Focusrite RedNet X2P 2x2 Dante Audio Interface with Red Evolution Mic Pre-Amps

SKU: FRREDNETX2P MFR: REDNET-X2P
Earn VIP Reward Points

Key Features

  • Capture pristine audio with Focusrite's RedNet X2P, featuring premium Red Evolution mic preamps.
  • Experience low latency audio interface performance for seamless recording and monitoring sessions.
  • Utilize Dante network connectivity for flexible audio routing in complex studio environments.
  • Enjoy high-quality headphone outputs, perfect for critical listening and accurate mix monitoring.
  • Easily integrate into your existing setup with versatile XLR and 1/4" inputs/outputs.
  • Take advantage of robust driver support for reliable performance with your favorite DAWs.
See More Product Details
Special Order?Estimated to Ship: 09/08/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$139.99

3 Year

$184.99

5 Year

$339.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Focusrite RedNet X2P Specifications

Microphone/Line Inputs

Microphone/Line Inputs

Jump to...
  • Gain Range

    0dB to 68dB in 1dB steps

  • Type

    Electronically Balanced, Zin = 6.2k Ohms

  • Max. Input Level

    +24dBu, min gain

  • Frequency Response

    20Hz - 35kHz +/-0.1dB

  • THD + N

    -103dB (0.0007%) at -1dBFS ( at 24dB Gain)

  • EIN

    <-130dBu 'A'-Weighted (typical)

  • Signal-To-Noise Ratio

    -120dB 'A'-Weighted (typical), min gain

  • Common-Mode Rejection Ratio

    50/60Hz CMRR: -80dB

  • Phantom Power

    +48V, independently switchable per channel.

  • HPF

    High-Pass Filter (HPF): -3dB at 80 +/- 3Hz, 12dB/Octave, independently switchable per channel

  • Air Mode

    2dB boost at 10kHz and -2dB at 20Hz (ref 1kHz). Input impedance drop to 2.2k Ohms

Instrument Inputs

Jump to...
  • Instrument Inputs Gain Range

    0dB to 68dB in 1dB steps

  • Instrument Inputs Type

    Electronically Balanced, Zin = 2M Ohms

  • Instrument Inputs Max. Input Level

    +15dBu, min gain

  • Instrument Inputs Frequency Response

    20Hz - 35kHz +/-0.1dB

  • Instrument Inputs THD + N

    <-100dB (0.001%) at -1dBFS ( at 16dB Gain)

  • Instrument Inputs Signal-To-Noise Ratio

    -118dB 'A'-Weighted (typical), min gain

  • Instrument Inputs HPF

    High-Pass Filter (HPF): -3dB at 80 +/- 3Hz, 12dB/Octave, independently switchable per channel

Line Level Outputs

Jump to...
  • Line Level O/P 0 DBFS Reference Levels

    +18 or +24dBu (switchable)

  • Line Level Outputs Frequency Response

    20Hz - 35kHz +/-0.1dB

  • Line Level Outputs THD + N

    <-104dB (0.0006%) at -1dBFS

  • Line Level Outputs Dynamic Range

    -120dB 'A'-Weighted (typical), 20Hz - 20kHz

Headphone Output

Jump to...
  • Headphone Output 0 DBFS Reference Levels

    +19dBm

  • Headphone Output Frequency Response

    20Hz - 20kHz +/-0.2dB

  • Headphone Output THD + N

    <-103dB (0.0007%) at -1dBFS

  • Headphone Output Dynamic Range

    117dB 'A'-weighted (typical), 20Hz - 20kHz

  • Headphone Output Impedance

    5 Ohms

  • Headphone Impedance

    32-600 Ohms

Microphone/ Line Crosstalk

Jump to...
  • Mic/Line Input To Input

    < -72dB; 20Hz - 20kHz (driven channel at -20dBFS)

  • Mic/Line Input To Output

    < -126dB; 20Hz - 20kHz (driven channel at -20dBFS)

  • Output To Mic/Line Input

    < -159dB; 20Hz - 20kHz (driven channel at -20dBFS)

Output Crosstalk

Jump to...
  • Output To Output

    < -101dB; 20Hz - 20kHz (driven channel at -20dBFS)

Headphone Crosstalk

Jump to...
  • Right To Left

    < -85dB; 20Hz - 20kHz (driven channel at -20dBFS)

