HP DesignJet Z6 Pro 64" Large Format Color Inkjet Plotter Printer
HP DesignJet Z6 Pro Printer: Out Of This World Precision | DesignJet Printers | HP
HP DesignJet Z6 Pro: Picture 1 thumbnail
HP DesignJet Z6 Pro: Picture 2 thumbnail
HP DesignJet Z6 Pro: Picture 3 thumbnail
HP DesignJet Z6 Pro: Picture 4 thumbnail
HP DesignJet Z6 Pro: Picture 5 thumbnail
HP DesignJet Z6 Pro: Picture 6 thumbnail
HP DesignJet Z6 Pro: Picture 7 thumbnail
HP DesignJet Z6 Pro: Picture 8 thumbnail
HP DesignJet Z6 Pro: Picture 9 thumbnail
HP DesignJet Z6 Pro: Picture 10 thumbnail
HP DesignJet Z6 Pro: Picture 11 thumbnail
HP DesignJet Z6 Pro: Picture 12 thumbnail
HP DesignJet Z6 Pro: Picture 13 thumbnail
HP DesignJet Z6 Pro: Picture 14 thumbnail
See all HP items

HP DesignJet Z6 Pro 64" Large Format Color Inkjet Plotter Printer

SKU: IHPZ6P64 MFR: 2QU25A
Be the first to review this itemAsk a Question
$11,550.00
OR
$963/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Experience vibrant color accuracy with our HP DesignJet Z6 Pro printer.
  • Create stunning, high-impact graphics with 2400 x 1200 optimized DPI resolution.
  • Print quickly with speeds up to 98 sq. m/hr, boosting your productivity.
  • Handle various media types, including fine art and photographic papers.
  • Enjoy reliable performance with pigment-based inks for long-lasting prints.
  • Safeguard sensitive data with advanced security features and encrypted printing.
See More Product Details
Temporarily On Backorder?Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

HP DesignJet Z6 Pro Specifications

  • Functions

    Print

  • Print speed

    Fast: 98 sq. m/hr on plain media
    Normal: 29 sq. m/hr on coated media
    Best: 14.1 sq. m/hr on glossy media

  • Ink drop

    7/3 pl dual-drop weight (M, C, PK); 6 pl single-drop weight (Y, CR, MK)

  • Print head nozzles

    3136 per color; 18,816 in total

  • Print cartridge volume delivered

    500 ml

  • Ink types

    Pigment-based

  • Number of print cartridges

    6 (cyan, magenta, yellow, matte black, photo black, chromatic red)

  • Print heads

    3 universal printheads (valid for all colors)

  • Color(s) of printing supplies

    Cyan, magenta, yellow, matte black, photo black, chromatic red

  • Print quality color (best)

    Up to 2400 x 1200 optimised dpi

  • Maximum optical density (black)

    4 L min/2.5 D

  • Finished output handling

    One automatic roll feed, spindle-less system, optional multifunction roll accessory enabling either automatic second roll feed with smartroll-switchingor take-up reel capability, optional standalone take-up reel accessory, media output bin, automatic horizontal cutter (cuts all HP Z-series printer-qualified media, including most canvas)

  • Media sizes standard (metric rolls)

    420 to 1626-mm

  • Roll external diameter

    170 mm

  • Roll maximum input

    2

  • Roll maximum weight

    25 kg

  • Recommended media

    Q6583A HP Universal Instant-dry Satin Photo Paper (FSCcertified)[4](Recyclable)[5]1524 mm x 30.5 m; E4J58B HP Artist Matte Canvas 1524 mm x 15.2 m; C6977C HP Heavyweight Coated Paper (FSCcertified)(Recyclable)1524 mm x 30.5 m; CH027A HP Everyday Matte Polypropylene, 2 Pack(Recyclable)1524 mm x 30.5 m; CG460B HP Premium Matte Photo Paper (FSCcertified)(Recyclable)914 mm x 30.5 m

  • Media thickness

    Up to 23.6 mil

  • Media thickness (metric)

    Up to 0.6 mm

  • Media width, maximum

    1626 mm

  • Supported Primary Applications

    Exhibition and event graphics; Indoor posters; Line drawings; Maps; Office Graphics; Orthophotos; Photo maps; Presentations; Renderings; Technical presentations

  • Non-printable area (roll media)

    5 x 5 x 5 x 5 mm

  • Media types

    Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit

  • Media weight, recommended

    80 to 500 g/sq. m

  • Model size

    1626 mm

  • Internal Storage

    500 GB self-encrypting

  • Line accuracy

    +/-0.1%

  • Printer drivers included

    Raster drivers for Windows, raster drivers for macOS; PDF driver for Windows and PostScript driver for macOS with optional PostScript/PDF Upgrade Kit

  • Print languages

    TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL

  • Print technology

    HP Thermal Inkjet

  • Theoretical minimum line width

    0.02 mm

  • Color Stability

    < 1 dE2000 in less than 5 minutes

  • Optional printer languages

    Adobe PostScript 3, Adobe PDF 1.7

  • Print repeatability

    Average < 0.5 dE2000, 95% of colors < 1.4 dE2000

  • Printing path

    Print drivers, HP Click, printing support for Chrome OS, HP Print Service Plugin for Android, HP Smart app for iOS and Android, HP SmartStream

