Hall Research ULTRA-V-R 4K UHD HDMI Splitter/Extended Over CAT6 to 328', RJ45 Output

SKU: HRULTRAV1S MFR: ULTRA-V-1S
Earn VIP Reward Points

Key Features

  • Extend HDMI signals up to 328 feet with this 4K UHD HDMI Splitter over CAT6.
  • Enjoy crystal-clear visuals with HDMI 1.4, supporting up to 4K60 resolution.
  • This HDMI splitter supports DVI single link for versatile connectivity options.
  • Use this HDMI extender in environments from 32 to 122°F with robust cooling.
  • Reliable HDMI distribution with a MTBF of 90,000 hours, ensuring lasting performance.
  • Compact metal enclosure protects this HDMI splitter, compliant with CE & FCC standards.
See More Product Details
Special Order?Estimated to Ship: 08/20/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$174.99

3 Year

$224.99

4 Year

$299.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Hall Research ULTRA-V-1S Specifications

  • Video Standards

    DVI (single link)
    HDMI 1.4 video specifications including 12 bit color depth, 3D video
    HDCP 1.4

  • Connectors

    1x HDMI Input
    1x HDMI Output
    1x RJ45 Output
    1x Mini-USB Service Port
    1x 2.0MM Locking DC Power Input

  • Resolutions

    DVI Signal: VGA (640x480) thru WUXGA (1920x1200)
    HDTV Signal: 480p through 4K60 4:2:0 (Interlaced resolutions are not supported)

  • Power Supply

    100 VAC to 240 VAC, 47-63 Hz, External; 5 VDC

  • Temperature/Humidity

    Storage: -40 to +158 Degree F (-40 to +70 Degree C)
    10% to 90%, non-condensing
    Operating: +32 to +122 Degree F (0 to +50 Degree C)
    10% to 90%, non-condensing

  • Typical DC

    5V DC, 4.0 A Power Supply

  • Current Draw

    TBD

  • Cooling

    Convection

  • Enclosure type

    Metal (Steel)

  • Saftey

    CE

  • EMI/EMC

    CE, FCC Class A

  • MTBF

    90,000 hours (estimate)

About Hall Research ULTRA-V-1S

The ULTRA-V series are a family of extenders used to extend HDMI Video at resolutions up to 4K UHD to one or more remote locations up to a maximum distance of 100m (328ft) over a single CAT5e/CAT6 cable.

The Senders are available in three versions, depending on the number of remote outputs needed. ULTRA-V-1S has a single remote output, ULTRA-V-4S has four, and ULTRA-V-8S has eight. All Senders feature a single HDMI input and a local HDMI output. This allows for a local display, or daisy-chaining the HDMI to another Sender to increase the number of remote displays.

The Receivers have a single remote input, and one HDMI output for connection to a remote display.

Hall Research ULTRA-V-1S Features

  • Supports high resolution HDMI video including FHD (1920x1080), WQHD (2560x1440), and 4K UHD (3840x2160)
  • Local HDMI outputs at all Senders to connect to a local display, or to daisy-chain a second ULTRA-V Sender
  • 1 output to distribute video to multiple locations
  • No video calibration required; no video quality reduction due to cable length or type
  • ULTRA-V Receivers are compatible with ULTRA-4K Sender

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Extend HDMI signals up to 328 feet with this 4K UHD HDMI Splitter over CAT6.
  • Enjoy crystal-clear visuals with HDMI 1.4, supporting up to 4K60 resolution.
  • This HDMI splitter supports DVI single link for versatile connectivity options.
  • Use this HDMI extender in environments from 32 to 122°F with robust cooling.
  • Reliable HDMI distribution with a MTBF of 90,000 hours, ensuring lasting performance.
  • Compact metal enclosure protects this HDMI splitter, compliant with CE & FCC standards.

What's in the box:

  • ULTRA-V-R 4K UHD HDMI Splitter/Exxtended Over CAT6 to 328'
  • Hall Research 3 Year Limited Warranty