Digital Performance

Jump to...
  • Supported Sample Rates

    44.1 / 48 / 88.2 / 96 kHz (-4% / -0.1% / +0.1% / +4.167%) at 24 bit

  • Clock Sources

    Internal or from Dante Network Master

Front Panel Connectivity

Jump to...
  • Outputs Headphone Outputs

    1x 1/4" stereo jack

Rear Panel Connectivity

Jump to...
  • Inputs Mic/Line/Inst Inputs

    2x Locking Combi XLR

  • Outputs Line Outputs

    2x Male XLR

PSU and Network Connections

Jump to...
  • PSU (PoE And DC)

    1x PoE (Port 1) Input and 1x DC 12V Locking Barrel Input Connector

  • Network

    2x etherCON connectors, also compatible with standard RJ45 connectors

Top Panel Indicators

Jump to...
  • LCD Screen

    1x Screen (Status & Metering)

  • Power Over Ethernet (PoE)

    Complies with IEEE 802.3af class 0 Power-over-Ethernet standard (PoE A or PoE B compatible)

  • DC Power Supply

    1x 12V 1.2A DC Power Supply.

  • Power Consumption

    PoE: 11.0W - DC: 13.32W (When using supplied DC PSU)

Heat Performance

Jump to...
  • Operating Temperature

    Operates at up to an ambient temperature of 45 deg. C (113 deg. F)

General

Jump to...
  • Dimensions (HxWxD)

    1.87 x 5.51 x 4.09" (4.75 x 14.00 x 10.39cm)

  • Weight

    1.04kg (2.29 lbs)

  • UPC Code

    815301006336

About Focusrite RedNet X2P

2x2 Analogue I/O With 2x Mic Pres, Headphone And Line Output, PoE Supplied
RedNet X2P is a compact, portable and robust 2x2 Dante audio interface featuring two Red Evolution mic pres, stereo line out and a stereo headphone amplifier. RedNet X2P allows you to effortless add a high quality Dante audio interface by integrating power, audio, clock and remote control over a single Ethernet cable - simply use a power over Ethernet switch or PoE injector. A local input mixer allows 'more me' monitoring control, while a control lockout mode ensures settings can not be changed when used remotely.

Rear panel XLR outputs offer level-controlled analogue outputs of up to 24dBu, while a front panel 1/4" connector provides a high-powered headphone output capable of driving both high and low impedance headphones. A pair of combination XLR/1/4" inputs allow the connection of mic, line or instrument level signals to the mic pres, which include Focusrite's acclaimed Air mode which emulates the sound of our classic input transformers.

The top panel features an array of controls: output level for headphone and line outputs, mic pre controls of gain, high-pass filter, Air, phase invert, phantom power and stereo linking; as well as the crossfader for controlling the balance of mic pre inputs and network receiver channels which to be sent to the headphone or line outputs.

Focusrite RedNet X2P Features

  • Stereo 2x2 audio interface for Dante Audio-over-IP networks
  • Two Red Evolution mic preamps for mic, line or instrument level inputs
  • Power-over-Ethernet supplied: IEEE 802.3af compliant
  • Up to 24-bit, 96kHz sampling rates
  • Robust steel and aluminum chassis
  • Local input mix to allow 'more-me' style monitoring for easy foldback control
  • Powerful headphone output even with high-impedance headphones
  • Local control lockout of mic pre settings, output settings or both
  • Up to 24dBu line output levels
  • Independent level control of headphone and line outputs
  • Mute switch for line output
  • Mic stand mount
  • Kensington security slot
  • Integrated network switch allowing daisy-chaining of network devices

Key Features

  • Capture pristine audio with Focusrite's RedNet X2P, featuring premium Red Evolution mic preamps.
  • Experience low latency audio interface performance for seamless recording and monitoring sessions.
  • Utilize Dante network connectivity for flexible audio routing in complex studio environments.
  • Enjoy high-quality headphone outputs, perfect for critical listening and accurate mix monitoring.
  • Easily integrate into your existing setup with versatile XLR and 1/4" inputs/outputs.
  • Take advantage of robust driver support for reliable performance with your favorite DAWs.

What's in the box:

  • Focusrite RedNet X2P 2x2 Dante Audio Interface with Red Evolution Mic Pre-Amps
  • Locking DC Power Supply
  • Ethernet Cable
  • RedNet Control Software
  • RedNet PCIe Drivers (Included with RedNet Control Download)
  • Audinate Dante Controller (Installed with RedNet Control)
  • Focusrite 2 Year Warranty
