Kramer Electronics VS-88DT 8x8 HDMI to HDMI/HDBaseT Matrix Switcher

SKU: KRVS88DT MFR: VS-88DT
Earn VIP Reward Points

Key Features

  • Seamless HDMI matrix switching: Effortlessly route 8 HDMI sources to 8 displays.
  • Extend your reach with HDBaseT: Transmit high-resolution video over long distances reliably.
  • Enjoy low latency video distribution: Perfect for live events and real-time applications.
  • Control your video matrix easily: Use the web server, RS-232, or included IR remote.
  • Experience good compatibility: Supports 3D, Deep Color, and up to 7.1 channel audio.
  • Ensure reliable performance: Kramer's 7-year warranty guarantees peace of mind.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$229.99

3 Year

$274.99

4 Year

$369.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Kramer Electronics VS-88DT Specifications

  • Inputs

    8x HDMI, 9x infrared on 3.5mm mini jacks, 1x RS-232 on a 9-pin D-sub connector, 1x Ethernet on an RJ-45 connector, 1x program on a mini USB connector

  • Outputs

    8x HDMI, 8x HDBaseT on RJ-45 connectors, 9x infrared on 3.5mm mini jack connectors

  • HDMI Support

    3D, Deep Color, x.v.Color, Lip Sync, Dolby TrueHD, Dolby Digital Plus, DT-HD, and 7.1 multi-channel audio

  • Control Options

    Embedded web server, RS-232, IR remote (included), software application

  • Max. Data Rate

    6.75Gbps (2.25Gbps per graphic channel)

  • Audio Support

    Up to 7.1 channels at 192kHz

  • Power Consumption

    100-240V AC 50/60Hz 60VA

  • Operating Temperature

    0 to 40 deg. C (32 to 104 deg. F)

  • Storage Temperature

    -40 to 70 deg. C (-40 to 158 deg. F)

  • Humidity

    10% to 90%, RHL non-condensing

  • Dimensions (WxDxH)

    19 x 7.24 x 2" (48.26 x 18.39 x 5.08cm)

  • Weight

    1.6kg (3.53 lbs)

  • UPC Code

    7291063063948

About Kramer Electronics VS-88DT

While the VS-88DT 8x8 HDMI to HDMI/HDBaseT Matrix Switcher may seem like a simple piece of equipment, it is actually a sophisticated, high-tech device that offers advanced functionality. This state-of-the-art matrix switcher, manufactured by the reputable Kramer Electronics, is designed to seamlessly route up to eight HDMI and IR inputs to any or all of eight HDMI or HDBaseT and IR outputs. This innovative feature allows for flexible connection to compatible HDBaseT receivers such as the TP-580RXR.

Ideal for a variety of applications, the VS-88DT 8x8 HDMI to HDMI/HDBaseT Matrix Switcher is perfect for use in video conferencing, digital signage, and home theater systems. With its high number of outputs, this device stands out in the market, offering users the ability to switch between multiple HDMI inputs and output them to a single HDMI or HDMI/HDBaseT output.

Experience the convenience and superior performance of the VS-88DT 8x8 HDMI to HDMI/HDBaseT Matrix Switcher, a testament to Kramer Electronics' commitment to producing high-quality audio and video equipment.

Kramer Electronics VS-88DT Features

  • Max Data Rate - 675Gbps (225Gbps per graphic channel)
  • HDTV Compatible
  • HDCP Compliant
  • EDID Capture - Copies and stores the EDID from a display device
  • HDBaseT Range - Up to 130m (430') at normal mode (2K) when using BC-UNIKat cables
  • HDMI Support - 3D, Deep Color, xvColor, Lip Sync, Dolby TrueHD, Dolby Digital Plus, DTS-HD and 71 multi-channel audio
  • Non-Volatile Memory - Stores and recalls preset matrix configurations
  • Automatic Output Shutdown - If no input signal is detected after a configurable idle period
  • LCD Display - 2 lines/20 characters for easy configuration and operation
  • Kramer Protocol 3000 Support

Warranty Information

This product has a limited warranty of 84 months.

Key Features

  • Seamless HDMI matrix switching: Effortlessly route 8 HDMI sources to 8 displays.
  • Extend your reach with HDBaseT: Transmit high-resolution video over long distances reliably.
  • Enjoy low latency video distribution: Perfect for live events and real-time applications.
  • Control your video matrix easily: Use the web server, RS-232, or included IR remote.
  • Experience good compatibility: Supports 3D, Deep Color, and up to 7.1 channel audio.
  • Ensure reliable performance: Kramer's 7-year warranty guarantees peace of mind.

What's in the box:

  • Kramer Electronics VS-88DT 8x8 HDMI to HDMI/HDBaseT Matrix Switcher
  • Set of Rack Ears
  • IR Remote
  • Kramer Electronics 7 Year Limited Warranty
