Hikvision 60W Single Port PoE Midspan Injector for PTZ Camera
See all Hikvision items

Hikvision 60W Single Port PoE Midspan Injector for PTZ Camera

SKU: HV101700361
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Hikvision Single Port PoE Midspan Specifications

  • Compatibility

    PTZ Camera

  • Input Current

    2A

  • Output Voltage Range

    54V - 57V

  • Output Power

    60W

  • Pass Through Data Rates

    10/100/1000 Mbps

  • Ports

    Two 10/100/1000M adaptive RJ45 ports, one is DATA/IN, another is PoE/DATA

  • LED Indicator

    Power & PoE Status(The module operates normally when MID and END are on)

  • Base Function

    Compliance to IEEE 802.3 at/af Standard for PD

  • Network Medium

    10BASE-T: unshielded twisted pair category 3, 4 or 5
    100BASE-TX: unshielded twisted pair category 5 and above
    1000BAST-TX: unshielded twisted pair category 5 and above

  • Protection Methods

    Output Over Current Protection, Short Circuit Protection

  • Operating Humidity

    5% - 90%

  • Operating Temperature

    -4 - 140 Degree F (-20 - 60 Degree C)

  • Dimensions (L x W x H)

    7.28 x 2.78 x 1.46" (185 x 70.8 x 37mm)

  • Weight

    16.68 oz (473g)

About Hikvision Single Port PoE Midspan

Hikvision POE midspan is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3at Power-over-Ethernet (PoE) standard.

The converter signature and control circuit provides the PoE compatibility signature and power classification required by the Power Sourcing Equipment (PSE) before applying up to 60W power to the port

Hikvision Single Port PoE Midspan Features

  • RoHS compliant
  • Compatible With All IEEE pre 802.3af, 802.3at and Legacy Powered Devices
  • Input voltage: 90Vac-264Vac
  • Support 300Vac input for long time work
  • Output over current protection
  • Short circuit protection
  • MTBF >=1,000,000 hrs
  • Surge protection
  • CE mark
  • WEEE compliant

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • RoHS compliant
  • Compatible With All IEEE pre 802.3af, 802.3at and Legacy Powered Devices
  • Input voltage: 90Vac-264Vac
  • Support 300Vac input for long time work
  • Output over current protection
  • Short circuit protection

What's in the box:

  • 60W Single Port PoE Midspan Injector
  • Hikvision 3 Year Limited Warranty
