Hikvision Turbo HD1080P Outdoor Vandal Proof IR Dome Camera with 2.8-12mm Lens Specifications

  • Image Sensor

    1/3" Progressive Scan CMOS

  • Signal System

    PAL/NTSC

  • Effective Pixels

    1920 (H) x 1080 (V)

  • Min. Illumination

    0.01 Lux at (F1.2,AGC ON),0 Lux with IR
    0.014 Lux at (F1.4,AGC ON), 0 Lux with IR

  • Shutter Time

    1/25(1/30)s to 1/50,000s

  • Lens

    2.8-12mm at F1.4
    Angle of view: 103 Degree - 32.1 Degree

  • Lens Mount

    14mm

  • Adjustment Range

    Pan: 0 - 355 Degree , Tilt: 0 - 80 Degree , Rotation: 90 Degree

  • Day& Night

    IR cut filter with auto switch

  • Wide Dynamic Range:

    120dB

  • Video Frame Rate

    1080p at 25fps/1080p at 30fps

  • Synchronization

    Internal Synchronization

  • Video Output

    1Vp-p Composite Output (75 Ohms/BNC)

  • S/N Ratio

    More than 52dB

  • Up the Coax

    Support

  • Camera ID

    On/off (15 characters, position programmable)

  • D/N Mode

    Color/ BW/ EXT

  • Auto White Balance

    ATW/ AWC-SET/ Indoor/ Outdoor/ Manual

  • Private Mask

    On/Off, maximum 8 zones

  • Motion Detection

    On/Off, maximum 4 zones

  • BLC

    On/Off

  • AGC

    Support

  • Anti-flicker

    On/ Off

  • Language

    English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic

  • Function

    Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM

  • Scene

    Indoor, Outdoor, Indoor1, LOW-LIGHT

  • Operating Conditions

    Minus 30 Degree C - 60 Degree C (-22 Degree F - 140 Degree F)
    Humidity 90% or less (non-condensing)

  • Power Supply

    12 V DC 10%
    (-A series support 24 V AC 10%, 12 V DC 10%)

  • Power Consumption

    12 VDC: Max. 4W
    24 VAC: Max. 5W

  • Impact Protection

    IK10

  • Weather Proof

    IP66

  • IR Range

    Up to 40m

  • Dimension

    5.72 x 4.89" (145.3 x 124.2 mm)

  • Weight

    1.95 lb (880 g)

  • UPC Code

    816783019449

About Hikvision Turbo HD1080P Outdoor Vandal Proof IR Dome Camera with 2.8-12mm Lens

Hikvision's brand reputation is built on producing quality surveillance and video components, and this outdoor dome-style unit is no exception. With a whole host of smart functions, helpful interface points, and additional security features, the camera will help keep a watchful eye on what's important to you.

The camera's built around a 1/3" progressive-scan CMOS sensor, which provides 1080p video output as well as still-image capture. Low-light performance is aided by digital noise reduction technology, as well as an IR cut filter and supplemental LED lighting, increasing the night vision range to 40 meters in total darkness. Other security features include motion and intrusion detection and a tampering alarm.

The camera's housing is weatherproofed to an IP66 standard, meaning it can be installed in an open outdoor setting such as under a large overhang, near entry/exit doors, or in uninsulated structures like garages. It can operate without issue in temperatures as low as -22F and as high as +140F, and can handle humidity up to 90%.

• 2 Megapixel high-performance CMOS
• Analog HD output, up to 1080P resolution
• True Day/Night
• 2.8 - 12mm vari-focal lens
• OSD menu, 3D DNR, Smart IR
• Up to 40m IR distance
• IP66 weatherproof & vandal proof
• 24V AC/ 12V DC (-A)

Key Features

  • 2MP still-image capture
  • 1080p video recording
  • Progressive-scan CMOS sensor
  • True day / night modes
  • VariFocus lens
  • IP66 weatherproof design

What's in the box:

  • Hikvision Turbo HD1080P Outdoor Vandal Proof IR Dome Camera with 2.8-12mm Lens
  • Hikvision 3 Year Limited Warranty
