Questions & Answers

FAQ

What is the maximum resolution supported by the 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit?

The KVMP Switch Kit supports a high resolution of up to 2560 x 1600 for Dual-Link DVI and 4K UHD Resolution of 3840x2160.

Is any software installation required to use the 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit?

No, this is a plug-and-play solution, requiring no software installation.

Can I use the 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit with my MAC keyboard?

Yes, this KVMP Switch Kit is compatible with both MAC and Sun keyboards.

What is included in the 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit?

The kit includes 4 active DisplayPort to DVI adapters, all necessary cables, a built-in USB 2.0 Hub, and supports 2.1 stereo sound.

What is Iogear's DynaSync technology?

Iogear's DynaSync technology remembers your monitor's configurations when switching between computers, providing a smooth transition and maintaining ideal video settings.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

IOGEAR KVMP Switch Kit Specifications

  • System Requirements

    Console:
    Standard wired USB keyboard
    Standard wired USB mouse
    4K Resolution: 4K enable HDMI monitor

    Computers:
    Dual-Link DVI or DisplayPort ports
    USB Type A port

    Operating Systems:
    Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows 10
    Mac OS 9 to 10.x
    Oracle Solaris
    Linux, Unix and other USB supported systems

  • Computer Connections

    Direct: 2
    Port Selection: Hotkeys, Pushbutton, or Mouse

  • Console Connectors: Monitor

    2x Dual-Link DVI-I Female

  • Console Connectors: Keyboard

    1x USB Type A Female

  • Console Connectors: Mouse

    1x USB Type A Female

  • Console Connectors: Audio

    1x Mini Stereo Jack Female (Green)

  • Console Connectors: Microphone

    1x Mini Stereo Jack Female (Pink)

  • CPU Connectors: Monitor

    4x Dual Link DVI-I or DisplayPort Female

  • CPU Connectors: Keyboard & Mouse

    2x USB Type B Female

  • CPU Connectors: Audio

    2x Mini Stereo Jack Female (Green)

  • CPU Connectors: Microphone

    2x Mini Stereo Jack Female (Pink)

  • Switches: F/W Upgrade

    1x 4-conductor 3.5mm Jack

  • Switches: Port Selection

    3x Pushbutton

  • Switches: Power Connections

    1x DC Jack

  • Connectors: USB

    2x USB Type A Female

  • LEDs

    Mode: 1x Orange
    KVM: 2x Green
    Audio: 2x Green
    USB Peripherals: 2x Green

  • Emulation: Keyboard

    USB

  • Emulation: Mouse

    USB

  • Emulation: Video Resolution

    Single Link DVI: 1920x1200; Dual Link DVI: 2650x1600; 4K UHD: 3840x2160 (depends on source)

  • Emulation: Scan Interval

    1-99 seconds (5 seconds by default)

  • Power

    Voltage: DC 5.3V
    Amps: 2.4A

  • Housing

    Case: Metal

  • Operating Temperature

    0 to 50 deg. C (32 to 122 deg. F)

  • Storage Temperature

    -20 to 60 deg. C (-4 to 140 deg. F)

  • Humility

    0-80% RH, Non-condensing

  • Dimensions (HxDxL)

    10.2 x 1.7 x 2.9" (25.91 x 4.32 x 7.37cm)

  • Weight

    2 lbs (0.91kg)

About IOGEAR KVMP Switch Kit

You can streamline your workspace with the 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit, a TAA Compliant solution designed for professionals seeking versatility and efficiency. This kit is an ideal choice for home offices or small to medium-sized businesses, offering the flexibility to connect with both DVI and DisplayPort computers.

The KVMP Switch Kit allows seamless control over two DVI or DisplayPort computers using a single USB keyboard, USB mouse, and two monitors. It's a cost-effective solution that includes 4 active DisplayPort to DVI adapters, enabling you to utilize your existing DisplayPort-enabled devices and convert your DisplayPort to DVI effortlessly.

This kit supports a high resolution of up to 2560 x 1600 for Dual-Link DVI and 4K UHD Resolution of 3840x2160, ensuring crisp and clear visuals. It's compatible with AMD Radeon Eyefinity Graphics Processing Units (GPUs) and compliant with DisplayPort 1.2 and HDMI 1.4 standards.

The Iogear's DynaSync technology remembers your monitor's configurations when switching, providing a smooth transition between computers. The kit also includes a built-in USB 2.0 Hub and supports 2.1 stereo sound for a full bass response and microphone support.

Switching between computers is a breeze with options to switch via pushbutton, hotkey, or mouse. The kit also features asynchronous hotkey switching between KVM focus, USB peripheral, and audio ports.

The 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit is a plug-and-play solution, requiring no software installation. It's also firmware upgradeable, HDCP compliant, and supports MAC and Sun keyboards.

With the added functionality of two USB 2.0 peripheral ports for asynchronously sharing USB devices between your computers, and a 3.5mm 2.1 audio and microphone port, this kit offers a comprehensive solution for your DVI and DisplayPort connections. All cables are included, making this KVMP Switch Kit a complete, ready-to-use solution right out of the box.

IOGEAR KVMP Switch Kit Features

  • High-performance 2-Port Dual-Link Dual View DVI and DisplayPort KVMP Switch Kit for seamless control over two computers
  • Supports high resolution up to 2560 x 1600 for Dual-Link DVI and 4K UHD Resolution of 3840x2160 for crystal-clear visuals
  • Includes Iogear's DynaSync technology for remembering monitor configurations when switching between computers
  • Plug-and-play solution with no software installation required, compatible with MAC & Sun keyboards
  • Features two USB 2.0 peripheral ports and a 3.5mm 2.1 audio and microphone port for enhanced functionality
  • Comes with 4 active DisplayPort to DVI adapters & all necessary cables for immediate setup & use

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Plug-and-play solution with no software installation required, compatible with MAC & Sun keyboards
  • Comes with 4 active DisplayPort to DVI adapters & all necessary cables for immediate setup & use

What's in the box:

  • Iogear 2-Port Dual Monitor Dual-Link DVI KVMP Switch
  • 4x Active DisplayPort to DVI Adapters
  • 2x Dual-Link DVI-D KVM Cables
  • 2x Dual-Link DVI-D Cables
  • Power Adapter
  • Quick Start Guide
  • IOGEAR 3 Year Limited Warranty
