KanexPro 4K HDBaseT 6x6 Matrix Switcher with PoE

The KanexPro MX-HDBASE6X6-4K matrix switcher is a professional 6 HDMI input to 6 HDBaseT output switch with 3 HDMI mirrored outputs designed for routing 4K/UHD applications. For proficient audio capabilities it includes 6 auxiliary audio inputs for stereo and 6 stereo outputs for HDMI audio de-embedding and IR inputs. The matrix switcher also features Ethernet port for controlling via web based GUI which reduces installation time and complicated set-up as well as full control for the matrix.

· Ultra-fast 6x6 switching with instant display
· Distribute six HDBaseT outputs up to 70m at 1080p 40m at 4KX2K on a single CAT5e/6 cable
· Supports power over Ethernet (PoE) to all six receivers
· Three HDMI mirrored outputs for local monitor support
· Deep color support up to 16 bit
· RGB/YCbCr 4:4:4, YCbCr: 4:2:2, 4K/30Hz
· Illuminated buttons w/ Front panel LCD
· Dedicated audio zones for digital and stereo audio
· Audio De-embedding
· Advanced EDID HDCP management
· Bi-directional IR RS-232 control
· Ethernet connectivity
· Controllable via front panel, RS232, IR IP
· IR remote control included
· Easy firmware upgrade thru Micro-USB port
· Locking HDMI connectors
· 2 RU rack-mountable steel enclosure
· External International power supply (100V-240V AC, 50/60Hz)

The HDMI inputs from the matrix can be controlled via front panel buttons, bi-directional IR RS232 or in GUI mode using Ethernet. The selected source is delivered to HDMI Output 1approx.3(for HDMI input 1approx.3) HDBaseT outputs 1approx.6 (easy extension to 70m at 1080p and 40m at 4KX2K on a single CAT5e/6 connection with optional PoE based HDBaseT receivers) simultaneously. The unit provides built-in EDID and HDCP management.

Applications
Ideally, designed for mid-scale applications such as multi-zone home theater, court systems, commercial AV distribution such as sending high-resolution 4K ultra imagery to medical displays where signal integrity and reliability is critical.

Note:
1. The HDBASE70POER receivers are not included with this matrix switcher please contact their sales team on ordering these to match your application.
2. To reduce video dropout problems from lighting, ceiling fans and other EMI issues, it is strongly recommended to use shielded CAT5e/CAT6 and use shielded RJ45 connectors with their HDBaseT products.
