Ikan OTTICA Full HD NDI|HX 30x PTZ Video Camera with PoE, White

SKU: IAOTTICA6 MFR: OTTICA-30X-WH
Earn VIP Reward Points

Key Features

  • Capture crystal-clear video with the Ikan PTZ camera's stunning Full HD 1080p resolution.
  • Experience incredible detail with the 30x optical zoom, perfect for live streaming events.
  • Enjoy versatile connectivity with HDMI, SDI, and NDI|HX, ensuring seamless integration.
  • Achieve smooth and quiet pan, tilt, and zoom operations with the step-driving motor mechanism.
  • Power over Ethernet (PoE) support simplifies setup, reducing cable clutter for video production.
  • Remotely control your PTZ camera with ease using IP VISCA, PELCO-D, and ONVIF protocols.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Ikan OTTICA Specifications

  • Color

    White

  • AV

    F1.6 - F4.7

  • Aspect Ratio

    16:9

  • Audio Compression Format

    AAC/MP3/G.711A

  • Audio Input Interface

    A-IN: Double Track 3.5mm Linear Input

  • Audio Output

    Yes

  • Auxiliary Power

    Yes

  • Base Connection Type

    1/4"-20 Screw Mount

  • BLC

    ON/OFF

  • Communication BPS

    2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 115200bps

  • Control Interface

    RS232 (input & output), RS485

  • Control Protocol

    IP VISCA, VISCA, PELCO-D, PELCO-P, ONVIF; Baud Rate:115200/9600/4800/2400bps

  • Digital Resolution

    1920x1080p

  • Digital Noise Reduction

    2D & 3D DNR

  • Effective Pixels

    16: 9, 2.07 megapixel

  • Input Audio Format

    1/8"

  • Input Current

    1A (Maximum)

  • Input Voltage

    DC12V +/-10%

  • Inputs

    1/8" Audio, RS-232 Cascade, DC12V

  • Interface

    3G-SDI, HDMI, LAN(NDI), RS232 (In & Out), RS485, A-IN

  • Modulation Mode

    OFDM

  • Motor Type

    Step-Driving Motor Mechanism

  • Signal to Noise Ratio

    >55dB

  • Optical Zoom

    30x f=4.3-129mm

  • Output Voltage

    DC12V

  • Pan Control Speed

    0.1 -60 Degree /sec

  • Pan Rotation

    +/-170 Degree

  • Port Network

    RJ45

  • Power Adapter

    Input: AC110V-AC220V. Output: DC12V/1.5A

  • Power Consumption

    12W (Max) / CONTROLLER: 0.6 W (Max)

  • Power Interface

    HEC3800 Outlet (DC12V), 2-pin Waterproof Aerial Socket (RF Model)

  • Power Supply

    DC12V +/-10%

  • Preset Number

    255 presets (10 presets by Remote Controller)

  • Preset Speed

    Pan: 60 Degree /sec, Tilt: 30 Degree /sec

  • Remote Control

    IR Remote Included

  • Resolution

    1080p 60p

  • Sensor

    1/2.8" HD CMOS sensor

  • Serial Port

    RS422, RS232

  • Storage Temperature

    14 Degree F - 140 Degree F (-10 Degree C - 60 Degree C)

  • Storage Humidity

    20%-95%

  • Tilt Control Speed

    0.1-30 Degree /sec

  • Tilt Rotation

    30 Degree -+90 Degree

  • Video Compression Format

    H.264, H.265

  • Viewing Angle

    2.34 Degree -65.1 Degree

  • Voltage

    DC12V

  • White Balance

    Auto / Manual/ One Push/2400K - 7100K

  • Working Humidity

    20%-80%

  • Working Temperature

    14 Degree F - 122 Degree F (-10 Degree C - 50 Degree C)

  • Dimensions (W x H x D)

    5.9 x 5.9 x 6.6" (150 x 150 x 167.5mm)

  • Weight

    3.08 lbs (1.40kg)

  • UPC Code

    847983034352

About Ikan OTTICA

Bring professional-grade video capture to your setup with the OTTICA Full HD NDI|HX 30x PTZ Video Camera with PoE in white. This high-quality camera is equipped with a 1/2.8" CMOS sensor and a 4.3-129mm varifocal lens, allowing for detailed video capture at a maximum resolution of 1080p at 60fps.

