Gefen 4K DisplayPort KVM Over IP Receiver

SKU: GEEXTPKLNSRX MFR: EXT-DPKA-LANS-RX
Earn VIP Reward Points

Key Features

  • Experience seamless 4K DisplayPort KVM over IP extension with this Gefen receiver.
  • Connect multiple USB devices using the versatile USB 2.0 and USB 1.1 ports.
  • Enjoy flexible power options with 5V DC or PoE (802.3af) for your KVM setup.
  • Remotely control your KVM system via RS-232, IR, and Ethernet ports for convenience.
  • Ensure reliable performance with a wide operating temperature range and high MTBF.
  • Easily integrate audio with dedicated headphone, mic, and optical digital audio outputs.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$124.99

3 Year

$159.99

4 Year

$189.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Gefen KVM Over IPReceiver Specifications

  • Video Output connector

    1x DP-20-pin, female

  • Mic Input

    1x 3.5mm mini-stereo jack

  • Headphones/Line Output

    1x 3.5mm mini-stereo jack

  • Optical Digital Audio Output

    1x TOSLINK

  • USB Device ports

    2x USB 2.0 Type A, female
    2x USB 1.1 Type A, female

  • RS-232 port

    1x DB-9, male

  • IR Sensor

    1x Located on front panel

  • IR In/Ext

    1x 3.5mm mini-stereo jack

  • IR Out

    1x 3.5mm mini-mono jack

  • IR Extender type

    EXT-RMT-EXTIRN

  • Ethernet ports

    2x RJ-45, shielded, one with PoE

  • Channel Up/USB-Request button

    1x tact-type

  • Channel Down button

    1x tact-type

  • Reset button

    1x tact-type, recessed

  • Program button

    1x tact-type, recessed

  • Program Select switch

    1x slide-type, recessed

  • Link Indicator

    1x LED, green

  • Power Indicator

    1x LED, blue

  • Power Supply jack

    5V DC, 2.5mm pin and 5.5mm barrel, locking

  • Power Requirement

    5V DC, or PoE (802.3af standard)

  • Power Consumption

    26W

  • Operating Temperature

    +32 to +122 Degree F (0 to +50 Degree C)

  • Operating Humidity

    5% to 90% RH, non-condensing

  • Storage Temperature

    -4 to +185 Degree F (-20 to +85 Degree C)

  • Storage Humidity

    0% to 95% RH, non-condensing

  • MTBF

    50000 hours

  • Dimensions (W x H x D)

    Without connectors or feet: 8.4 x 1 x 5.9" (214 x 25 x 150mm)

  • Weight

    2 lbs (900g)

  • UPC Code

    888814999815

About Gefen KVM Over IPReceiver

Before you settle for a conventional KVM solution, consider the transformative capabilities of the Gefen 4K DisplayPort KVM Over IP Receiver. This advanced device is engineered to extend and distribute DisplayPort, USB, RS-232, IR, and 2-way audio across a Local Area Network with unparalleled sophistication. Embracing Gefen's legacy of high-performance AV solutions, this state-of-the-art receiver offers a scalable and secure method of AV routing and distribution over a standard Gigabit LAN.

The second-generation KVM products from Gefen boast enhanced features and functionality, including support for 4K Ultra HD with HDR, ensuring your visuals are delivered with exceptional clarity and detail. The built-in scalers adeptly optimize images for a diverse range of displays and viewing environments, while the powerful video wall controller enables configurations up to 16x16, providing immense flexibility for live and signage content in even the most demanding installations.

With the Gefen 4K DisplayPort KVM Over IP Receiver, you gain the innovative advantage of independent USB, RS-232, IR, and audio routing. This allows for seamless control over sources and displays within your network, catering to the needs of graphic designers, video editors, photographers, and professionals requiring high-fidelity visuals and precise control.

The receiver's maximum input resolution stands at 4K 60 Hz 4:2:0, with an output resolution of 4K 30 Hz 4:4:4, supporting HDCP 2.2 and 1.4. The integrated USB hub features two USB 2.0 and two USB 1.1 ports, accommodating a variety of devices such as touch panels, keyboards, and mice, enhancing collaborative and interactive installations.

Audio outputs are compatible with both headphones and line-level devices, such as powered speakers, ensuring versatility in audio setups. The KM Emulation feature revolutionizes real-time keyboard and mouse control across all connected workstations, providing a seamless user experience.

Power-over-Ethernet (PoE) capabilities mean that both Sender and Receiver units can be powered through a PoE-enabled IP network switch, eliminating the need for external power supplies. When paired with the EXT-CU-LAN Matrix Controller, system configuration becomes automated and efficient, with the MFU feature ensuring all units remain up-to-date effortlessly.

