Kramer Electronics VS-44DT 4x4 4K60 4:2:0 HDMI/HDBaseT Extended-Reach PoE Matrix Switcher

SKU: KRVS44DT110V MFR: 20-00044010
Earn VIP Reward Points

Key Features

  • Enhance your event rooms with the Kramer VS-44DT matrix switcher for seamless connectivity.
  • Extended-reach HDBaseT technology transmits 4K signals up to 328', perfect for large venues.
  • This 4x4 HDMI matrix supports resolutions up to 4Kx2K at 30Hz, ensuring crisp visuals.
  • Control your presentation effortlessly using IR, RS-232, or Ethernet with this KVM switch.
  • Enjoy reliable performance with a max data rate of 10.2Gbps, ideal for high-bandwidth needs.
  • Simplify setup in lecture halls using PoE, reducing cable clutter with this HDMI switch.
See More Product Details
Free Expedited Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$399.99

3 Year

$599.99

4 Year

$699.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Kramer Electronics VS-44DT Specifications

  • Applications

    Event rooms
    Large conference rooms
    Lecture halls

  • Inputs

    4x HDMI on HDMI connectors, 5x IR on 3.5mm mini jack connectors

  • Outputs

    2x HDMI connectors, 4x HDBaseT on RJ-45 connectors, 5x IR on 3.5mm mini jack connectors, 1x Unbalanced stereo audio on a 3.5mm mini jack connector

  • Ports

    1x Ethernet on an RJ-45 connector, 1x Program on a USB connector, 1x RS-232 control on a 3-pin terminal block, 1x RS-232 data on a 3-pin terminal block

  • Max. Data Rate

    10.2Gbps (3.4Gbps per graphic channel)

  • Supported Resolutions

    VGA to WUXGA (reduced blanking), 4Kx2K at 30Hz with Deep Color up to 36bpp

  • HDMI Range

    15m (49') at 8bit resolution, 10m (33') at 12 bit resolution

  • HDBaseT Range

    100m (328') 4K at 30Hz 180m (590') 1080 at 60Hz at 24bpp

  • Power Consumption

    100-240V AC, 50/60Hz, 60VA

  • Operating Temperature

    0 to 40 deg. C (32 to 104 deg. F)

  • Storage Temperature

    -40 to 70 deg. C (-40 to 158 deg. F)

  • Humidity

    10% to 90%, RHL non-condensing

  • Cooling

    Fan

  • Enclosure Type

    Aluminum chassis

  • Vibration

    ISTA 1A in carton (International Safe Transit Association)

  • Safety Regulatory Compliance

    CE

  • Environmental Regulatory Compliance

    Complies with appropriate requirements of RoHs and WEEE

  • Dimensions (WxDxH)

    43.6 x 35.30 x 4.36cm (17.17 x 13.90 x 1.72")

  • Weight

    7.3 lbs (3.31kg)

  • UPC Code

    7291063073671

About Kramer Electronics VS-44DT

With the advanced VS-44DT 4x4 4K60 4:2:0 HDMI/HDBaseT Extended-Reach PoE Matrix Switcher, experience seamless transmission of high-definition video, audio, Ethernet, RS-232, and IR signals over extended distances. This high-tech matrix switcher is designed to accept up to four HDMI and four IR inputs, along with Ethernet and RS-232 network and control.

The innovative routing feature allows these inputs to be directed to any or all of the four HDBaseT outputs, the first two of which also offer simultaneous HDMI outputs. The VS-44DT is compatible with HDBaseT receivers such as TP-780RXR, TP-580RXR, and TP-588D, ensuring versatile connectivity options.

Supporting resolutions of up to 4K at 60Hz (4:2:0) and WUXGA, this state-of-the-art switcher delivers crystal clear visuals. The HDBaseT range extends up to 130m (430') at normal mode (2K), and up to 100m at normal mode (4K). For ultra mode (1080p at 60Hz at 24bpp), the range can reach up to 180m (590') when using BC-UNIKAT cables.

As a PoE provider, the VS-44DT provides power over Ethernet to compatible PoE receivers, enhancing its functionality. The switcher also features EDID capture that copies and stores the EDID from a display device.

The VS-44DT supports 3D, Deep Color, x.v.Color, Lip Sync, Dolby TrueHD, Dolby Digital Plus, DTS-HD, and 7.1 PCM, ensuring a comprehensive HDMI support. It also features non-volatile memory that stores and recalls preset matrix configurations, and an automatic output shutdown if no input signal is detected after a configurable idle period.

To prevent unwanted tampering with the settings, a lock button is included. The switcher offers flexible control options, including an embedded web server, RS-232, and an IR remote. With a worldwide power supply of 100-240V AC, the VS-44DT 4x4 4K60 4:2:0 HDMI/HDBaseT Extended-Reach PoE Matrix Switcher is a sophisticated solution for professional AV installations.

Kramer Electronics VS-44DT Features

  • HDTV Compatible
  • HDCP Compliant
  • Kramer Protocol 3000 Support
  • 4K at 60Hz (4:2:0) HDMI/HDBaseT matrix switcher
  • Resolutions up to 4K at 60Hz (4:2:0)
  • Managed by Kramer Network

Warranty Information

This product has a limited warranty of 84 months.

Key Features

  • Enhance your event rooms with the Kramer VS-44DT matrix switcher for seamless connectivity.
  • Extended-reach HDBaseT technology transmits 4K signals up to 328', perfect for large venues.
  • This 4x4 HDMI matrix supports resolutions up to 4Kx2K at 30Hz, ensuring crisp visuals.
  • Control your presentation effortlessly using IR, RS-232, or Ethernet with this KVM switch.
  • Enjoy reliable performance with a max data rate of 10.2Gbps, ideal for high-bandwidth needs.
  • Simplify setup in lecture halls using PoE, reducing cable clutter with this HDMI switch.

What's in the box:

  • Kramer Electronics VS-44DT 4x4 4K60 4:2:0 HDMI/HDBaseT Extended-Reach PoE Matrix Switcher
  • Rack Ears
  • IR Blaster
  • IR Receiver RC-IR3 Remote Control Transmitter
  • Kramer Electronics 7 Year Limited Warranty
