Kramer Electronics HDBT-IN4-F32 4-Channel HDMI over Extended Reach HDBaseT Input Card for VS-3232DN Switcher

SKU: KRHDBT4F32SE MFR: HDBT-IN4-F32/STANDALONE
Earn VIP Reward Points

Key Features

  • Seamless integration with VS-3232DN Switcher for reliable video switching performance.
  • Extend HDMI signals up to 430ft with HDBaseT technology for ultimate flexibility.
  • Enjoy 3D pass-through support, ensuring high-quality video for immersive experiences.
  • Bidirectional RS-232 and IR extension via terminal blocks simplifies device control.
  • Ensure compliance with HDCP 1.4 and HDMI 1.3a standards for secure connectivity.
  • Low latency and high resolution video bandwidth of 2.25Gbps per channel.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$99.99

3 Year

$119.99

4 Year

$154.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Kramer Electronics HDBT-IN4-F32 Specifications

  • Compatibility

    VS-3232DN Switcher

  • Inputs

    4 HDBaseT TP on RJ-45 connectors

  • Ports

    4 RS-232 and 4 IR on 10 pin terminal blocks for bidirectional RS-232 and IR extension
    1 Ethernet on an RJ-45 connector for bidirectional Ethernet extension

  • Bandwidth Per Channel

    Video: 2.25Gbps
    Serial data: 115200

  • Total Bandwidth

    Video: 6.75Gbps
    Serial data: 115200

  • Maximum Range

    130m (430ft) normal mode, 180m (590ft) ultra-mode (1080p at 60Hz at 24bpp). Note: When using Kramer HDBaseT cables

  • 3D Pass Through

    Supported

  • Extended Ethernet

    Up to 100Mbps extended line rate bandwidth

  • Extended Rs-232

    300 to 115200 baud rate

  • Power Consumption

    28W

  • Operating Temperature

    0 to 40 deg. C (32 to 104 deg. F)

  • Storage Temperature

    -40 to 70 deg. C (-40 to 158 deg. F)

  • Humidity

    10% to 90%, RHL non-condensing

  • Standard Compliance

    HDCP 1.4, HDMI 1.3a, HDBaseT

  • Safety Regulatory Compliance

    CE

  • Environmental Regulatory Compliance

    Complies with appropriate requirements of RoHs and WEEE

  • Dimensions (WxDxH)

    22.00 x 18.80 x 2.00cm (8.66 x 7.40 x 0.79")

  • Weight

    0.2kg (0.44 lbs) approx.

  • UPC Code

    7291063049973

About Kramer Electronics HDBT-IN4-F32

Take your professional AV installations to the next level with the HDBT-IN4-F32, a high-quality 4-Channel HDMI over Extended Reach HDBaseT Input Card designed specifically for the VS-3232DN Series Modular Multi-Format Digital Matrix Switchers. This advanced input card is engineered to facilitate the seamless transmission of four extended reach HDBaseT signals, incorporating bidirectional RS-232, Ethernet, and IR from the line to the chassis, ensuring efficient and reliable communication between devices.

With a maximum data rate of 6.75Gbps (2.25Gbps per graphic channel), the HDBT-IN4-F32 supports 3D pass-through, making it ideal for high-definition video applications that require dynamic and immersive visuals. The card's HDBaseT technology is not only HDTV compatible but also HDCP compliant, guaranteeing secure and high-quality digital content delivery.

The system's impressive range extends up to 130m (430ft) in normal mode and up to 180m (590ft) in ultra-mode (1080p at 60Hz at 24bpp), when used with Kramer HDBaseT cables. This extended reach capability is perfect for large venues such as conference rooms, auditoriums, and control rooms where the source and display equipment may be significantly distanced from each other.

Furthermore, the HDBT-IN4-F32 enhances connectivity with its Ethernet extension feature, allowing for up to 100Mbps of Ethernet connectivity in both directions. This facilitates LAN communication and device control across your network. The bidirectional RS-232 and IR extensions offer additional control flexibility, enabling the transmission of serial interface data and remote control of peripheral devices located at either end of the extended line.

This durable and reliable input card is an indispensable component for professional display systems that require sophisticated video signal routing. It is also an excellent choice for broadcast, presentation, and production facilities, as well as monitoring in large duplication systems. For rental and staging environments where setup and breakdown are frequent, the HDBT-IN4-F32's robust build ensures it can withstand the rigors of transport and constant handling.

Choose the HDBT-IN4-F32 for its advanced features, extended system range, and the reputable quality associated with Kramer Electronics, a leader in professional audio and video equipment. This input card is not just a component; it's a comprehensive solution for high-performance, long-distance AV signal transmission.

Kramer Electronics HDBT-IN4-F32 Features

  • High-quality 4-Channel HDMI over Extended Reach HDBaseT Input Card for the VS-3232DN Series Digital Matrix Switchers
  • Supports 3D pass-through with a maximum data rate of 6.75Gbps for dynamic, high-definition visuals
  • Extended system range up to 130m in normal mode and 180m in ultra-mode, ideal for large venue installations
  • Integrated bidirectional RS-232, Ethernet, and IR extensions for efficient device control and communication
  • HDTV compatible and HDCP compliant, ensuring secure and high-quality digital content delivery
  • Durable and reliable design from Kramer Electronics, a reputable name in professional audio and video equipment

Warranty Information

This product has a limited warranty of 84 months.

Key Features

  • Seamless integration with VS-3232DN Switcher for reliable video switching performance.
  • Extend HDMI signals up to 430ft with HDBaseT technology for ultimate flexibility.
  • Enjoy 3D pass-through support, ensuring high-quality video for immersive experiences.
  • Bidirectional RS-232 and IR extension via terminal blocks simplifies device control.
  • Ensure compliance with HDCP 1.4 and HDMI 1.3a standards for secure connectivity.
  • Low latency and high resolution video bandwidth of 2.25Gbps per channel.

What's in the box:

  • Kramer Electronics HDBT-IN4-F32 4-Channel HDMI over Extended Reach HDBaseT Input Card
  • Kramer Electronics 7 Year Limited Warranty
