Heritage Audio 80 Series 1084 Microphone Preamplifier and EQ Module

SKU: HA1084 MFR: HA1084
Earn VIP Reward Points

Key Features

  • Experience pristine sound quality with this Heritage Audio microphone preamplifier.
  • Achieve versatile tone shaping with the integrated EQ module for studio recordings.
  • Enjoy a wide gain range, perfect for capturing vocals, guitars, and drums effortlessly.
  • Low noise circuitry ensures clean, professional recordings every single time.
  • Selectable input impedance lets you optimize performance with various microphones.
  • Built to last, this preamp offers exceptional build quality for years of reliable use.
See More Product Details
Special Order?Estimated to Ship: 08/11/2025
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$299.99

3 Year

$449.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Heritage Audio Mic Preamplifier Module Specifications

  • Input Impedance

    Microphone HI: 1200 ohms transformer balanced and floating
    Microphone LO: 300 ohms
    Higher gain positions gradually have greater impedances
    Line: 10 kOhms bridging, transformer balanced and floating

  • Output Impedance

    Less than 75 ohms, transformer balanced and floating to drive a load of 600 ohms

  • Maximum Output

    Greater than +26 dBm into 600 ohms, greater than +32 dBu into 10 kOhms

  • THD

    Less than 0.025% at 1 kHz, less than 0.05% at 100 Hz

  • Frequency Response

    20 (+0.3 dB) to 20,000 Hz (-0.2 dB)

  • Maximum Gain

    Slightly greater than 80 dB

  • High Frequency

    +/-16dB shelving at either 10, 12 or 16 kHz, Baxandall type

  • Low Frequency

    +/-16dB with selectable frequency shelving of 35Hz, 60Hz, 110Hz & 220Hz,Baxandall type

  • Noise

    Less than -100 dBm

  • Power Consumption

    106 mA at 24 VDC

  • Dimensions (W x H x D)

    1.77 x 12.2 x 8.74" / 44.96 x 309.88 x 222.00mm

  • UPC Code

    799430206259

About Heritage Audio Mic Preamplifier Module

Over the years, the Heritage Audio 80 Series 1084 Microphone Preamplifier and EQ Module has become an iconic staple in the professional recording and audio industry, often regarded as a more versatile and feature-rich successor to the legendary 1073 module. This high-quality, advanced unit is designed to deliver unparalleled audio fidelity, making it a top choice for audio professionals seeking a reliable and durable preamplifier and EQ solution.

The 80 Series 1084 boasts an impressive 80dB Class A microphone preamplifier with selectable minimum input impedance, both balanced and floating, to ensure pristine audio capture. The high gain positions offer increased impedance, perfect for pairing with vintage ribbon microphones, while the 10dB Class A line amplifier further enhances signal integrity.

At the heart of the 1084's versatility is its sophisticated EQ section. The mid-frequency band offers a choice of two distinct 'Q' values, allowing for either +/-18dB or +/-16dB peaking. Users can select center frequencies from 0.36kHz up to 7.2kHz, utilizing a dual inductor-based design for precise tonal shaping. The high pass filter, with its 18dB per octave slope, is switchable between 45Hz, 70Hz, 160Hz, and 360Hz, offering additional control over the lower frequency spectrum.

The module's low pass filter, also with an 18dB per octave slope, provides switchable options between 6kHz, 8kHz, 10kHz, 14kHz, and 18kHz, enabling users to refine the high-frequency response and eliminate unwanted hiss or noise. This feature is particularly beneficial for managing bass-heavy tracks where a flat high-frequency response is not desired.

Unique to the 1084 module are three selectable high shelf frequencies, providing more flexibility than the fixed 12kHz option found in the 1073. Additionally, the two selectable 'Q' settings in the mid-band, including the high 'Q' identical to the 1073, allow for nuanced sound sculpting. The five frequency selectable passive LC low pass filter, absent in the 1073, enables the creation of special effects such as telephone, radio, and TV sounds that are challenging to replicate authentically with plugins.

The EQ button on the 1084 module conveniently engages or bypasses the equalizer, while the phase button flips the phase by 180 degrees, offering further sound customization options. The low 'Q' option in the mid-band facilitates heavy boosting that remains exceptionally natural, making it ideal for unprocessed-sounding tracks, especially in acoustic and classical recordings.

For audio professionals who value the heritage and sound of the 1073 but require additional sonic flexibility, the 80 Series 1084 Microphone Preamplifier and EQ Module is the definitive choice. It retains all the beloved features and sounds of the 1073 while providing the added benefits of the sweet low pass filter and expanded high shelving frequency options. Whether you're recording in a studio or managing live sound, the 1084 module stands as a testament to Heritage Audio's commitment to excellence in audio engineering.

Heritage Audio Mic Preamplifier Module Features

  • Class A 80dB microphone preamplifier for professional-grade audio capture
  • Dual inductor-based EQ with selectable 'Q' values for precise sound shaping
  • Versatile high and low pass filters for refined frequency control
  • Three selectable high shelf frequencies for enhanced tonal flexibility
  • Phase reversal button and EQ bypass for advanced audio manipulation
  • Heritage Audio's renowned build quality for reliable studio performance

Key Features

  • Experience pristine sound quality with this Heritage Audio microphone preamplifier.
  • Achieve versatile tone shaping with the integrated EQ module for studio recordings.
  • Enjoy a wide gain range, perfect for capturing vocals, guitars, and drums effortlessly.
  • Low noise circuitry ensures clean, professional recordings every single time.
  • Selectable input impedance lets you optimize performance with various microphones.
  • Built to last, this preamp offers exceptional build quality for years of reliable use.

What's in the box:

  • Heritage Audio 80 Series 1084 Microphone Preamplifier and EQ Module
  • Heritage Audio 1 Year Parts & Labor Warranty
