Shopper : I have the eco maps ultra 122sv is the new live scope plus compatible?
Shopper : Is this in stock?
Shopper : Why Did You Choose This?BRAD L : The bestSCOTT S : Fishing

Reviews about this item

Review Summary

2022-06-13T08:33:58

Rated 5 out of 5

Buy with confidence!

Fantastic product! Fantastic company with quick shipping!

CHAD D.

Garmin LiveScope Plus System Specifications

Sonar Features

Sonar Features

Jump to...
  • Frequency

    530 - 1,100 kHz

  • Maxdepth

    Down and Forward: 200' (61m)

Connections

Jump to...
  • Connections

    Garmin Marine Network Ports: 1 (small connector)

Electrical Features

Jump to...
  • Power Input

    10-32 V

  • Power Usage

    21 W typical, 58 W max

  • Transmit Power

    500 W

  • Fuse

    7.5 A

  • Compass-Safe Distance

    4" (10.16cm)

General

Jump to...
  • Minimum Depth

    36' (91.44cm)

  • Sonar Type

    Live

  • Beamwidth

    20 Degree x 135 Degree

  • Transducer Cable Length

    20' (6m)

  • Transducer Number Of Pins

    21

Physical

Jump to...
  • Waterproof

    IPX7

  • Temperature Range

    GLS 10 Black Box: Operating: 5 to 158 Degree F (-15 C to 70 Degree C)
    Panoptix LiveScope LVS34 Transducer: Operating: 32 to 104 Degree F (0 to 40 Degree C)

  • Dimensions

    GLS 10 Sonar Black Box: 9.7 x 5.9 x 2.6" (24.5 x 14.9 x 6.5cm)
    LVS34 Transducer: 6.4 x 3.1 x 1.9" (16.2 x 7.8 x 4.8cm)

  • Weight

    GLS 10 Sonar Black Box: 4.3 lbs (2.0kg)
    LVS34 Transducer: 2.25 lbs (1.02kg)

  • UPC Code

    753759298456

About Garmin LiveScope Plus System

FEATURED REVIEWS

Buy with confidence!

By CHAD D.

Fantastic product! Fantastic company with quick shipping!

A cutting-edge advancement in marine technology, the LiveScope Plus System with GLS 10 Sonar Module and LVS34 Transducer is the epitome of high-resolution, real-time sonar imaging. This state-of-the-art system offers an unparalleled level of clarity and precision, enhancing your underwater exploration and navigation capabilities.

With its sophisticated sonar technology, the GLS 10 Sonar Module delivers crystal-clear images and superior target separation. This allows you to scan your surroundings with sharper images, reduced noise, and fewer sonar artifacts, providing a more accurate and detailed view of the underwater world.

The LiveScope Plus System is not just about improved resolution; it's about providing a comprehensive, real-time view of your marine environment. With supported Forward, Down, and Perspective modes, you can scout ahead of your boat, explore the activity directly beneath, or view the underwater scene from your perspective above the water.

The system also features a built-in stabilization system, ensuring that the sonar image on your compatible chartplotter remains steady, even in rough conditions. This innovative feature enhances your ability to accurately interpret and respond to the data provided by the system, improving your overall navigation and tracking capabilities.

To further enhance your viewing experience, the LiveScope Plus System offers seven vivid color palettes, including Aqua, Caribbean, and Lava. These options allow you to see fish and structure in maximum contrast and clarity, providing a more detailed and vibrant view of your underwater surroundings.

In addition, upgrading your current LiveScope System is as simple as adding a new transducer. This flexibility allows you to continually enhance and adapt your system to meet your evolving needs and preferences.

In summary, the LiveScope Plus System with GLS 10 Sonar Module and LVS34 Transducer is a sophisticated, high-tech marine electronics system that offers advanced features and capabilities, setting a new standard in sonar imaging technology.

Garmin LiveScope Plus System Features

  • Live sonar images with improved screen clarity, increased transducer sensitivity and better target separation
  • Sharper images with reduced noise and fewer sonar artifacts that impede a clear picture of fish and structure
  • New transducer can be used with existing LiveScope System black box (GLS 10) for easy upgrade
  • Vivid color palettes for enhanced detail and clarity
  • Supports Forward, Down and Perspective mode with all necessary mounts included in the box

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Experience real-time sonar with the Garmin LiveScope Plus System for unparalleled fish finding.
  • Utilize the GLS 10 sonar module to see detailed underwater structures and fish activity clearly.
  • The Panoptix LVS34 transducer provides live scanning, offering both forward and downward views.
  • Easily switch between views with the included perspective mount for versatile fishing scenarios.
  • Enjoy reliable performance with a wide frequency range (530-1,100 kHz) for detailed sonar imaging.
  • Durable and waterproof (IPX7), this Garmin system is built to withstand harsh marine environments.

What's in the box:

  • Garmin LiveScope GLS 10 Sonar Module
  • Panoptix LVS34 Transducer
  • Perspective Mount
  • Trolling Motor Barrel Mount
  • Shaft Mount
  • Power Cable
  • 2m Marine Network Cable (Small Connector)
  • Network Adapter Cable
  • Documentation
  • Garmin 1 Year Limited Warranty
