32% Off

Kramer Electronics TP42 Component YUV Video and S/PDIF Audio Long-Range Receiver Over Network Cable

SKU: KRTP42 MFR: TP-42
$156.00
$230.00
Save: $74 (32%)
Earn VIP Reward Points

Key Features

  • Extend your video reach with this long-range YUV video and S/PDIF audio receiver.
  • Enjoy reliable signal transmission up to 1080i resolution over network cable.
  • Achieve optimal image quality with adjustable YUV level and equalization controls.
  • This durable video receiver offers low latency, ensuring seamless AV experiences.
  • Set up is a breeze! Quickly integrate this wireless video receiver into your system.
  • Experience crystal-clear audio with a high S/N ratio for superior sound quality.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$11.99

2 Year

$17.99

3 Year

$27.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Kramer Electronics TP42 Specifications

  • Input

    1x RJ-45 Twisted-pair network cable jack - female

  • Output

    1x S/PDIF digital audio RCA female
    3x Component video (1x Y, 1x U, 1x V) RCA female

  • Max Output Level

    Video: 2.1Vpp

  • Max. Resolution

    1080i

  • Diff. Gain

    0.15%

  • Diff. Phase

    0.68Deg

  • K-factor

    0.80%

  • S/N Ratio

    Video: 78dB; Audio: 78.4dB

  • Crosstalk (all Hostile)

    Video: -55dB; Audio: -50.5dB

  • Controls

    YUV level: -0.7dB to +0.8dB
    YUV equalization: 0 to +7.5dB
    S/PDIF level: -0.5dB to +1.2dB
    S/PDIF equalization: 0 to +7.8dB

  • Coupling

    DC

  • Power Input

    12 VDC 82mAh

  • Dimensions (W x D x H)

    4.7 x 3 x 1" (12 x 7.5 x 2.5 cm)

  • Weight

    0.7 lbs (0.3 kg)

About Kramer Electronics TP42

How the Kramer Electronics TP-42 Audio/Video Receiver revolutionizes your audio-video experience is truly remarkable. This high-quality and durable receiver is specifically designed for long-range extension and distribution of component video and digital audio. It's an efficient solution for those seeking to extend their studio, A/V, or presentation applications beyond the typical constraints of short cabling.

Working in harmony with a compatible transmitter, the TP-42 Receiver re-converts the video signal produced by a DVD player, computer A/V workstation, or similar devices. This process occurs after the signal has been transmitted over common network cables, ensuring reliable and high-quality audio and video transmission.

The TP-42 Receiver is not just a device; it's a user-friendly solution for those who require flexibility in their home theater or audio system setup. It's compatible with a wide range of devices, making it a versatile choice for users with diverse connectivity needs.

To revert the signal back from a standard YUV component video and S/PDIF audio signal at the other end of your wiring configuration, the Comprehensive/Kramer Electronics PT-41 is the perfect companion. The TP-42 Component YUV Video and S/PDIF Audio Long-Range Receiver Over Network Cable is your key to an enhanced audio-video experience.

Kramer Electronics TP42 Features

  • Individual level and EQ controls for the Y, U, V signals and audio level and EQ control
  • Power Connect System - Only one unit in a signal path, either the transmitter or receiver, needs to be connected to a power source. All the system units must have Power Connect circuitry to make use of this feature
  • With Power Connect System and heavy gauge CAT5 type cable, it can receive a video signal up to 320' (98 m.) Distances vary depending on signal resolution, device power, cable quality and type. Standard CAT5 cable can transmit up to 160' (50 m.)
  • Twisted pair output can utilize common and inexpensive unshielded RJ-45 network cabling such as CAT5
  • HDTV compatible

Warranty Information

This product has a limited warranty of 84 months.

Product Documents

User Manual

Key Features

  • Extend your video reach with this long-range YUV video and S/PDIF audio receiver.
  • Enjoy reliable signal transmission up to 1080i resolution over network cable.
  • Achieve optimal image quality with adjustable YUV level and equalization controls.
  • This durable video receiver offers low latency, ensuring seamless AV experiences.
  • Set up is a breeze! Quickly integrate this wireless video receiver into your system.
  • Experience crystal-clear audio with a high S/N ratio for superior sound quality.

What's in the box:

  • Kramer Electronics TP42 YUV Video and S/PDIF Audio Receiver
  • Power Adapter
  • Kramer Electronics 7 Year Limited Warranty
