Gefen DVI and KVM Over IP Sender

SKU: GEDKVMLANTX MFR: EXT-DVIKVM-LANTX
Earn VIP Reward Points

Key Features

  • Extend your DVI KVM signals over IP with this Gefen sender for remote access.
  • Control your computer remotely using this KVM Over IP Sender, boosting productivity.
  • Enjoy seamless connectivity with the included DVI and USB cables for easy setup.
  • This DVI KVM over IP solution supports high-quality video and reliable performance.
  • Manage servers efficiently with this compact KVM sender, saving space in your setup.
  • Durable construction ensures long-lasting reliability for your KVM over IP needs.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$79.99

3 Year

$109.99

4 Year

$129.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Gefen DVI and KVM Over IP Sender Specifications

  • Maximum Pixel Clock

    165MHz

  • IR Extender Type

    EXT-RMT-EXTIRN

  • Power Consumption

    Sender: 10W (max.)

  • IR Emitter

    Sender: 3.5mm mini-mono jack

  • Line Input

    Sender: 3.5mm mini-stereo jack

  • Line Output

    Sender: 3.5mm mini-stereo jack

  • Dimensions (W x H x D)

    Sender: 8.4x 1.7 x 4.5" / 213.36 x 43.18 x 114.30mm

  • RS-232 Connector

    Sender: DB-9, Female

  • Video Input Connector

    Sender: DVI 29-pin, Female

  • Power Indicator

    Sender: LED, Blue

  • Link Indicator

    Sender: LED, Green

  • Ethernet connector

    Sender: RJ-45, Shielded

  • Mode button

    Sender: Tact-type

  • USB Host Interface

    Sender: USB Type B, Female

  • UPC Code

    845344078984

About Gefen DVI and KVM Over IP Sender

Explore the innovative capabilities of the DVI and KVM Over IP Sender, a high-quality and reliable solution for extending and distributing DVI, USB, RS-232, IR, and 2-way audio over a Local Area Network (LAN). This product supports a wide range of resolutions, up to 1080p Full HD and 1920 x 1200 (WUXGA), ensuring crystal clear video quality.

This DVI and KVM Over IP Sender is compatible with HDMI, DVI, and VGA Senders and Receivers, allowing for a versatile range of connections. It can be configured to unique IP addresses, either automatically or manually, facilitating the connection of multiple Senders and Receivers to the same network.

The product's innovative design allows for a virtual crosspoint matrix of over 65,000 Sender and Receiver units, depending on the network bandwidth and number of ports on your network switch. This feature makes it an ideal solution for large scale remote workstation access and digital signage applications.

Each Receiver unit is equipped with a built-in Ethernet switch and two additional RJ-45 Ethernet ports, enabling the connection of computers and other IP-enabled devices. The product supports USB 2.0 data rates up to 480 Mbps and is backward-compatible with USB 1.1.

The DVI and KVM Over IP Sender also offers bi-directional analog audio capability, allowing audio to be transported between the Sender and the Receiver units. The built-in mic pre-amp on the Receiver unit ensures compatibility with a variety of microphones.

The product's user-friendly design includes a built-in web server interface for easy set-up and configuration. It also supports IR commands from the Receiver side to sources connected to any of the Senders units and extends RS-232 serial control between each Sender and Receiver unit.

This DVI and KVM Over IP Sender is a durable and innovative solution for transmitting high-quality video and audio signals over an Ethernet network. It is designed for professional use in audio and video applications where it is necessary to transmit signals over long distances.

Gefen DVI and KVM Over IP Sender Features

  • High-quality DVI and KVM Over IP Sender for extending and distributing DVI, USB, RS-232, IR, and 2-way audio over a Local Area Network
  • Supports a wide range of resolutions up to 1080p Full HD and 1920 x 1200 (WUXGA) for crystal clear video quality
  • Compatible with HDMI, DVI, and VGA Senders and Receivers, offering versatile connection options
  • Features a virtual crosspoint matrix of over 65,000 Sender and Receiver units, ideal for large scale remote workstation access and digital signage applications
  • Equipped with a built-in Ethernet switch and two additional RJ-45 Ethernet ports for connecting IP-enabled devices
  • Offers bi-directional analog audio capability and a built-in mic pre-amp on the Receiver unit for compatibility with a variety of microphones

Key Features

  • Extend your DVI KVM signals over IP with this Gefen sender for remote access.
  • Control your computer remotely using this KVM Over IP Sender, boosting productivity.
  • Enjoy seamless connectivity with the included DVI and USB cables for easy setup.
  • This DVI KVM over IP solution supports high-quality video and reliable performance.
  • Manage servers efficiently with this compact KVM sender, saving space in your setup.
  • Durable construction ensures long-lasting reliability for your KVM over IP needs.

What's in the box:

  • Gefen EXT-DVIKVM-LANS DVI KVM Over IP Sender
  • CAB-DVIC-DLN-06MM 6' DVI Cable (M-M)
  • CAB-USB-6 6' USB Cable
  • CAB-DB9-6MF 6' DB-9 Cable
  • EXT-MP-C01 L-shaped Mounting Brackets with Screws
  • EXT-PS526AIP-LP 5V DC Power Supply
  • QSG-DVIKVM-LANTX Quick-Start Guide
  • Gefen 2 Year Limited Warranty
