Kino Flo FreeStyle Air Mini 55W RGB LED Light Panel with DMX Controller Universal Kit

SKU: KSFSAMINIU MFR: FE3.00103
Earn VIP Reward Points

Key Features

  • Achieve stunning color accuracy with CRI/TLCI >96, perfect for professional photography.
  • Easily adjust brightness from 1-100% and color temperature from 2500-9900K for any scene.
  • Experience versatile power options with both AC and DC input for studio or on-location shoots.
  • Control your lighting precisely with the included DMX controller, enhancing your creative workflow.
  • Enjoy the lightweight and durable design of this 55W RGB LED light panel for effortless portability.
  • Illuminate your subjects beautifully with the included SnapBox, providing soft, diffused light.
See More Product Details
New Item?
Free Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Kino Flo SYS-FAMINI Specifications

Light Fixture

Light Fixture

Jump to...
  • Number of Heads/Lights

    1

  • Fixture Type

    Light Panel

  • Photometrics

    6500K:
    183 fc / 1970 Lux at 3.3' (1m)
    21 fc / 233 Lux at 9.8' (3m)
    7 fc / 86 Lux at 16.4' (5m)

  • Color Accuracy Standard

    CRI >96
    TLCI >96

  • Color Temperature

    RGB

  • Color Temperature Range

    2500 to 9900K

  • Display

    LED

  • Built-In Flash

    No

  • Cooling System

    Passive

  • Dimming

    1 to 100%

  • Water Resistance/IP Rating

    IP20

  • Power Source

    AC Power
    Battery (Not Included)

  • Power Consumption

    55 W

  • AC Input Power

    100VAC-240VAC

  • DC Input Power

    24VDC

Mounting

Jump to...
  • Fixture Mount

    Proprietary

  • Umbrella Mount

    No

  • Accessory Mount

    Front: Proprietary

Physical Details

Jump to...
  • Panel Size

    21 x 13" (53.3 x 33cm)

  • Dimensions

    21 x 13 x 2" (53.3 x 33 x 5.1cm)

  • Weight

    3 lbs (1.4kg)

Controller

Jump to...
  • Connections

    Power
    AC Input: IEC Connector
    DC Input: 3-Pin XLR
    DMX In & Out: 5-Pin XLR (Male & Female)
    USB: Mini-B

  • Dimming Range

    100 to 1% Brightness

  • Power

    Voltage
    AC: 120 to 240 VAC, 50/60 Hz
    DC: 18 to 36 VDC, 150 W

    Draw
    AC: 1.25 A @ 120 VAC
    DC: 6.25 A @ 24 VDC

    Fuse: 3.15 A/250 V

  • Dimensions

    9.5 x 7.5 x 2.5" (24.13 x 19 x 6.35cm)

  • Weight

    4.5 lbs (2.04kg)

SnapBox

Jump to...
  • Color

    Interior: Silver

  • Item Type

    Softbox (Rectangular Shape)

  • Light Compatibility

    Direct Attachment (Requires No Bracket/Speed Ring)

  • Quick Open Type

    Collapsible

  • Accepts Grids

    Yes (Not Included)

  • Removable Front Face

    Yes

  • Interior Baffle

    No

  • Material

    Fabric

  • Dimensions

    23.5 x 15 x 3" (59.7 x 38.1 x 7.6cm) (Open)

  • Weight

    1.5 lbs (0.7kg)

Twist-On Mount

Jump to...
  • Mount

    5/8" (16mm) Baby Receiver

Extension Cable

Jump to...
  • Connector 1

    Proprietary Male

  • Connector 2

    Proprietary Female

  • Rated Power Support

    Not Specified by Manufacturer

  • Environmental Resistance

    No

  • Cable Length

    25' (7.62m)

About Kino Flo SYS-FAMINI

- FreeStyle Air Mini -
The FreeStyle Air Mini arrives ready to take its place as a lightweight accessory that integrates seamlessly with existing FreeStyle systems. Compatible with FreeStyle mounts, extension cables and LED-140 Series controllers, this portable thin profile panel offers the advantages of easy deployment and favorable cost of ownership to current FreeStyle owners and operators.