  • Connectivity, standard

    Gigabit Ethernet (1000Base-T) (802.3, 802.3u, 802.3ab)

  • Security features

    HP Secure Boot, Whitelisting, Role Based Access Control, SNMPv3, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, Secure Disk erase (DoD 5220.22-M), Secure File erase, self-encrypted HDD, encrypted PIN printing, unique admin password, HP Connection Inspector

  • Memory

    86 GB file processing (based on 4 GB RAM)

  • Acoustic power emissions

    <=6.9 B(A) (operating), <=4.3 B(A) (idle), <4.0 B(A) (sleep) (active, printing)

  • Acoustic pressure emissions

    52 dB(A) (operating), 25 dB(A) (idle), <20 dB(A) (sleep)

  • Operating humidity range

    20 to 80% RH

  • Operating temperature range

    41 to 104 Degree F (5 to 40 Degree C)

  • Storage temperature range

    -4 to 131 Degree F (-20 to 55 Degree C)

  • Power consumption

    150 W (printing); <35 W (ready); <9 W (sleep); <0.3 W (off)

  • Power

    Input voltage (auto ranging): 100-240 V ( +/-10%), 50/60 Hz ( +/-3 Hz), 3 A max

  • Software included

    HP Click printing software, HP PrintOS, HP Partner Link, HP DesignJet Accounting Tool, HP Web Jetadmin, HP SmartTracker (optional), HP SmartStream (optional), HP JetAdvantage Security Manager (optional)

  • Electromagnetic compatibility

    Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia and New Zealand (RCM), Japan (VCCI), Korea (KCC), China (CCC)

  • Energy star certified

    Yes

  • Environmental certification

    ENERGY STAR 3.0, WEEE, EU RoHS, China RoHS, REACH, EPEAT

  • Safety

    IEC 60950-1+A1+A2 and IEC 62368-1 compliant; USA and Canada (CSA listed); EU (LVD and EN 60950-1 and 62368-1 compliant); Russia, Belarus, and Kazakhstan (EAC); Argentina (IRAM); Singapore (PSB), China (CCC)

  • Dimensions (W x D x H)

    102.5 x 31.10 x 55.19" (260.5 x 79 x 140.2cm)

  • Weight

    372 lbs (169kg)

About HP DesignJet Z6 Pro

Make your large format printing tasks a breeze with the high-quality DesignJet Z6 Pro 64" Large Format Color Inkjet Plotter Printer. This professional-grade printer is designed to deliver the highest precision and fine line detail, making it ideal for creating detailed images, sharp contour lines, and clear text.

Powered by the Adobe PDF Print Engine, this printer ensures excellent transparency and layer reproduction, providing you with clear PDF output every time. The high-definition HP HDNA printheads further enhance the printer's performance, enabling it to achieve the finest details with ease.

The DesignJet Z6 Pro is not just about precision, it's also about vibrant color reproduction. Thanks to HP Pixel Control, you can enjoy smooth gradients and distinct shades of color. Plus, with HP Vivid Photo Inks, your prints will be water- and fade-resistant, ensuring their longevity.

When it comes to efficiency and speed, this printer is a game-changer. It features a dual roll option for two media types/sizes, reducing media change time by up to 40%. The spindle-less and automatic roll feed further enhances media handling, making it the fastest in its class.

Boost your productivity with the ability to print 2X faster on plain paper without compromising on quality. The printer also comes with the world's easiest job submission software, HP Click, allowing you to send multiple files to print with just a click.

Security is a top priority with the DesignJet Z6 Pro. It's recognized as the world's most secure large-format printer, offering the best data protection with encrypted communications and an Access Control List. Secure PIN printing controls who can access the printer and its confidential documents. You can set security preferences at any time with HP Jet Advantage Security Manager software. Plus, with HP Connection Inspector, HP Secure Boot, and Whitelisting, you can rely on the best network protection.

In a nutshell, the DesignJet Z6 Pro 64" Large Format Color Inkjet Plotter Printer is a durable, fast, and versatile solution for all your large format printing needs.

HP DesignJet Z6 Pro Features

  • Precise - Highest precision and fine line detail
  • Productive-Enhanced efficiency, higher speed
  • Secure - World's most secure large-format printer

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Product Documents

User Manual

Key Features

  • Experience vibrant color accuracy with our HP DesignJet Z6 Pro printer.
  • Create stunning, high-impact graphics with 2400 x 1200 optimized DPI resolution.
  • Print quickly with speeds up to 98 sq. m/hr, boosting your productivity.
  • Handle various media types, including fine art and photographic papers.
  • Enjoy reliable performance with pigment-based inks for long-lasting prints.
  • Safeguard sensitive data with advanced security features and encrypted printing.

What's in the box:

  • HP DesignJet Z6 Pro 64" Large Format Color Inkjet Plotter Printer
  • Printheads
  • Introductory Ink Cartridges
  • Maintenance Cartridge
  • Printer Stand and Media Bin
  • 3-In Core Adapter
  • Setup Poster
  • Power Cord
  • User Maintenance Set
  • Quick Start Guide
  • HP 1 Year Limited Warranty
