Kenwood NEXEDGE NX-240 VHF Digital & FM Two Way Radio, 16 Channel Per Zone, 5W RF Power Output

Your business will have to adopt digital radios sooner or later, you know that, but you probably wonder when to make the extra investment. A leap into the unknown? Not with the new NEXEDGE NX-240. It operates in both analog FM and NXDN digital modes, offering a cost-effective way to migrate smoothly from legacy systems while discovering the benefits of advanced digital technology - including increased effective coverage area, low noise for superior clarity and inherent secured voice. All this comes in a tough, compact radio that is easy to operate, delivers high-powered audio and ensures round-the-clock reliability. Don't delay the opportunity to expand the potential of your business.

Digital
• Over-The-Air Alias (TX only)
• Paging Call
• Individual Call & Conference Group Call
• Status Messaging
• Remote Monitor
• Site Roaming
• Late Entry
• NXDN ESN

Analog
• Fleet Sync, MDC-1200, DTMF
• QT/DQT/2-tone
• Compander
• Squelch Level

General
• Multiple Scan
• 4-Color LED (Blue / Red / Green / Orange)
• 2 PF Keys
• 16-Position Mechanical Selector
• Zone / Channel Number Voice Announcement
• VOX Ready
• Emergency Call
• Remote Stun/Kill
• Lone Worker Alert (per channel)
• Time Out Timer
• Busy Channel Lockout
• Low Battery Warning
• Battery Saver
• KPG-169D Windows FPU
• Wireless Cloning
• Password Protection
• PTT Release Tone
• Minimum Volume
• Mic Sense
• MIL-STD-810 C/D/E/F/G
• IP54/55 Water & Dust Intrusion

NXDN Digital Air Interface
NEXEDGE radios employ NXDN, an FDMA digital air interface with AMBE+2 voice coding technology, unique filtering and a 4-level FSK modulation technique with low bit error rate (BER) even at weak RF signal strengths.

Enhanced Audio Quality
AMBE+2 VOCODER technology accurately replicates natural human speech nuances for superior voice quality, even at highway speeds. Additionally, the powerful 36mm-diameter speaker delivers up to 1 watt audio output, providing undeniably clearer and crisper audio.

Ultimate Performance
RF output power is 5W VHF (NX-240)

Ergonomic Design
The slim contours and ergonomic design of the NX-240 make it comfortable to hold, while the dimples on both sides ensure a firm grip.

32 Channels/2 Zone
The NX-240 can be used with two conventional zones, offering up to 16 channels per zone.

Switchable Digital and Audio Dual Mode
The NX-240 is effectively two radios in one - analog and digital - operating on 12.5/25kHz in analog zones and on 6.25/12.5kHz NXDN in digital zones. For convenience, a PF key can be used to switch between zones.

6.25/12.5kHz NXDN Digital Channel
Digital communications are more spectrum-efficient and offer wider area coverage than analog.

NXDN Conventional
Compatible with NEXEDGE Digital Conventional Mode, this radio offers 64 RAN (Radio Access Numbers) and individual & conference group calling to ensure expeditious communications.

High Security
Confidentiality in radio communications is a KENWOOD priority and helping to maintain a high level of security in analog mode is a 16-code voice inversion scrambler, while robust NXDN encryption is available in digital mode.

GPS Connectivity
The optional KMC-48GPS Speaker Microphone will enable GPS tracking applications to work with the NX-240. GPS data can be transmitted at programmed timing or upon receiving a request.
