Fujinon Fujifilm Fujinon 2/3" 35mm F2.0 C-Mount T360 Fixed Focal Length Lens
See all Fujinon items

Fujinon 2/3" 35mm F2.0 C-Mount T360 Fixed Focal Length Lens, 19.65 mm

SKU: FUJ35SR4ASA1

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Fujinon 35mm F/2.0 Specifications

  • Mount

    C

  • Focal length

    35 mm

  • Focus

    Manual

  • Iris Range

    F2.0 - T360

  • Iris

    Auto (DC Type)

  • Back Focal Distance (In Air)

    19.65 mm

  • Exit Pupil Position (From Image Plane)

    -68 mm

  • Object Dimensions at M.O.D.

    2/3": 191x143 mm
    1/2": 139 mmx104 mm
    1/3": 104x78 mm (4:3)2/3": 208x117 mm
    1/2": 151x85 mm
    1/3": 114x64 mm (16:9)

  • Angular Field of View

    2/3":14deg.20' x 10deg.46'
    1/2": 10deg.27' x 7deg.51'
    1/3": 7deg.51' x 5deg.53'(4:3)
    2/3": 15deg.36' x 8deg.48'
    1/2": 11deg.22' x 6deg.25'
    1/3": 8deg.33' x 4deg.49' (16:9)

  • Focusing Range (From Front of the Lens)

    Infinity - 0.75 m

  • Filter Thread

    M40.5 x 0.5 mm

  • Coil Resistance

    Drive Coil: 190 Ohm
    Damping Coil: 1,150 Ohm

  • Current Consumption

    23 mA (Max.) at DC 4V

  • Mass

    270 g / 9.52 oz

About Fujinon 35mm F/2.0

The Fujifilm Fujinon HF35SR4A-SA1L 5 megapixel day & night, 35mm (IR) fixed focal length lens is a high image-quality monitoring lens with optical performance supporting 5 megapixels. The advanced surveillance is possible in combination with 2/3" cameras seeking high performance. Chromatic aberration is reduced to the limit by utilizing advanced design engineering and special optic glass. It is best suited for high performance day and night cameras.
