Gefen 4K Ultra HD HDMI and VGA KVM Over IP Receiver Unit

SKU: GEUHDKALARX MFR: EXT-UHDV-KA-LANS-RX
Earn VIP Reward Points

Key Features

  • Experience seamless control with this Gefen KVM receiver, managing your systems efficiently.
  • Enjoy superior 4K Ultra HD resolution with HDMI/VGA KVM over IP for crystal-clear visuals.
  • Connect multiple USB devices with the KVM receiver's USB 2.0 and USB 1.1 ports for versatility.
  • Utilize PoE support for simplified installation, powering your KVM receiver through Ethernet.
  • Control devices remotely via IR, extending your reach with this Gefen KVM over IP receiver unit.
  • Ensure reliable performance with a robust design, backed by Gefen's 3-year limited warranty.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$124.99

3 Year

$159.99

4 Year

$189.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Gefen Receiver Specifications

  • Video Output connector

    1x HDMI Type A 19-pin, female, locking
    1x HDMI VGA HD-15, female

  • Line Input

    1x 3.5mm mini-stereo jack

  • Line Output

    1x 3.5mm mini-stereo jack

  • Optical Digital Audio Output

    1x TOSLINK

  • USB Device ports

    2x USB 2.0 Type A, female
    2x USB 1.1 Type A, female

  • RS-232 port

    DB-9, male

  • IR Sensor

    1x Located on front panel

  • IR In/Ext Port

    1x 3.5mm mini-stereo jack

  • IR Out port

    1x 3.5mm mini-mono jack

  • IR Extender type

    EXT-RMT-EXTIRN

  • Ethernet port

    3x RJ-45, shielded, 1 with PoE

  • Channel Up/USB-Request button

    1x tact-type

  • Channel Down button

    1x tact-type

  • HDMI/VGA Selector button

    1x tact-type

  • Reset button

    1x tact-type, recessed

  • Program button

    1x tact-type, recessed

  • Program Select switch

    1x slide-type, recessed

  • Link Indicator

    1x LED, green

  • Power Indicator

    1x LED, blue

  • Power Supply jack

    5V DC, 2.5mm pin and 5.5mm barrel, locking

  • Power Requirement

    5V DC or PoE

  • Power Consumption

    19W

  • Operating Temperature

    32 to 122 deg. F (0 to 50 deg. C)

  • Operating Humidity

    5% to 90% RH, non-condensing

  • Storage Temperature

    -4 to 185 deg. F (-20 to 85 deg. C)

  • Storage Humidity

    0% to 95% RH, non-condensing

  • MTBF

    50000 hours

  • Dimensions (WxHxD)

    8.4 x 1.0 x 4.3" (213.36 x 25.40 x 109.22mm) (without connectors or feet)

  • Weight

    1.5 lbs (0.68kg)

  • UPC Code

    888814999624

About Gefen Receiver

Bring high-definition video and audio to your workspace or entertainment setup with the advanced 4K Ultra HD HDMI and VGA KVM Over IP Receiver Unit. This innovative device is designed to extend and distribute 4K HDMI, VGA, USB, RS-232, IR, and 2-way audio over a Local Area Network (LAN), making it an ideal solution for high-performance, scalable, and secure AV routing and distribution.

The receiver unit features a compact 1U tall and half-rack-width enclosure, making it suitable for rack mounting, surface mounting, or shelf placement. With the included IR Extender module, this low-profile unit can be discreetly tucked away behind a display or in an equipment closet, maintaining a clean and professional look for your setup.

This reliable receiver unit is more than just a signal extender. It also serves as a video wall controller, accommodating any screen configuration up to 16x16. This feature allows for flexible sizing and manipulation of live and signage content, making it a perfect fit for demanding installations in corporate, education, hospitality, and retail establishments, as well as sports bars and restaurants.

When used with the EXT-CU-LAN Matrix Controller, system configuration is automated and quick, enhancing network security by separating the control and AV networks. Control options include front panel buttons, web server interface, Telnet, UDP, and the Gefen Keyboard Switching Controller software.

The receiver unit also features a built-in 3-port Gigabit switch, allowing for the connection of additional receivers and providing daisy-chaining functionality. This feature is particularly useful in digital signage applications, where content replication on multiple displays is required.

