Kramer Electronics Kramer SP11D Multi-Format Video Processor and Converter
See all Kramer Electronics items

Kramer Electronics SP-11D Multi-Format Analog & Digital Video Processor/ProcAmp/TBC/Format & Standards Converter

SKU: KRSP11D

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Kramer Electronics SP-11D Specifications

  • CV Input/Output

    1Vpp/75 Ohm on BNC connectors

  • S-Video Input/Outputs

    1Vpp/75 Ohm (Y), 0.3Vpp/75 Ohm on 4-pin connectors

  • Component Input/Output

    Y/R-Y/B-Y (1Vpp/0.7Vpp/0.7Vpp)/75 Ohm (or RGB/S) on BNC connectors

  • SDI Input/output

    SMPTE-259M, ITUR BT.601 on BNC connectors

  • Genlock Input

    Looped 75 Ohm/Hi-Z on BNC connectors

  • Video Standards

    PAL-B/D/G/H/I/M/N, NTSC-3.58/4.43, SECAM

  • Digital Resolution

    10 bit

  • Video Bandwidth

    0.5dB to 5MHz

  • Signal To Noise Ratio

    60dB

  • K-factor

    0.40%

  • Diff. Gain

    1%Deg

  • Diff. Phase

    1%

  • Luma Non-linearity

    1%

  • Chroma/luma Delay

    <15ns

  • Memory

    Non-volatile memory for storage of 16 setups

  • Controls

    Front-panel and RS-232: Contrast, brightness, video gain, color, hue, H/V sharpness, SCH phase, delay, H/V shift; R, G, B, R-Y, B-Y level; screen splitter (process to bypass); freeze; panel lock

  • Power Source

    Universal, 100-240V AC, 50/60Hz

  • Max Power Consumption

    27VA

  • Dimensions

    19" 1U, rack-mountable

  • Weight

    2.6kg (5.7lbs) approx

  • Warranty

    Kramer 7 years limited warranty

About Kramer Electronics SP-11D

The Kramer SP-11D is a broadcast quality video processor that functions as a ProcAmp, TBC, format converter and standards converter for composite video, S-Video (Y/C), RGB/component video (YUV or RGBS) and SDI video signals. The original and processed image can be viewed simultaneously with the split screen output enabled.

Kramer Electronics SP-11D Features

  • Bandwidth - 5MHz (-0.5dB)
  • Multi-Format Capability - Selected input is simultaneously output as composite video, s-Video, component video (YUV or RGBS) and SDI
  • Multi-Standard - NTSC (3.58.4.43), PAL (B/D/G/H/I/M/N) & SECAM
  • Standards Conversion - Any input format and standard can be converted to any output format and standard
  • ProcAmp Control - Contrast, brightness, H/V sharpness, level/gain (R, G, B, R-Y & B-Y)
  • Time Base Corrector
  • Screen Splitter - Simultaneous display of original video and processed video on a single screen (adjustable)
  • Timing Control - Video delay, H/V delay & SCH phase
  • Switching Synchronization - Synchronize either to external reference or internal genlock sync generator
  • Looping Sync Input
  • Selectable Sync Signal Termination
  • Resolution - 10 bits
  • Memory Locations - Store 15 multiple switches as presets
  • Control - Front Panel and RS-232
  • Front Panel Lockout
  • Standard 19" Rack Mount Size - 1U

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Bandwidth - 5MHz (-0.5dB)
  • Time Base Corrector
  • Selectable Sync Signal Termination
  • Resolution - 10 bits
  • Control - Front Panel and RS-232
  • Front Panel Lockout

What's in the box:

  • Kramer SP-11D Multi-Format Analog & Digital Video Processor & Standards Converter
  • Power Cord
  • Null-Modem Adapter
  • Kramer 7 Years Limited Warranty
