Ikan BEM-242 24" Studio Broadcast & Production LED Monitor with Waveform & Vectorscope (BON), 1920x1080

BEM-242 is a cost-effective 24" LED broadcast monitor. It has color-calibrated screen with selectable color temperatures. Also, an optional tilting stand is selectable on purchase.

• Color Calibrated Screen
• Signal Analysis Features
• Lightweight and Thin Form Factor
• 3G-SDI Support
• 10-bit Signal Processing
• Monitor Control/Update via RS-422
• De-embedded 8 to 16ch Audio Level Meter (SDI)
• 2 Channel Audio Level Meter (HDMI)
• 3 Color Tally Lamp
• Rack and Vesa-mount Options (sold separately)
• Picture in Picture
• Vector scope (SDI Only)
• Exposure Range Check(SDI Only)
• Menu Setting Copy via USB Flash Memory
• UMD Mode Display
• Zero/Under/Over Scan
• Pixel to Pixel
• R/G/B/Gray Only (SDI)
• Time Code Display (ATC_HD-SDI,DVITC_SD-SDI) (SDI Only)
• R,G,B and White Internal Patterns Display for Color Test (SDI Only)
• 10-bit Signal Processor
• Waveform (SDI Only)
• Focus Assistance(SDI Only)
• False Color (SDI Only)
• V-CHIP display (SDI Only)
• Various Markers(EBU, 4:3, 16:9, 1.85:1, 2.35:1, etc.)
• H/V Delay(SDI)
• R/G/B Only (HDMI)
• Closed Caption (CEA-608/708, SDI Only)
• Remote Control via GPI(RJ-45) Port
• Rack & VESA Mount (Option)

Color-Calibrated Screen
The screen is calibrated to reproduce precise colors offering selectable color temperatures such as 3200K, 5600K, 6500K, 9300K.

Signal Analysis Function
SDI Waveform/Vectorscope, R/G/B or Gray only modes and audio level meters are included. Three function buttons in front are user-assignable. Markers and safety area are displayed as user selected in the menu to check the sides and edges of taken pictures.

Lightweight and Thinner Volume
It is easy to carry and install the monitor anywhere due to the thin frame and light weight.
