KanexPro 4K HDMI and VGA Wall Plate Transmitter Over HDBaseT

SKU: KPWPHDBASETX MFR: WP-HDBASETX
Earn VIP Reward Points

Key Features

  • Extend HDMI/VGA signals up to 197 ft with this HDBaseT wall plate transmitter for seamless integration.
  • This affordable wall plate offers 4K HDMI and VGA inputs, perfect for classrooms and conference rooms.
  • Enjoy crystal-clear audio with the 3.5mm stereo jack, ensuring high-quality sound transmission via VGA.
  • Simplify installations with the space-saving, 2-gang Decora style wall plate, designed for easy mounting.
  • Supports resolutions up to 4Kx2K for HDMI, delivering stunning visuals for your display needs with ease.
  • Ensure reliable performance with this durable power supply wall plate, backed by a 3-year KanexPro warranty.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$79.99

2 Year

$139.00

3 Year

$209.00

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

KanexPro Transmitter Specifications

  • Input Signal

    1x HDMI (female), 1x VGA(female), 1x Audio (3.5mm Mini jack)

  • Input Connector

    1x HDMI, 1x VGA, 1x 3.5 mm mini-jack and 1x RS-232 Connector

  • HDMI Video Signal

    HDMI1.4

  • Audio

    Digital audio transmitted through HDMI audio & VGA thru 3.5mm Stereo Jack

  • Output Signal

    1x HDBaseT

  • Output Connector

    1x RJ-45

  • Resolutions supported

    VGA outputs resolution up to 1080p
    800x600 to 1920x1200
    3D formats
    4Kx 2K for HDMI

  • Transmission Mode

    HDBaseT Lite Technology

  • Resolution Range

    From 800x600 to 1920x1200, 4K

  • Maximum distance

    197' / 60.05m

  • Gain

    0dB to 10dB at 100MHz

  • Differential Phase Error

    +/-10 deg. at 135MHz_100M

  • SNR

    >70dB at 100MHz-100M

  • Bandwidth

    10.2Gbps

  • Return Loss

    <-30dB at 5KHz

  • THD

    <0.005% at 1KHz

  • Min to Max. Level

    <0.3V to 1.45Vp-p

  • Impedance

    75Ohms

  • Temperature

    -20 to 60 deg. C / -4 to 140 deg. F

  • Humidity

    10% to 90%

  • Power Supply

    24V DC

  • Power Consumption

    9.6W

  • Chassis

    Universal Decora Style 2-Gang Wall plate

  • Dimensions (W x H x D)

    104.5 x 89 x 44mm / 4.11 x 3.50 x 1.73"

  • Weight

    1.76lbs / 0.80kg

  • UPC Code

    814556017562

About KanexPro Transmitter

For professionals and enthusiasts seeking a durable and high-quality solution for signal transmission, the KanexPro WP-HDBASETX 4K HDMI and VGA Wall Plate Transmitter Over HDBaseT is an innovative choice. This compact, 2-input transmitter is capable of sending HDMI or 15-pin HD analog video, audio, and control signals up to 230 feet (70m) over a shielded CAT6 cable, ensuring reliable and high-quality signal transmission even over long distances.

Designed with a Decora style 2-gang wall plate, this transmitter not only offers functionality but also seamlessly blends with your decor. It supports Power over Ethernet (PoE) to the receiver, reducing the need for additional power sources and simplifying your setup.

Leveraging the power of HDBaseT technology, this wall plate extender is HDCP and EDID compliant, guaranteeing proper output to displays. It features a built-in scaling function for HDMI with output resolutions up to 4K, providing you with crisp, clear visuals every time.

With HDMI or VGA with audio input selectable, this transmitter offers versatility in signal transmission. It also provides the convenience of auto-switching or manual button control between inputs, and is RS232 controllable, making it user-friendly and easy to operate.

Ideal for use in classrooms, lecture halls, boardrooms, and home theaters, the KanexPro WP-HDBASETX 4K HDMI and VGA Wall Plate Transmitter Over HDBaseT is perfect for situations where HDMI and/or analog VGA based source devices are combined to present high-resolution signals up to 4K.

Please note, to maintain the integrity of the signal and avoid degradation or damage to the unit, it is advised not to use couplers between the RJ-45/ CAT6 cables. To reduce video dropout problems from lightings, ceiling fans, and other EMI issues, it is strongly recommended to terminate shielded CAT6 or CAT5e cables and use shielded RJ45 connectors with this extender product.

KanexPro Transmitter Features

  • 4K HDMI and VGA wall plate transmitter for seamless signal extension up to 230 feet
  • HDBaseT technology ensures HDCP and EDID compliance for reliable display output
  • Decora style 2-gang design with PoE support for a clean, efficient setup
  • Built-in scaling function enhances HDMI input to deliver high-resolution 4K video
  • Selectable HDMI or VGA with audio inputs and convenient auto or manual switching
  • RS232 controllable for easy integration and operation in various environments

Key Features

  • Extend HDMI/VGA signals up to 197 ft with this HDBaseT wall plate transmitter for seamless integration.
  • This affordable wall plate offers 4K HDMI and VGA inputs, perfect for classrooms and conference rooms.
  • Enjoy crystal-clear audio with the 3.5mm stereo jack, ensuring high-quality sound transmission via VGA.
  • Simplify installations with the space-saving, 2-gang Decora style wall plate, designed for easy mounting.
  • Supports resolutions up to 4Kx2K for HDMI, delivering stunning visuals for your display needs with ease.
  • Ensure reliable performance with this durable power supply wall plate, backed by a 3-year KanexPro warranty.

What's in the box:

  • KanexPro 4K HDMI and VGA Wall Plate Transmitter Over HDBaseT
  • 4x Screws for Wall Plate
  • 3x Pluggable Terminal Blocks (2-Pin Block
  • 3-Pin Block and 4-Pin Block)
  • Face Plate (Selectable)
  • 4x Screws for Face Plate
  • Power Adapter (DC 12V 2A
  • Selectable)
  • User Manual
  • KanexPro 3 Year Parts & Labor Warranty
