Kramer Electronics VS-88UHD 8x8 4K60 4:2:0 Ultra HD Matrix Switcher
See all Kramer Electronics items

Kramer Electronics VS-88UHD 8x8 4K60 4:2:0 Ultra HD Matrix Switcher

SKU: KRVS88UHD
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Kramer Electronics MX-88: Picture 1 regular
Kramer Electronics Cobra MX-88 8x8 Twisted Switcher, Bk
$3,365.00
Kramer Electronics VP-553: Picture 1 regular
Kramer Electronics VP-553 Boardroom Presentation Switcher/Dual Scaler
$3,595.00
Kramer Electronics VP-732: Picture 1 regular
Kramer Electronics VP-732 1RU 10 Input ProScale Presentation Switcher
$3,675.00$3,175.20
Kramer Electronics VP-732: Picture 1 regular
Kramer Electronics VP-732 10-Input Presentation Switcher/Dual Scaler
$4,605.00$3,684.00
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Kramer Electronics VS-88UHD Specifications

  • Application

    Control rooms with multiple displays
    Presentation and multimedia applications
    Systems that require automatic HDMI routing

  • Inputs

    8 HDMI: On female HDMI connectors

  • Outputs

    8 HDMI: On female HDMI connectors

  • Ports

    1 Programming: On a Mini-USB connector
    1 RS-232: On a 3-pin terminal block connector
    1 Ethernet: On an RJ-45 connector
    1 USB: On a USB-type A connector for powering an external devic

  • Video

    Max. Resolutions: 4K@60Hz (4:2:0) and 4K@30Hz (4:4:4)
    Standards Compliance: HDMI 1.4 and HDCP 1.4

  • User Interface

    Indicators: Output/Input LED Display
    Control: Front panel buttons, RS-232, Ethernet remote connection

  • Power

    Source: 100-240V/50-60Hz
    Consumption: 600mA

  • Environmental Conditions

    Operating Temperature: 0 to +40 Degree C (32 to 104 Degree F)
    Storage Temperature: -40 to +70 Degree C (-40 to 158 Degree F)
    Humidity: 10% to 90%, RH (non-condensing)

  • Accessories

    Included: Rack ears, power cord

  • Dimensions

    19 x 9.34 x 1.7" (48.26 x 23.72 4.36cm)

  • Weight

    5.3 lb (2.4kg)

About Kramer Electronics VS-88UHD

VS-88UHD is a high-quality 8x8 matrix switcher for 4K@60Hz (4:2:0) HDMI signals and embedded audio. It reclocks and equalizes the signals and can route any one of eight HDMI, HDCP-compliant sources (selectable) to any or all outputs simultaneously. VS-88UHD offers a flexible audio scheme where any HDMI digital audio input can be routed to any HDMI digital audio output in addition to ARC support to produce an equivalent 16x12 audio matrix.

Kramer Electronics VS-88UHD Features

  • Max. Data Rate - 8.91Gbps data rate (2.97Gbps per graphics channel)
  • Max. Resolution - 4K@60Hz (4:2:0)
  • Independent 16x12 Audio Matrix - With 8 embedded digital inputs + 8 ARC inputs and 8 digital outputs + 4 ARC outputs
  • Kramer Step-In Over HDMI Technology
  • HDMI, HDCP and DVI Compliance
  • Selectable HDCP Off per Input
  • Memory Locations - 16 presets for quick access to common configurations
  • Advanced EDID Management per Input
  • Active Source & Acceptor Detection
  • Automatic Input Selection - Based on priority selection or last connected input
  • HDMI Support - Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels
  • Kramer reKlocking and Equalization Technology - Rebuilds the digital signal to travel longer distances
  • Embedded Pattern Generator - With selectable patterns
  • Lock Button - To prevent tampering
  • Kramer Protocol 3000 Support
  • Firmware Upgrade - Via mini USB, Ethernet or the RS-232 port
  • Control Options - RS-232 serial commands transmitted by a PC, touch screen system or other serial controller, Ethernet port via LAN, embedded Web pages via LAN for configuration and control
  • Size - Standard 19" (1U) Rack "ears" included

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Max. Data Rate - 8.91Gbps data rate (2.97Gbps per graphics channel)
  • Max. Resolution - 4K@60Hz (4:2:0)
  • Kramer Step-In Over HDMI Technology
  • HDMI, HDCP and DVI Compliance
  • Selectable HDCP Off per Input
  • Memory Locations - 16 presets for quick access to common configurations

What's in the box:

  • VS-88UHD 8x8 4K60 4:2:0 Ultra HD Matrix Switcher
  • Kramer 7 Year Limited Warranty