Enhanced network security is achievable by separating control and AV networks, and multiple control options are available, including front panel buttons, web server interface, Telnet, UDP, and Gefen Keyboard Switching Controller software. The Gefen Enhanced API further adds functionality and compatibility with third-party controllers.

Designed for use with Gefen Syner-G software, initial IP configuration is simplified, and the built-in 2-port Gigabit switch on the Receiver allows for daisy-chaining of additional Receivers or IP-enabled devices. This feature is particularly beneficial in digital signage applications, enabling content replication across multiple displays without the need for direct runs to the main network switch.

The Sender and Receiver can function as KVM extenders in a one-to-one system or as nodes in a virtual matrix, supporting up to 39,900 Senders and over 65,000 units combined. This makes the system ideal for diverse applications such as AV systems in entertainment venues, corporate environments, command centers, educational institutions, and retail settings.

For installation flexibility, the Sender features a 1U tall, half-rack-width enclosure suitable for rack-mounting, surface-mounting, or shelf placement. The low-profile Receiver unit also offers similar mounting options and can be discreetly hidden with a Gefen IR Extender module. This Gefen 4K DisplayPort KVM Over IP Receiver is not just a product but a comprehensive solution for those who demand the best in remote computer access and control.

Gefen KVM Over IPReceiver Features

  • Extends DisplayPort, USB, RS-232, 2-way analog audio, and IR, using a Gigabit Local Area Network
  • Independent video, USB, RS-232, IR, and audio routing (future firmware update)
  • Backward-compatible with first generation Gefen AV over IP products
  • Supports input resolutions up to 4K 60Hz 4:2:0
  • Supports output resolutions up to 4K 30Hz 4:4:4
  • Supports HDCP 2.2 and 1.4
  • KM Emulation feature facilitates real-time, simultaneous Keyboard and Mouse control of each source from all connected workstations
  • Integrated scaler ensures maximum compatibility and best possible viewing experience with different contents and displays
  • Built-in video wall controller accommodates any number of rows and columns up to 16x16
  • Built-in Audio De-Embedder on Receiver breaks out 2 channel analog, 2 channel PCM, and up to 5.1 channels of Bitstream audio from the HDMI signal, allowing the audio content to be sent to external amplifiers and music distribution systems for added impact
  • MFU (Mass-Firmware-Update), quick and automated configuration, and enhanced control capabilities and system security when used with the Gefen EXT-CU-LAN Matrix Controller
  • Enhanced API for added functionality with third-party control systems
  • Built-in web interface, Telnet, and UDP
  • Compatible with the Gefen Keyboard Switching Controller software, available for download at www.gefen.com
  • Supports 39,900 Senders and a combination of over 65,000 Sender and Receiver units, depending on the network bandwidth and number of ports on your network switch
  • Two USB 2.0 ports with data rates up to 480 Mbps and backward-compatibility with USB 1.1
  • Two USB 1.1 ports with KM Emulation, for use with Human Interface Devices (H.I.D.)
  • 802.3af standard Power-over-Ethernet allows the new Sender and Receiver units to be powered through a standard PoEenabled IP network switch, without the need for external power supplies
  • Two-port Gigabit Ethernet switch built into the Receiver unit
  • Mode switch on Sender for sharpness or motion-optimization of image
  • Field-updatable firmware via EXT-CU-LAN controller or the built-in web server interface
  • Locking power supply connectors
  • Half-rack width Sender and Receiver enclosures are rackmountable using EXT-RACK-1U-GRY
  • Sender and Receiver can also be surface-mounted using the included L-brackets
  • Low profile Receiver enclosure features an IR Extender port and can be hidden away behind the display

Key Features

  • Experience seamless 4K DisplayPort KVM over IP extension with this Gefen receiver.
  • Connect multiple USB devices using the versatile USB 2.0 and USB 1.1 ports.
  • Enjoy flexible power options with 5V DC or PoE (802.3af) for your KVM setup.
  • Remotely control your KVM system via RS-232, IR, and Ethernet ports for convenience.
  • Ensure reliable performance with a wide operating temperature range and high MTBF.
  • Easily integrate audio with dedicated headphone, mic, and optical digital audio outputs.

What's in the box:

  • Gefen 4K DisplayPort KVM Over IP Receiver
  • 5V 4A Power Supply (EXT-PS54AULPN-6)
  • AC Power Cord (CAB-POWERCORD-xx)
  • 4x Self-Adhesive Rubber Feet
  • 2x L-Shaped Mounting Brackets
  • 4x Machine Screws for L-Shaped Mounting Brackets
  • 2x Machine Screws for EXT-RACK-1U-GRY
  • User Manual
  • Gefen 3 Year Limited Warranty