The OTTICA camera's advanced ISP processing algorithms ensure vivid, high-resolution images with a strong sense of depth and fantastic color rendition. With support for H.265/H.264 encoding, motion video remains fluent and clear, even under less than ideal bandwidth conditions.

Incorporating innovative NDI technology, this camera offers seamless integration with NDI-compatible software and hardware. The full-bandwidth NDI 1080p x60 fps video data stream uses approximately 100Mbps, while the NDI|HX video data stream requires only around 10Mbps, expanding the camera's compatibility with various network options.

The sophisticated 30x optical zoom lens ranges from 2.34 Degree (tele) to 65.1 Degree (wide), providing greater flexibility in framing shots and capturing distant subjects. The camera also employs an autofocus algorithm for fast, accurate, and stable focusing performance.

The OTTICA camera ensures high SNR with its low noise CMOS and advanced 2D/3D noise reduction technology. The step drive motor mechanism and motor drive controller allow for smooth and noiseless PTZ operation.

This professional camera supports POE (802.3af), HDMI, 3G-SDI, Ethernet (NDI|HX), RS-232, RS-485, and audio-in connectivity. It also includes a low-power sleep/wake up function, RS-232 cascade function, and the ability to program up to 255 preset camera positions.

Control the OTTICA camera over IP through a web client, adjusting various parameters including pan, tilt, zoom, exposure, shutter speed, focus, color temperature, and more. The camera supports multiple control protocols such as VISCA, IP VISCA, PELCO-D, PELCO-P, and ONVIF, and can be directly controlled from software like OBS using NDI|HX, or from the Web Client using the camera IP address in a browser tab.

The OTTICA Full HD NDI|HX 30x PTZ Video Camera with PoE comes with a wall mount for easy installation, providing a sturdy long-term mounting solution. Please note that the OTTICA camera is not compatible with the Blackmagic Design ATEM Television Studio HD at 1080p 60fps, but it is compatible with other video switchers including Black Magic's ATEM Mini & ATEM Mini Pro.

Ikan OTTICA Features

  • NDI|HX2 Compatibility with PoE (Power Over Ethernet)
  • NDI|HX License Included
  • 1/2.8" CMOS Sensor
  • 1080/60P Resolution/Frame Rate
  • Fast, Stable, & Accurate Auto-focus
  • Silent PTZ Motor Mechanism
  • 4.3-129mm Varifocal Lens with 30x Zoom
  • HDMI, SDI, Ethernet, RS-232, RS-485, & Audio-in Connectivity
  • 2D/3D Noise Reduction

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Capture crystal-clear video with the Ikan PTZ camera's stunning Full HD 1080p resolution.
  • Experience incredible detail with the 30x optical zoom, perfect for live streaming events.
  • Enjoy versatile connectivity with HDMI, SDI, and NDI|HX, ensuring seamless integration.
  • Achieve smooth and quiet pan, tilt, and zoom operations with the step-driving motor mechanism.
  • Power over Ethernet (PoE) support simplifies setup, reducing cable clutter for video production.
  • Remotely control your PTZ camera with ease using IP VISCA, PELCO-D, and ONVIF protocols.

What's in the box:

  • Ikan OTTICA Full HD NDI|HX 30x PTZ Video Camera with PoE (White)
  • Lens Cap
  • Power Adapter
  • RS232 Cable
  • IR Remote Controller
  • Wall Mounting Bracket
  • Mounting Screws
  • RS485 Connector
  • Cascade Cable
  • User Manual
  • Ikan 1 Year Limited Warranty
