Kramer Electronics KDS-DEC5 4K30 H.264 Video Decoder with PoE and Video Wall Support

SKU: KRKDSDEC5 MFR: KDS-DEC5
Earn VIP Reward Points

Key Features

  • Enjoy pristine video quality with the KDS-DEC5's 4K30 decoding capabilities.
  • Achieve reliable live streaming with H.264 compression for efficient broadcast.
  • Simplify setup using PoE (Power over Ethernet) for streamlined installations.
  • Utilize versatile video wall support for dynamic and engaging displays.
  • Ensure low latency streaming for real-time video applications and minimal delay.
  • Supports multiple formats, including HDMI, with stereo audio for immersive sound.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Kramer Electronics KDS-DEC5 Specifications

Outputs

Outputs

Jump to...
  • 1 HDMI (1.4)

    On a female HDMI connector

  • 1 Unbalanced Stereo Audio

    On a 3-pin terminal block connector

  • 1 Ethernet

    On an R-J45 connector

  • 1 RS-232

    On a 3-pin terminal block connector

  • Compression Standard

    H.264/MPEG-4 AVC

  • Profiles

    Base line, Main, High profile

  • Levels

    Up to 5.0

  • Rate Control

    CBR,VBR, adjustable GOP size

  • Bit Rates

    2Mbps-30Mbps

  • Encapsulation Format

    MPEG-2 transport stream

  • Transmission format

    TS over UDP, TS over RTP

  • Input Resolutions

    640x480, 800x600, 1024x768, 1280x800, 1280x1024, 1360x768, 1366x768, 1440x900, 1400x1050, 1600x1200, 1680x1050, 1920x1200, 720x480 (480p), 720x576 (576p), 1280x720 (720p30), 1280x720 (720p50), 1280x720 (720p60), 1920x1080 (1080p24), 1920x1080 (1080p25), 1920x1080 (1080p30), 1920x1080 (1080p50), 1920x1080 (1080p60) , 1920x1200, 3840x2160 (4Kp24), 3840x2160 (4Kp30)

  • Output Resolutions

    640x480, 720x480 (480p), 720x576 (576p), 800x600, 1024x768, 1280x720 (720p50), 1280x720 (720p60), 1280x800, 1280x1024, 1366x768, 1440x900, 1600x1200, 1680x1050, 1920x1080 (1080p24), 1920x1080 (1080p25), 1920x1080 (1080p30), 1920x1080 (1080p50), 1920x1080 (1080p60), 1920x1200, 3840x2160 (4Kp24), 3840x2160 (4Kp30)

  • Compression Standard

    MPEG4 AACLC

  • Channels

    2 channel (stereo), HDMI with stereo LPCM/AAC audio

  • Sample Frequency

    48kHz

  • Bitrate

    1.6Mbps (LPCM), =240Kbps (AAC)

  • Source

    PoE or 12V DC power supply (not included)

  • Consumption

    5.6W

Environmental Conditions

Jump to...
  • Operating Temperature

    0 to 45 deg. C (32 to 113 deg. F), 10% to 90%, non-condensing

  • Storage Temperature

    -20 to 70 deg. C (-4 to 158 deg. F), 10% to 90%, non-condensing

  • Humidity

    10% to 90%, non-condensing

General

Jump to...
  • Dimensions (WxDxH)

    21.90 x 13.50 x 2.50cm (8.62 x 5.31 x 0.98")

  • Weight

    0.8kg (1.76 lbs) approx.

  • UPC Code

    7291063085599

About Kramer Electronics KDS-DEC5

Take your video installations to the next level with the Kramer Electronics KDS-DEC5 4K30 H.264 Video Decoder. This advanced and efficient device is engineered to deliver high-quality video decoding, supporting 4K resolutions at 30Hz with full 4:4:4 color sampling for crystal-clear images. The KDS-DEC5 is not only reliable but also durable, ensuring long-lasting performance in a variety of professional settings.

With its built-in Power over Ethernet (PoE) capability, the KDS-DEC5 simplifies installation by eliminating the need for a separate power supply, allowing for a cleaner and more organized setup. This feature is particularly beneficial in situations where power outlets are scarce or difficult to reach.

The decoder's video wall support is a standout feature, offering the flexibility to create stunning large-scale video displays. Whether you're setting up a video wall for a commercial advertisement, an educational facility, or a high-end entertainment venue, the KDS-DEC5 seamlessly integrates into both unicast and multicast configurations, making it a versatile choice for one-to-one or many-to-many streaming scenarios.

Designed to work effortlessly with various video sources, the KDS-DEC5 is the ideal solution for professionals seeking a decoder that can handle the demands of 4K video content with H.264 compression. Its robust construction and reliable performance make it a smart investment for anyone looking to produce an exceptional visual experience.

In summary, the KDS-DEC5 4K30 H.264 Video Decoder from Kramer Electronics is a top-tier choice for those in need of a high-performance, efficient, and flexible video decoding solution. Its PoE feature and video wall support, combined with its compatibility with 4K and H.264 standards, make it an indispensable tool for creating impactful video displays.

Kramer Electronics KDS-DEC5 Features

  • Max. Data Rate - HDMI 4K at 30Hz (4:4:4) output
  • Standard AVC Support - H.264 & AAC codecs
  • Virtualization - RS-232 over IP
  • Network and IP Support - Standard Ethernet network operation 10/100/1000 Mb. Managed switch:1G, multicast, IGMP snooping, layer 2. Configurable DHCP, Static or Auto IP
  • Streaming and Session Control - Unicast, multicast and RTP over RTSP
  • Management and Control Options - Embedded web pages and API
  • Video Wall - Up to 256 screens (16x16)
  • Analog Audio Output
  • Power - PoE or external power supply (not included)
  • AVC Support - H.264/MPEG-4 & AAC codec
  • Open Encoding - Enables software decoding through VLC player software
  • Streaming Support - Multicast, Unicast, RTP over RTSP
  • Managed via open API
  • Powered by the network (PoE)
  • Video wall (16x16) support

Warranty Information

This product has a limited warranty of 84 months.

Key Features

  • Enjoy pristine video quality with the KDS-DEC5's 4K30 decoding capabilities.
  • Achieve reliable live streaming with H.264 compression for efficient broadcast.
  • Simplify setup using PoE (Power over Ethernet) for streamlined installations.
  • Utilize versatile video wall support for dynamic and engaging displays.
  • Ensure low latency streaming for real-time video applications and minimal delay.
  • Supports multiple formats, including HDMI, with stereo audio for immersive sound.

What's in the box:

  • Kramer Electronics KDS-DEC5 4K30 H.264 Video Decoder
  • 4x Rubber Feet
  • Bracket Set
  • Quick Start Guide
  • Kramer Electronics 7 Year Limited Warranty