In addition to a twist-on mount for light stands, and corner bumpers for 4-point hangs, the FreeStyle Air Mini comes with eyelets to simplify overhead and other surface attachment. Its rigid construction prevents any flex when handling and safeguards the integrity of its components. Usable LED life is extended with a proven passively-cooled design that ensures color and luminosity remain stable over the rated life of the LEDs.

Ease of maintenance is built into a user serviceable design. It features a removable upper rail and quick access to pull-out LED platens that are easily replaced or repaired. Combining new mobility and reliable performance with familiar features, the FreeStyle Air Mini delivers Kino Flo's renowned Color Science LED technology in this lightweight addition to the range.

The FreeStyle Air Mini is lightweight with a slim profile. It includes a built-in harness and a twist-on mating plate to accept a twist-on mount. The four molded corners offer additional rigging points for rope hanging, for example. With the KinoGrip mount, the fixture can be hand-held. When the mount is removed, the fixture is flat and can be screwed to the wall or ceiling through its eyelets.

FreeStyle Air Mini Design
• Remote fixture
• KinoGrip Center Mount
• Lightweight, slim profile
• Mounts to stand, light enough to be hand-held


- SnapBox -
Kino Flo Lighting Systems has added another layer of light control refinement with a pair of new softbox products tailor-made for FreeStyle LED. DoPchoice of Munich has created the SnapBox light controls that mount snuggly and easily on Kino Flo's portable LED softlights. No special mounting rings or extra mounting accessories are required. The SnapGrid louver, a featherweight fabric butterfly, attaches to the front of the SnapBox with Self-Securing Closure to control the spread of light without black flags or cutters.

The award-winning DoPchoice softboxes and fabric grids earn kudos from gaffers and cinematographers for their compact, portable and durable designs. The SnapBox for FreeStyle LED's are ideal for lighting up to 8ft by 8ft of set space.

Kino Flo SYS-FAMINI Features

  • Color Rendering TLCI >96, CRI >96, TM-30-18 Rf=95, Rg=103
  • Kelvin presets
  • Dial-in color temperature control between 2500K-9900K
  • Green/Magenta Control
  • Hue angle and Saturation adjustments
  • Kino Flo presets and Gels
  • RGB control
  • CIE xy
  • FX Control
  • Camera Profiles LUTs
  • Color Space
  • Works with Apps with predetermined RGB presets or color wheels
  • Can use preset buttons to store custom Kelvin settings
  • Light levels do not change when selecting Kelvin settings
  • No color shift while dimming
  • Universal input 100VAC-240VAC or 24VDC
  • Energy efficient, draws 1.25A, 120VAC and 6.25A, 24VDC
  • Flicker-free, quiet operation
  • Full range onboard and DMX dimming
  • DMX wireless link (Lumen Radio)
  • DMX Auto Terminate
  • The firmware is updatable from a PC using the Mini B USB data port

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Achieve stunning color accuracy with CRI/TLCI >96, perfect for professional photography.
  • Easily adjust brightness from 1-100% and color temperature from 2500-9900K for any scene.
  • Experience versatile power options with both AC and DC input for studio or on-location shoots.
  • Control your lighting precisely with the included DMX controller, enhancing your creative workflow.
  • Enjoy the lightweight and durable design of this 55W RGB LED light panel for effortless portability.
  • Illuminate your subjects beautifully with the included SnapBox, providing soft, diffused light.

What's in the box:

  • Kino Flo FreeStyle Air Mini 55W RGB LED Light Panel
  • FreeStyle 140 LED DMX Controller
  • FreeStyle Air Mini SnapBox with 2x Diffusion
  • KinoGrip 41K Mount with 5/8" Baby Receiver Short
  • 25' FreeStyle/4 Extension Cable
  • Kino Flo 1 Year Limited Warranty
