Hall Research EX-HDBT3-RX100 HDBaseT Receiver for EMCEE200 Switcher
See all Hall Research items

Hall Research EX-HDBT3-RX100 HDBaseT Receiver for EMCEE200 Presentation Switcher

SKU: HREXHDBT3RX1 MFR: EX HDBT3-RX100
Be the first to review this itemAsk a Question
$469.21
$493.90
Save: $24.69 (5%)
OR
$79/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Extend your EMCEE200 Presentation Switcher's reach with this HDBaseT Receiver.
  • Enjoy uncompressed 4K video and audio with reliable HDBaseT signal extension.
  • Transmit crystal-clear HDMI 2.0b signals up to 4K60Hz with 4:4:4 color sampling.
  • Control devices remotely using integrated RS-232 and IR pass-through features.
  • Power the receiver conveniently via POH (Power over HDBaseT) for easy setup.
  • Integrate USB 2.0 devices seamlessly for interactive displays and control systems.
See More Product Details
Special Order?Estimated to Ship: 09/10/2025
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$34.99

2 Year

$59.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Hall Research EX-HDBT3-RX100 Specifications

  • Video

    DVI (single link)
    HDMI 1.4 and HDMI 2.0b including 12 bit color depth, 3D video and HDCP 1.4/2.2

  • Resolutions

    DVI signal - VGA (640 x 480) thru WUXGA (1920 x 1200)
    HDTV signal 480p through 4K 60 Hz 4:4:4

  • Connectors

    1x Terminal block 3P RS232
    1x 3.5 mm IR IN
    1x 3.5 mm IR OUT
    1x USB 2.0 Tab B
    1x RJ45 HDBT

  • Audio Formats

    LPCM 2CH Audio (32, 44.1 and 48 KHz sample rate)
    Digital Audio multi-channel 2.0, 5.1, 7.1

  • RS-232 Signals

    1x RX, TX and GND on Terminal Strip
    RS-232 Baud Rate: 115200, N, 8, 1

  • USB

    1x USB-B Host port - USB 2.0/1.1 compatible

  • IR

    1x 3.5mm IR Receiver: Tip= IR signal, Ring = GND , Sleeve= V+
    1x 3.5mm IR Emitter: Tip= IR signal, Sleeve= GND

  • POH Voltage

    48VDC PSE

  • POH Standard

    802.3af POH

  • POH Class

    class 3 13.5W

  • Temp/Humidity

    Storage: -4 Degree F to 140 Degree F (-20 Degree C to 60 Degree C)/10% to 90% non-condensing
    Operating: +32 to +122 Degree F (0 to +50 Degree C)/10% to 90%, non-condensing

  • Enclosure Type

    Aluminum Faceplate

  • UPC Code

    656750712580

About Hall Research EX-HDBT3-RX100

When integrated with the EX-HDBT3-TX100 in the EMCEE200 presentation switcher, the RX100 HDBaseT receiver becomes a powerful tool for enhancing your audio-visual experience. This receiver is designed to add an extra mirrored output to the EMCEE200, expanding its functionality and versatility.

The RX100 HDBaseT receiver is engineered to extend HDMI 2.0, Bi-Directional IR, USB 2.0, and RS-232 signals. It also receives Power over Ethernet (PoE) over a single CAT6A cable via the advanced HDBaseT 3.0 technology. This feature allows for an impressive transmission distance of up to 90 meters (295 ft), ensuring reliable and high-quality signal delivery over long distances.

In addition to its primary functions, the RX100 HDBaseT receiver also features a second HDMI input. This added feature provides the convenience of connecting an additional local source device, offering more flexibility in your setup.

In summary, the RX100 HDBaseT receiver for EMCEE200 presentation switcher is a robust and efficient solution for your audio-visual needs, providing extended connectivity and high-quality signal transmission.

Hall Research EX-HDBT3-RX100 Features

  • For use with EMCEE200 presentation switcher
  • Extends HDMI 2.0, Bidirectional IR, RS-232 and receives PoE over single CAT-6A cable via HDBaseT 3.0 up to (90m) 295'
  • A second HDMI input allows for additional connection of a local source device

Warranty Information

This product has a limited warranty of 36 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Extend your EMCEE200 Presentation Switcher's reach with this HDBaseT Receiver.
  • Enjoy uncompressed 4K video and audio with reliable HDBaseT signal extension.
  • Transmit crystal-clear HDMI 2.0b signals up to 4K60Hz with 4:4:4 color sampling.
  • Control devices remotely using integrated RS-232 and IR pass-through features.
  • Power the receiver conveniently via POH (Power over HDBaseT) for easy setup.
  • Integrate USB 2.0 devices seamlessly for interactive displays and control systems.

What's in the box:

  • Hall Research EX-HDBT3-RX100 HDBaseT Receiver
  • Hall Research 3 Year Limited Warranty
