Furman Sound Merit M-8S 15 Amp 1RU Power Sequencer, 9 Outlets, 10' Cord

SKU: FUM8S MFR: M-8S
Earn VIP Reward Points

Key Features

  • Safeguard your equipment with this 15 Amp Furman power sequencer, ensuring reliable power distribution.
  • Optimize your rack setup; this 1RU power sequencer features 9 outlets for efficient cable management.
  • Enjoy peace of mind with standard-level AC surge protection, defending against voltage spikes effectively.
  • Customize power sequencing with rear panel DIP switches, offering versatile control for any setup.
  • Easily monitor power status with front panel indicators for delay, power, and protection confirmation.
  • Utilize the remote terminal for seamless integration, enhancing control of your rack-mounted equipment.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$79.99

3 Year

$109.99

4 Year

$129.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Furman Sound M-8S Specifications

  • Maximum Output Current

    15 amps, 120 VAC (Thermal breaker)

  • Line Cord

    14AWGx3, 10', black, fixed, NEMA 5-15P plug

  • AC Receptacles

    Convenience Outlet (Front Panel) 1 Un-switched NEMA 15-5R
    Rear Panel Outlets: 2 Un-switched NEMA 5-15R (1 duplex),
    6 Sequenced NEMA 5-15R (3 duplexes, each controlled by separate relay)

  • Standard level AC Surge Protection

    Merit Class (sacrificial)

  • Spike Protection Mode

    Line to neutral, zero ground leakage

  • Max Continuous Operating Voltage

    130V RMS

  • Max Clamp Voltage

    500 Volts Peak

  • Peak Impulse Current

    12,000 Amps

  • Energy Rating (2x 820uS)

    225 Joules

  • AC Filtering

    Standard level Pi LCR Filter

  • Noise Attenuation

    >26dB, 100 KHz to 1 MHz

  • Operating Temperature Range

    5 to 40 deg. C / 41 to 104 deg. F

  • Humidity Range

    <90% rH (Relative Humidity)

  • Rocker Switch

    Front panel, Sequence (ON, OFF)

  • Thermal Circuit Breaker

    Front panel, push to reset

  • Front Panel Indicators

    Delay 1, Delay 2, Delay 3, Power, Protection OK

  • Rear Panel DIP Switches

    12V Mode On/Off, GND Mode On, Momentary/Maintained

  • Potentiometer

    Rear panel, time calibration fine tune delay adjust

  • Remote Terminal

    +5-30VDC In, 12VDC (12mA) Out
    Phoenix type 4-Pin Connector with Screw terminals; +12V, STAT, REM, GND (Class 2 Wiring)

  • Power Consumption

    5W

  • Safety Agency

    C/CSA/US

  • Dimensions (L x D x H)

    19 x 8.75 x 1.75" / 482.60 x 222.25 x 44.45mm
    ANSI 1RU

  • Weight

    7lbs / 3.18kg

  • UPC Code

    654061041078

About Furman Sound M-8S

Merit M-8S Power Sequencer is the perfect low-cost AC power solution for any rack mount system. Install an M-8S in your rack and the eight outlets in the rear panel will power up in sequence and protect all your equipment up to a 15-amp load.

• Standard level AC protection and filtering
• Six sequenced rear panel outlets (in 3 groups), two unswitched rear panel outlets and one front panel unswitched outlet
• Momentary and Maintained sequencing via rear panel terminal block or front panel switch (momentary only)
• All settings and configurations available on rear panel
• 15 amp rating
• Three year limited warranty

Power Sequencing
Prevents excessive inrush currents.

Noise Filtration
Noise filtering to reduce radio frequency and electromagnetic interference.

Surge Protection
Ensures equipment stays safe.

9 Total Outlets
Eight rear panel outlets and one front panel convenience panel outlet.

15 Amp Rating
15 amp rating, with circuit breaker.

"Protection OK" Indicator
Front panel indicator LEDs for Outlet Banks, Protection OK and Power Status.

Wall Wart Spacing
Rear outlets have been spaced to accommodate even the bulkiest of wall warts and adapters.

Furman Sound M-8S Features

  • Power Sequencing
  • Prevents excessive inrush currents
  • Noise filtering to reduce radio frequency and electromagnetic interference
  • Surge Protection
  • Ensures equipment stays safe
  • 9 Total Outlets
  • Eight rear panel outlets and one front panel convenience panel outlet
  • 15 amp rating with circuit breaker
  • Front panel indicator LEDs for Outlet Banks, Protection OK and Power Status
  • Wall Wart Spacing
  • Rear outlets have been spaced to accommodate even the bulkiest of wall warts and adapters
  • All settings and configurations available on rear panel

Key Features

  • Safeguard your equipment with this 15 Amp Furman power sequencer, ensuring reliable power distribution.
  • Optimize your rack setup; this 1RU power sequencer features 9 outlets for efficient cable management.
  • Enjoy peace of mind with standard-level AC surge protection, defending against voltage spikes effectively.
  • Customize power sequencing with rear panel DIP switches, offering versatile control for any setup.
  • Easily monitor power status with front panel indicators for delay, power, and protection confirmation.
  • Utilize the remote terminal for seamless integration, enhancing control of your rack-mounted equipment.

What's in the box:

  • Furman Sound Merit M-8S 15 Amp 1RU Power Sequencer
  • Furman Sound 3 Year Limited Warranty
