This item is no longer available.
Video Input and Transmission
• Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input
• Up to 2-ch 4MP IP cameras input
• Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
Compression and Recording
• H.265+/H.265/H.264+/H.264 encoding for the main stream and H.265/H.264 for the sub-stream of analog cameras
• Connectable to H.265+/H.265/H.264+/H.264 IP cameras
• H.265+ can be enabled to improve encoding efficiency and reduce data storage costs
• Up to 3MP resolution for recording
• Supports real-time 1080p lite and when enabled, the image effect is similar with 1080p
Video Output
• Simultaneous HDMI/VGA output
• HDMI output at up to 4K (3840 x 2160) resolution
• Separate CVBS output
Storage and Playback
• 2x SATA Interfaces
• 16-ch synchronous playback
• Smart search for efficient playback
• Supports the 3rd party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)
Smart Function
• Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
• Supports 2-ch line crossing detection and intrusion detection and 1-ch sudden scene change detection
• VQD (Video Quality Diagnostics)
• Supports PTZ control via Omnicast VMS of Genetec protocol
Network & Ethernet Access
• Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
• 1x RJ45 10M/100M/1000M Ethernet network interface
• Output bandwidth limit configurable
