IOGEAR KVMP Switch Specifications

  • Requirements

    Console
    HDMI compatible monitor
    Standard 104 key wired USB keyboard
    Standard 2 or 3 button wired USB mouse
    Speakers (optional)
    Computer
    HDMI port
    Type A USB port
    Audio ports (optional)

  • Direct Computer Connections

    4

  • Port Selection

    Pushbutton, Hotkey, RS-232 and Mouse (mouse emulation enabled)

  • Console Connectors

    Monitor: 1 x HDMI Female (Black)
    Keyboard: 1 x USB 2.0 Type-A (Black)
    Mouse: 1 x USB 2.0 Type-A (Black)
    Audio: 2 x 3.5mm Speaker Audio Jack (Green)

  • CPU Connectors

    Monitor: 4 x HDMI Female (Black)
    Keyboard & Mouse: 4 x USB 3.1 Gen1 Type B (Blue)
    Audio: 4 x 3.5mm Speaker Jack (green)

  • Port Selection Switches

    Pushbutton

  • Power Connections

    1 x DC 5V Jack

  • Connectors

    2 x USB 3.1 Gen 1 Type A (Blue, front and rear)
    RS-232: 1 x RJ-11

  • LEDs

    KVM: 4 (Orange)
    Audio: 4 (Green)
    USB Peripherals: 4 (Green)

  • Emulation Keyboard/Mouse

    USB/USB

  • Video Resolution

    4096 x 2160 @ 60Hz (Cinema 4K)

  • Scan Interval

    5-99 seconds (5 seconds default)

  • Power Consumption

    DC 5V: 2.535W: 54.5 BTU

  • Operation Temperature

    32 to 104 Degree F (0 to 40 Degree C)

  • Storage Temperature

    -4 to 140 Degree F (-20 to 60 Degree C)

  • Humidity

    0 to 80% RH, Non-condensing

  • Housing Case

    Metal, plastic

  • Dimensions (L x H x D)

    10.25 x 1.69 x 2.94" (26.03 x 4.3 x 7.47cm)

  • Weight

    30.4 oz (861g)

  • UPC Code

    881317518941

About IOGEAR KVMP Switch

Enhance your digital workspace with the 4-Port 4K DisplayPort KVMP Switch with HDMI Connection and USB 3.0 Hub, Audio (TAA Compliant). This advanced switch allows you to connect and control four HDMI-enabled computers using a single 4K HDMI monitor, USB keyboard, and mouse. Powered by IOGEAR's cutting-edge technology, this 4-Port 4K KVMP Switch offers a seamless user experience, enriched with extended features and the latest innovations in HDMI technology.

The switch comes with EDID support, enabling it to read and remember the monitor's parameters. This feature ensures a consistent video resolution, eliminating any changes when switching between connected computers.

The KVMP switch also offers enhanced audio connectivity. Its unique Audio Mixing feature allows you to add up to two audio sources using a simple hotkey operation. This means you can monitor the activities of each connected computer without having to switch between sources.

Experience cinema-quality visuals with the GCS1934H's ability to deliver clear image resolutions up to Cinema 4K (4096 x 2160) at a frame rate of 60Hz. This high-resolution support makes it an ideal choice for various industries, including healthcare, engineering, design, mid-sized businesses, and federal segments. It also enhances electronic applications in diagnostics, coding, software development, application design, and forensic analysis.

The KVMP switch also features Power On Detection, automatically connecting to the next powered-on computer. Its built-in USB 3.1 Gen1 ports support SuperSpeed 5 Gbps data transfer rates and are backward compatible with USB 2.0 and USB 1.1 legacy devices.

Switching between connected computers is a breeze with the push-button on the front panel or hotkey combination on your keyboard. The switch also offers mouse port-switching functionality, allowing you to switch between computers by clicking the wheel button on your 3-button USB mouse. For controlled access, the switch supports RS-232 commands.

This 4-Port 4K DisplayPort KVMP Switch is a cost-saving solution that reduces wear and tear on your USB peripherals and audio devices. Share your peripherals with the push of a button and save on the cost of additional keyboards, mice, monitors, hard drives, flash drives, printers, and more. Plus, its straightforward firmware updates eliminate the need to purchase upgraded KVMP switches.

IOGEAR KVMP Switch Features

  • Control 4 computers using a single keyboard, mouse, and 4K HDMI monitor
  • Superior video quality - Cinema 4K (4096 x 2160 @60Hz)
  • HDCP 2.2 compliant; HDR Support
  • 2-Port USB 3.1 Gen1 Hub with SuperSpeed 5Gbps transfer rate
  • Computer selection via front panel pushbuttons, hotkeys, mouse, or RS-232 command
  • Independent switching of the KVM, USB, and audio
  • Mouse emulation or bypass feature supports most mouse drivers and multifunction mice
  • Support HD Audio
  • Audio Mixer Modes -Mixes up to two audio sources as audio output
  • Multi-platform support - Windows7, Windows8.1, Windows10, Mac, and Linux
  • Multilingual keyboard mapping supports English, French, and German keyboards
  • Mac keyboard support and emulation
  • Auto Scan Mode to monitor all computers
  • Power On Detection
  • Hot pluggable
  • Firmware Upgradable
  • Support N-Key Rollover(NKRO) - permits collision - free keying

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Seamlessly switch between 4 computers with this IOGEAR 4K DisplayPort KVMP switch.
  • Enjoy stunning Cinema 4K resolution at 60Hz for detailed, high-quality visuals.
  • Connect your HDMI monitor, USB keyboard/mouse, and audio devices effortlessly.
  • Utilize the integrated USB 3.0 hub for high-speed data transfer and device connectivity.
  • TAA Compliant switch ensures secure and reliable performance for government use.
  • Hotkey and push-button port selection offers flexible and quick computer access.

What's in the box:

  • 4-Port 4K DisplayPort KVMP Switch
  • 2x HDMI Cables (6')
  • 2x USB 3.0 Cables (6')
  • 2x Audio Cable Set (6')
  • Power Adapter
  • Quick Start Guide
  • IOGEAR 3 Year Limited Warranty
