

  • Video Inputs

    Compliant with the followings (75 Ohms BNC)
    SMPTE 424M (2.97 Gbps, 2.97/1.001 Gbps)
    SMPTE 292M (1.485 Gbps, 1.485/1.001 Gbps)
    SMPTE 259M (270 Mbps)
    DVB-ASI

  • Cable Equalization

    3G-SDI: 70 m (when a 5C-FB (Belden 1694A) equivalent cable is used)
    HD-SDI: 100 m (when a 5C-FB (Belden 1694A) equivalent cable is used)
    SD-SDI: 200 m (when a 5C-2V (Belden 8281) equivalent cable is used)

  • Video Outputs

    Compliant with the followings (75 Ohms BNC) (with automatic reclocking)
    SMPTE 424M (2.97 Gbps, 2.97/1.001 Gbps)
    SMPTE 292M (1.485 Gbps, 1.485/1.001 Gbps)
    SMPTE 259M (270 Mbps)
    DVB-ASI

  • Reference Inputs

    BB: NTSC: 0.429 Vp-p/PAL: 0.45 Vp-p or Tri-level Sync: +/-0.3 Vp-p, 75 Ohms BNC x 1, loop-through (Terminate with 75 Ohms terminator, it unused)

  • Interfaces

    MFR-LAN: 10/100BASE-T, RJ-45 x 2 (for RU/GPI connection, up to 128 units) (LAN 2: For MFR-SRCPU connection)
    PC-LAN: 10/100BASE-TX, RJ-45 x 1 (for computer or other external device connection)
    SERIAL: RS-232C/RS-422 (selectable by internal switches) 9-pin D-sub (male) x1
    ALARM: 9-pin D-sub (female) x1
    TO RS: Unused

  • Power

    100 V AC to 240 V AC +/-10%, 50/60 Hz

  • Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Humidity

    30 % to 90 % (no condensation)

  • Power Consumption

    100 VAC to 120 VAC: 48 VA (45 W)
    200 VAC to 240 VAC: 57 VA (45 W)

  • Dimensions (W x H x D)

    430 x 88 x 300mm / 16.93 x 3.46 x 11.81" (EIA 2RU)

  • Weight

    6kg / 13.23lbs

About For.A Routing Switcher

Multi-format routing switcher that supports 3G-SDI, HD-SDI, SD-SDI, ASI and AES signals. This inherits various, proven MFR-5000 Series functions such as the interface function for multi-link synced operation and tally and automatic source name tracking connections with peripheral devices (video switchers and multi-viewers).

Multi-format support
3G-SDI, HD-SDI, SD-SDI and ASI input and output support provide automatic signal recognition, allowing you to perform your operation irregardless of the signal type. AES signal supporting model MFR-1616A is also provided.

Aside from ordinary crosspoint switching, supports various crosspoint control formats/functions
• Salvo function: Button assigning type, Main unit storage type
• Take operation: Mode-switching Take button, Always Take button
• Link function
• Level operation
• Chop function
• Incorrect operation deterrence - Inhibition: Crosspoint, Source, Destination; Lock: Lock Other, Lock All, Lock Local

System construction with FOR-A video switchers and multi-viewers
System proposals that include FOR-A video switchers and multi-viewers and third-party manufacturer products (protocols: TSL, HARRIS).

SNMP remote monitoring support
This supports SNMP remote monitoring, for integration into an SNMP monitoring system. You can monitor various function states such as crosspoint errors, presence of SDI signal input/output, as well as power source, fan and CPU states.

4K Capability (SDI, ASI supporting model)
Capable of 4K signal switching with four 3G-SDI inputs

Remote Control Units
For.A offers several types or remote control unit to suit your application. The number of units that can be connected is a maximum of 128, including the main unit. This lets you build a flexible control environment by the way you partition the matrix and make operation level settings.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Seamlessly switch between 32 video inputs and 16 outputs with this reliable video switcher.
  • Supports 3G/HD/SD/ASI formats for versatile video routing in broadcast environments.
  • Ensure signal integrity with cable equalization up to 70m for 3G-SDI video signals.
  • Remotely control your video matrix via LAN, perfect for complex video distribution setups.
  • Enjoy high-quality video output with automatic reclocking on all 16 BNC video outputs.
  • Integrate easily into existing racks; this 2RU video switcher includes rack mount brackets.

What's in the box:

  • For.A 32x16 Routing Switcher
  • Operation Manual
  • AC Cord
  • Rack Mount Brackets
  • For.A Warranty
