Kramer Electronics VP-794 8-Input Universal Live Event Scaler/Switcher/Warp and Blend for Projection, LED Videowalls

Are you seeking an advanced, high-tech solution for your live event or broadcast needs The VP-794 8-Input Universal Live Event Scaler/Switcher/Warp and Blend for Projection, LED Videowalls is a sophisticated piece of equipment designed to deliver superior performance in large screen displays and multiple screen applications.

This user-friendly device is capable of up-scaling or down-scaling incoming signals, processing images with high-quality video (HQV) and flexible warping, and geometry correction. It also offers professional-grade edge blending and outputs signals to a wide range of connectors including 3G HD-SDI, DVI/HDMI, VGA, and S/PDIF.

The VP-794 is equipped with a special mode for driving LED video walls, providing pixel-accurate output image sizing. It supports a variety of lock modes, including Genlock (V-Lock), I/O lock, and frame rate conversion. This reliable device is HDTV compatible, HDCP compliant, and supports deep color up to 12 bit via HDMI.

Additional features include a USB port for firmware upgrades, selectable aspect ratio conversion, audio de-embedding from HDMI & 3G HS-SDI to S/PDIF compatible formats, and a built-in test pattern generator. It also includes a built-in time base corrector to stabilize unstable video sources and non-volatile memory to auto-save and recall settings.

The VP-794 offers powerful geometry correction for off-axis projection, pin/barrel, and image rotation, pan, tilt, and zoom. It also provides superior de-interlacing with motion adaptive per pixel video de-interlacing and multi-directional diagonal de-interlace filter to reduce HD & SD image flicker and artifacts.

This device is designed to support multiple formats, including 3G HD-SDI, HDMI, DVI, computer graphics, component, composite, and s-Video inputs for signals up to 1080p & WUXGA. It also offers flexible control options, including front panel buttons, jog wheel, and LCD menu display, RS-232, TCP/IP API, and Web Server, and a PC-based Warp Map Generator tool.

Whether you're managing live events, working in professional AV, broadcast, corporate AV, or overseeing premium fixed installs, the VP-794 8-Input Universal Live Event Scaler/Switcher/Warp and Blend for Projection, LED Videowalls offers the advanced features and reliable performance you need.
