Ikan OTTICA Full HD NDI|HX 20x PTZ Video Camera with PoE, White

SKU: IAOTTICAW1 MFR: OTTICA-WH
Earn VIP Reward Points

Key Features

  • Capture crystal-clear video with the Ikan OTTICA's Full HD resolution, perfect for streaming.
  • Experience smooth, precise control with this PTZ camera's step-driving motor mechanism.
  • Utilize the 20x optical zoom to get up close and personal, ensuring every detail is captured.
  • Enjoy versatile connectivity with 3G-SDI, HDMI, and NDI|HX, streamlining your workflow.
  • Power over Ethernet (PoE) offers easy setup, reducing cable clutter for a clean workspace.
  • Remotely manage your camera with IP VISCA, PELCO-D, and ONVIF protocols, enhancing control.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Ikan OTTICA Specifications

  • Color

    White

  • AV

    F1.6 - F3.5

  • Aspect Ratio

    16:9

  • Audio Compression Format

    AAC/MP3/G.711A

  • Audio Input Interface

    A-IN: Double Track 3.5mm Linear Input

  • Audio Output

    Yes

  • Auxiliary Power

    Yes

  • Base Connection Type

    1/4"-20 Screw Mount

  • BLC

    ON/OFF

  • Communication BPS

    2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 115200bps

  • Control Interface

    RS232 (input & output), RS485

  • Control Protocol

    IP VISCA, VISCA, PELCO-D, PELCO-P, ONVIF; Baud Rate:115200/9600/4800/2400bps

  • Digital Resolution

    1920x1080p

  • Digital Noise Reduction

    2D & 3D DNR

  • Effective Pixels

    16: 9, 2.07 megapixel

  • Focusing

    Input Audio Format

  • Input Audio Format

    1/8"

  • Input Current

    1A (Maximum)

  • Input Voltage

    DC12V +/-10%

  • Inputs

    1/8" Audio, RS-232 Cascade, DC12V

  • Interface

    3G-SDI, HDMI, LAN(NDI), RS232 (In & Out), RS485, A-IN

  • Modulation Mode

    OFDM

  • Motor Type

    Step-Driving Motor Mechanism

  • Signal to Noise Ratio

    >55dB

  • Optical Zoom

    20x f=5.5-110mm

  • Output Voltage

    DC12V

  • Pan Control Speed

    0.1 -60 Degree /sec

  • Pan Rotation

    +/-170 Degree

  • Port Network

    RJ45

  • Power Adapter

    Input: AC110V-AC220V. Output: DC12V/1.5A

  • Power Consumption

    12W (Max) / CONTROLLER: 0.6 W (Max)

  • Power Interface

    HEC3800 Outlet (DC12V), 2-pin Waterproof Aerial Socket (RF Model)

  • Power Supply

    DC12V +/-10%

  • Preset Number

    255 presets (10 presets by Remote Controller)

  • Preset Speed

    Pan: 60 Degree /sec, Tilt: 30 Degree /sec

  • Remote Control

    IR Remote Included

  • Resolution

    1080p 60fp

  • Sensor

    1/2.8" HD CMOS sensor

  • Serial Port

    RS422, RS232

  • Storage Temperature

    14 Degree F - 140 Degree F (-10 Degree C - 60 Degree C)

  • Storage Humidity

    20%-95%

  • Tilt Control Speed

    0.1-30 Degree /sec

  • Tilt Rotation

    30 Degree -+90 Degree

  • Video Compression Format

    H.264, H.265

  • Viewing Angle

    3.3 Degree -54.7 Degree

  • Voltage

    DC12V

  • White Balance

    Auto / Manual/ One Push/2400K - 7100K

  • Working Humidity

    20%-80%

  • Working Temperature

    14 Degree F - 122 Degree F (-10 Degree C - 50 Degree C)

  • Dimensions (W x H x D)

    5.9 x 6.6 x 5.9" (150 x 167.5 x 150mm)

  • Weight

    3.08 lbs (1.40kg)

  • UPC Code

    847983033379

About Ikan OTTICA

Before you set up your next professional video surveillance or remote monitoring system, consider the OTTICA Full HD NDI|HX 20x PTZ Video Camera with PoE. This sophisticated device is engineered with a 1/2.8" CMOS sensor and a versatile 5.5-110mm varifocal lens, enabling you to capture crisp, high-resolution 1080p videos at a fluid 60 frames per second.

