This item is no longer available.
Review Summary
2021-02-18T07:36:50
When it worked it worked great but then transmission went pixelated. Adorama took the return no hassles! Thx
TIMOTHY W.
Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.
If we can’t fix it, we’ll replace it at no additional cost.
Protect your product from drops, spills, and more.
Enjoy your gear without fear. We have you covered!
When regular use of your product over time results in mechanical or electrical failure.
We will never charge you a deductible after the purchase of a plan.
Our claims process is simple & easy and our customer service team is happy to help.
Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.
Browse our FAQ
1x BNC SDI
1x HDMI type A
1x 3.5mm Audio
1x Mini-USB
1x 2-Pin LEMO (Power)
1x BNC SDI Loop Out
2x RP-SMA Antenna
HDMI:
1080p: 60/59.94/50/30/29/97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50
480p: 60
SDI:
3G, HD, and SD-SDI (Auto-Selected)
SMPTE-259/274/292/296/372/424/425
2-Channel, HDMI/SDI-Embedded 24-Bit, 48 kHz
5.1 to 5.9 GHz (Configurable with China, North America, Europe, etc.)
40 MHz
OFDM-16QAM
17 dBm (Maximum)
AES-128
Voltage: 7 to 36 VDC
Consumption: < 6 W
L-Series
FCC
5 x 2.8 x 1" (12.7 x 7 x 2.5cm) (without Antennas or Battery Plate)
9.2 oz (260g)
1x 2-Pin LEMO (Power)
1x Mini-USB
5x RP-SMA Antenna
2x BNC SDI
1x HDMI type A
HDMI:
1080p: 60/59.94/50/30/29/97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50
480p: 60
SDI:
3G, HD, and SD-SDI (Auto-Selected)
SMPTE-259/274/292/296/372/424/425
2-Channel, HDMI/SDI-Embedded 24-Bit, 48 kHz
5.1 to 5.9 GHz (Configurable with China, North America, Europe, etc.)
40 MHz
OFDM-16QAM
-75 dBm
AES-128
Gold Mount
Voltage: 7 to 36 VDC
Consumption: < 7 W
FCC
6.9 x 4.2 x 1" (17.4 x 10.6 x 2.5cm) (without Antennas or Battery Plate)
21 oz (590g)
3.66" (93mm)
5dBi
5.1-5.9 GHz
1200Ft Transmission Range
No pressure about transmission,meet your shooting distance needs
More Interface,More Scenarios can be Chosen
Transmitter:SDI/HDMI Input/SDI Loop Out; Receiver:Dual SDI Output/HDMI Input
Broadcast-Level, Uncompressed and Non-delayed HD Signals
Support HD 1080P60 without compression and non-delayed,capture video details,video clearly visible
1 Transmitter with Multiple Receivers
Support one transmitter and multiple receivers for video transmission at the same time; Multiplex monitoring to reduce costs
Support Trigger, Synchronous Recording
Support slow motion recording,compatible with 25/50/100 FPS. Automatically synchronize camera recording
Support Timecode
Support LTC & VITC Timecode. Higher accuracy,no skipping and delay frame. Facilitate the director,recording engineer and other staffs to organize record
USB Software Upgrade
USB software upgrades automatically and is easy to operate, adding value to your products
OLED Screen
Status reading easily,displaying current channel,signal strength, video format, fan status and temperature
- Mushroom Antenna -
Signal Transmission direction of TX can be changed by bending mushroom antennas, which makes our wireless video transmitter applicable in more complex environment.
5dBi Double Gigh Gain Antena with Stronger Signal
Compare to the common antenna, this 5dBi Double High Gain Antenna can reach 2 times signal enhancement; and transmit faster transmission rate. Wireless signal strong extension, increase stability for 5.8G Transmission
360 Degree Rotating Anti-Pressure
Mushroom antenna can be bent 90 degrees.
With delicate structure design at bottom, it can be 360 Degree bend, and extend a ntenna life.
360 Rotating Anti-pressure material innovative technology makes the consumption rate low 80%.
The King of highest safety factor & strongest anti-damage.
Gold-Plated Material SMA Gold-Plated Interface
Adopt high quality silver-plated feeder; SMA gold-plated interface; Greatly extended transmission distance, wide range of application
Light ABS Environmentally Friendly Material Strong and Rugged
ABS injection molding, with strong pressure resistance & impact resistance.
Anti-aging; exposure resistance; strong and rugged.
Tough and light.
Features
5dBi
Strong Signal
High Compatibility
