Kramer Electronics VS-44FO 1RU 1x1 to 4x4 3G HD-SDI Over Fiber Optic Matrix Switcher, Up to 40km Range
SKU: KRVS44FO MFR: VS-44FO
$2,636.00
$3,295.00
Save: $659 (20%)OR
Key Features
- Seamless 3G HD-SDI matrix switching for professional video setups, up to 40km range.
- Effortlessly manage up to 4 fiber optic inputs and 4 outputs with this video switcher.
- Enjoy reliable connection via Ethernet, RS-232, and IR remote for flexible control options.
- Ensure high resolution video distribution with low latency, perfect for live events.
- This video switcher supports wide compatibility with genlock for synchronized feeds.
- Easy setup with included rack ears; this switcher offers good price & performance ratio.
Ships from Manufacturer?
Free Shipping
See Options
1
Protect your gear with Adorama Protect.* Learn more
2 Year
$119.99
3 Year
$159.99
4 Year
$191.99
Available to U.S. customers only.
Need help? Ask our experts.
Overview
Compare
Specs
Protection
Q&A
About Kramer Electronics VS-44FO
You can experience advanced video signal management with the VS-44FO 1RU 1x1 to 4x4 3G HD-SDI Over Fiber Optic Matrix Switcher. This state-of-the-art device is designed to switch and distribute high-definition 3G HD-SDI video signals over fiber optic cables, offering a sophisticated solution for your audio-visual needs.
The VS-44FO is not just a matrix switcher, but a high-tech tool that allows for flexible signal routing. It can switch any or all inputs to any or all outputs, providing you with the versatility to manage your video sources and displays as needed.
This innovative switcher supports long-distance transmission, with an impressive range of up to 40km. This makes it an ideal choice for large venues or outdoor events where a signal needs to be transmitted over a significant distance.
Furthermore, the VS-44FO is equipped with a variety of interfaces, including Ethernet, fiber, RS-232, USB, and wire terminals. This adaptability ensures that it can be seamlessly integrated into a multitude of systems and configurations.
In essence, the VS-44FO 1RU 1x1 to 4x4 3G HD-SDI Over Fiber Optic Matrix Switcher is a comprehensive solution for managing your high-definition video signals, offering both flexibility and range in a single, sophisticated device.
Kramer Electronics VS-44FO Features
- Max. Data Rate - 3Gbps
- HDTV Compatible
- Optional SFP Modules - Maximum of 4 can be installed. Minimum of 1 is required
- Genlock Looping Input
- Selectable Sync Signal Termination
- Automatic Reclocking and Equalization
- Active Input Reporting - Each input button on the front panel automatically lights up when the unit detects a video signal on that input. Red indicates a standard definition (SDI) input signal and blue indicates a high definition (HD-SDI) input signal
- Multiple Memory Locations - Stores multiple switches as presets (salvos) to be recalled and executed when needed
- Take Button - Executes multiple switches all at once
- Vertical Interval Switching - Compliant with SMPTE RP-168
- Range - 2-40km depending on SFP modules installed
- Built-in Black Burst Generator
- Compatible Transmitter & Receiver - 690T & 690R
- Flexible Control Options - Front panel, RS-232 (with K-Router Windows-based software), RS-485, Ethernet and IR remote (included)
- Worldwide Power Supply - 100-240V AC
- Standard 19" Rack Mount Size - 1U. Rack "ears" included
Warranty Information
This product has a limited warranty of 84 months.