The camera's advanced Power over Ethernet (PoE) capability simplifies installation by allowing both power and data to be transmitted over a single Ethernet cable, reducing cable clutter and streamlining your setup. With a broad range of connectivity options including HDMI, SDI, Ethernet (NDI|HX), RS-232, RS-485, and audio-in, this camera integrates seamlessly into a variety of professional environments.

OTTICA's cutting-edge step drive motor mechanism and motor drive controller ensure smooth, silent PTZ operations, perfect for environments where minimal noise is crucial. The camera's high-tech autofocus technology delivers fast, precise, and stable focusing, ensuring that your subject is always sharp and clear.

Image quality is paramount, and the OTTICA does not disappoint. It features advanced ISP processing algorithms that produce vivid images with excellent depth, high resolution, and true-to-life color rendition. The camera supports both H.264 and H.265 video compression, allowing for smooth video transmission even in bandwidth-constrained situations. With NDI|HX technology, the camera offers flexible network compatibility, requiring significantly less bandwidth compared to full-bandwidth NDI streams.

The OTTICA's variable optical zoom lens ranges from a wide 3.3 degrees to a broad 54.7 degrees viewing angle, coupled with a powerful 20x optical zoom, giving you the versatility to frame shots perfectly or capture distant subjects with ease. Low noise CMOS and advanced 2D/3D noise reduction technology work together to maintain a high signal-to-noise ratio, preserving image clarity even in low-light conditions.

For energy efficiency, the OTTICA includes a low-power sleep function, consuming less than 500mW in sleep mode. The camera also features an RS-232 cascade function for easy installation and supports up to 255 preset positions for quick access to different viewing angles.

Control of the OTTICA is intuitive and accessible. Use the "Advanced IP Scanner" to locate the camera's IP address, then manage a wide array of settings via the web client, including pan, tilt, zoom, and various image parameters. The camera is compatible with multiple control protocols such as VISCA, IP VISCA, PELCO-D, PELCO-P, and ONVIF, and is automatically recognized for immediate use with software like OBS or via the web client.

Included with the OTTICA is a sturdy wall mount, ensuring a secure and permanent installation. The mount is designed to support the camera with a 1/4"-20 screw, providing a reliable solution for any professional setting.

In summary, the OTTICA Full HD NDI|HX 20x PTZ Video Camera with PoE is an innovative, high-tech choice for professionals seeking advanced surveillance and remote monitoring capabilities with the flexibility and performance to meet the demands of modern video production.

Ikan OTTICA Features

  • NDI|HX2 Compatibility with POE (Power Over Ethernet)
  • 1/2.8" CMOS Sensor
  • 1080/60P Resolution/Frame Rate
  • Fast, Stable, & Accurate Auto-focus
  • Silent PTZ Motor Mechanism
  • 5.5-110mm Varifocal Lens with 20x Zoom
  • HDMI, SDI, Ethernet, RS-232, RS-485, & Audio-in Connectivity
  • 2D/3D Noise Reduction
  • Purchase of Additional NDI HX License NOT Required

Warranty Information

This product has a limited warranty of 12 months for parts and 12 months for labor.

Key Features

  • Capture crystal-clear video with the Ikan OTTICA's Full HD resolution, perfect for streaming.
  • Experience smooth, precise control with this PTZ camera's step-driving motor mechanism.
  • Utilize the 20x optical zoom to get up close and personal, ensuring every detail is captured.
  • Enjoy versatile connectivity with 3G-SDI, HDMI, and NDI|HX, streamlining your workflow.
  • Power over Ethernet (PoE) offers easy setup, reducing cable clutter for a clean workspace.
  • Remotely manage your camera with IP VISCA, PELCO-D, and ONVIF protocols, enhancing control.

What's in the box:

  • Ikan OTTICA Full HD NDI|HX 20x PTZ Video Camera with PoE (White)
  • Lens Cap
  • Power Adapter
  • RS232 Cable
  • IR Remote Controller
  • Wall Mounting Bracket
  • Mounting Screws
  • RS485 Connector
  • Cascade Cable
  • User Manual
  • Ikan 1 Year Limited Warranty