The receiver unit supports input resolutions up to 4K 60 Hz 4:2:0 and HDR, and output resolutions up to 4K 30 Hz 4:4:4, along with HDCP 2.2 and 1.4 and 7.1 channels of HBR (High Bit Rate) lossless and LPCM digital audio. It also supports DVI when using Gefen HDMI-to-DVI cables, and VESA resolutions up to 1920x1200 at 60Hz (WUXGA) with its VGA input and output.

With its HDMI and VGA selectable inputs, HDMI and VGA outputs, USB/KVM routing ability, 4K with HDR support, and an array of cutting-edge enhancements, this receiver unit is designed to meet the growing needs of systems integrators. It also features USB routing and a USB hub with two USB 2.0 and two USB 1.1 ports, making it perfect for collaborative and interactive installations.

The receiver unit also supports PoE (Power over Ethernet), allowing it to be powered through a standard PoE-enabled IP network switch, eliminating the need for external power supplies. This high-quality, durable receiver unit is a versatile and innovative solution for your audio and video transmission needs.

Gefen Receiver Features

  • Extends HDMI, VGA, USB, RS-232, bi-directional stereo analog audio, and IR over IP, using a Gigabit Local Area Network
  • Supports input resolutions up to 4K 60Hz 4:2:0 on HDMI and up to 1920x1200, 60 Hz on VGA (WUXGA)
  • Supports output resolutions up to 4K 30Hz 4:4:4 on HDMI and up to 1920x1200 60 Hz or 1080p Full HD on VGA
  • Supported HDMI Features: HDR, HDCP 2.2 and 1.4, Deep Color, Lip-Sync pass-through
  • Supports uncompressed LPCM digital audio up to 7.1 channels
  • Supports up to 7.1 channels of HBR (High Bit Rate) digital audio including Dolby Atmos, Dolby TrueHD, DTS:X, and DTS-HD Master Audio
  • When used with Gefen DVI-to-HDMI cables (not included), supports the use of DVI sources and DVI displays up to 1080p Full HD and 1920x1200 (WUXGA)
  • Built-in video wall controller accommodates any number of rows and columns up to 16x16
  • Quick mass-firmware-update, automated configuration, and enhanced control capabilities and system security when used with the Gefen EXT-CU-LAN Matrix Controller
  • Built-in web interface, Telnet, and UDP
  • Compatible with the Gefen Keyboard Switching Controller software
  • Supports 39,900 Senders and a combination of just over 65,000 Sender and Receiver units, depending on the network bandwidth and number of ports on your network switch
  • Two USB 2.0 ports with data rates up to 480 Mbps and backward-compatibility with USB 1.1
  • Two USB 1.1 ports for use with Human Interface Devices (H.I.D.)
  • PoE (Power over Ethernet) allows the new Sender and Receiver units to be powered through a standard PoE-enabled IP network switch, without the need for external power supplies
  • Three-port Gigabit Ethernet switch built into the Receiver unit
  • Mode switch on Sender for sharpness or motion optimization of image
  • Field-updatable firmware via EXT-CU-LAN controller or the built-in web server interface
  • Locking power supply connectors
  • Half-rack width Sender and Receiver enclosures are rack-mountable using EXT-RACK-1U-GRY
  • Sender and Receiver can also be surface-mounted using the included L-brackets
  • Low profile Receiver enclosure features an IR Extender port and can be hidden away behind the display

Key Features

  • Experience seamless control with this Gefen KVM receiver, managing your systems efficiently.
  • Enjoy superior 4K Ultra HD resolution with HDMI/VGA KVM over IP for crystal-clear visuals.
  • Connect multiple USB devices with the KVM receiver's USB 2.0 and USB 1.1 ports for versatility.
  • Utilize PoE support for simplified installation, powering your KVM receiver through Ethernet.
  • Control devices remotely via IR, extending your reach with this Gefen KVM over IP receiver unit.
  • Ensure reliable performance with a robust design, backed by Gefen's 3-year limited warranty.

What's in the box:

  • Gefen 4K Ultra HD HDMI and VGA KVM Over IP Receiver Unit
  • EXT-PS54AULPN-6 5V 4A Power Supply
  • AC Power Cord
  • 4x Self-Adhesive Rubber-Feet
  • 2x L-Shaped Mounting Brackets
  • 4x Machine Screws for L-Shaped Mounting Brackets
  • 2x Machine Screws for EXT-RACK-1U-GRY Rack Tray
  • IR Extender Module
  • Quick-Start Guide
  • Gefen 3 Year Limited Warranty
