Lensbaby Mirrorless 16mm Pin Hole Pancake Lens for Micro MFT

SKU: LBO16M

This item is no longer available.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

FAQ

What makes the Lensbaby Obscura 16mm Pin Hole Pancake Lens unique?

The Lensbaby Obscura 16mm Pin Hole Pancake Lens is unique due to its ability to produce dreamy, vintage-style images with artistic flares and artifacts. It features three imaging options: Pinhole, Zone Plate, and Pinhole Sieve, giving photographers a high level of creative control.

What cameras is this lens compatible with?

This lens is specifically designed for use with Micro Four Thirds mirrorless cameras, offering a wide-angle perspective ideal for capturing expansive landscapes and intricate cityscapes.

How is the lens constructed?

The Obscura's imaging elements are made up of three layers of chrome with a total thickness of 0.00014mm deposited on 1.5mm thick glass before an anti-reflective coating is applied. This advanced photolithography process ensures superior light transmission, perfectly round pinholes, and precision-crafted zone plate zones.

Can the lens be cleaned like any other camera lens?

Yes, the Obscura's glass can be cleaned with the same care as any camera lens, without the risk of damaging any of the three imaging options.

What kind of images can I create with the Lensbaby Obscura 16mm Pin Hole Pancake Lens?

The Lensbaby Obscura lens allows you to create images with a unique, artistic effect. It produces a soft, dreamy quality to the images it captures, often used to create a vintage or retro look. By adjusting contrast and enhancing vibrance or saturation, images captured with the zone plate or pinhole sieve come alive with vivid detail.

Reviews about this item

Review Summary

2022-12-14T05:26:41

Rated 5 out of 5

Opening a Door to Imagination and Creativity

From the minute I put it on my camera, this fabulous lens has been encouraging playfulness and imagination, and the images it has helped me create have almost invariably made me smile. They have also elicited oohs and aahs from my friends and followers on social media. If you are already experimenting with using photographic images to create digital art, you should take to this lens quickly. If you haven?t been doing that, it may take a little time to reorient how you approach using the camera. But this lens may ultimately open that creative door for you.

THOMAS Y.

2021-12-08T10:18:18

Rated 5 out of 5

Fun and Well Built ?Pinhole? lens

It?s an interesting ?lens.? The only LensBaby I?d get. Fun to try different things with it vs. ?regular? lenses. Fun to use.

Maurice H.

2021-09-03T16:32:45

Rated 4 out of 5

Takes practice, but a lot of fun and potential

This lens produces a unique view, and it will take me much more practice before I get good enough at it to really know how to rate it. It is a lot of fun, regardless! There are 3 main "aperture" settings on this lens, but as far as I can tell, one of them produces totally muddy pictures that don't appeal to me. The other 2 settings let me get enough focus to be meaningful, so i end up using those for the most part. But again, I need to play with it more to be really sure. This was MUCH better than a different pinhole lens I purchased, and if you are interested in pinhole photography, I think this lens is a real winner.

Robert J.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Lensbaby Obscura 16mm Pancake Lens Specifications

  • Compatibility

    Micro 4/3

  • Focal Length

    16mm

  • Primary Effect

    Zone Plate; Pinhole Sieve; Pinhole

  • Optic Swap Compatible

    No

  • Aperture: Zone Plate

    f/22; Pinhole Sieve: f/45; Pinhole: f/90

  • Minimum Focusing Distance

    Zone Plate: 0.6m (23in.); Pinhole Sieve: 0.3m (12in.); Pinhole: 0.05m (2in.)

  • Format Compatibility

    35mm Full Frame; APS-C; and 4/3rds Sensors

  • Camera Compatibility

    MIL cameras

  • Focus Type

    Fixed

  • Diagonal Angle of View

    Full Frame: 107 Degree ; APS-C (1.5x): 83 Degree ; 4/3rds: 68 Degree

  • Diaphragm Blades

    None

  • Elements/Groups

    Zone Plate: 29 Zones / Pinhole Sieve: 203 pinholes / Pinhole: 1 pinhole

  • Coating

    Chrome aperture on broadband multi coated, anti-reflective glass

  • Dimensions

    2.88 x 0.90" (73.1 x 22.85mm) Micro 4/3rds
    Length with caps: 1.24" (31.45mm) Micro 4/3rds

  • Weight

    0.333 lbs (0.152kg)

8 Accessories for Lensbaby Mirrorless 16mm Pin Hole Pancake Lens for Micro MFT

  • All Accessories (8)
  • Tripods & Monopods (2)
  • Bags & Cases (4)
  • Cleaning Accessories (1)
  • Rain Covers (1)

About Lensbaby Obscura 16mm Pancake Lens

The Lensbaby Obscura redefines the essence of photography, offering a distinctive and innovative experience that harks back to the very roots of image capture. This high-quality mirrorless 16mm Pin Hole Pancake Lens for Micro MFT is not just a tool but an invitation to photographers and visual artists who are eager to explore the boundaries of their creativity. Those who are drawn to the Obscura are individuals who appreciate the beauty of simplicity and are ready to push the limits of what constitutes photographic art.

Crafted with a stylish and durable design, the Lensbaby Obscura stands out with its ability to produce unique flares and image artifacts that are unattainable with standard camera lenses. The dance between light and shadow is elegantly orchestrated, allowing photographers to capture images with a dreamy, vintage appeal. The Obscura's versatility is showcased in its three distinct versions: a 50mm Pinhole/Zone Plate/Pinhole Sieve optic for the Optic Swap System, a standalone 50mm version, and the featured standalone 16mm Pinhole/Zone Plate/Pinhole Sieve pancake lens, specifically designed for mirrorless cameras with a Micro Four Thirds system.

Unlike traditional pinholes that are fragile and prone to damage, the Obscura's imaging elements are exceptionally durable. They consist of three layers of chrome, each with a thickness of 0.00014mm, meticulously deposited onto a 1.5mm thick glass substrate before an anti-reflective coating is applied. This advanced photolithography process achieves a remarkable resolution of 128K dpi, ensuring true zone plates with superior light transmission, perfectly round pinholes, and precision-crafted zone plate zones.

The Obscura's glass can be cleaned with the same care as any camera lens, without the risk of damaging any of the three imaging options. The zone plate and pinhole sieve options offer a higher level of detail compared to the traditional pinhole, enveloped in a characteristic glow. By adjusting contrast and enhancing vibrance or saturation, images captured with the zone plate or pinhole sieve come alive with vivid detail. The zone plate features a curved field of focus that creates a sweet spot of sharpness, while the pinhole and pinhole sieve deliver consistent resolving power from the center to the corners of the image.

For photographers seeking a versatile, high-quality lens that provides a wide-angle perspective and the ability to create artistic, soft-focused images, the Lensbaby Obscura 16mm Pin Hole Pancake Lens for Micro MFT is an exceptional choice. It is the perfect companion for capturing expansive landscapes, intricate cityscapes, and other scenes where a wide field of view is desired, all while adding a touch of nostalgic charm to your photography.

Lensbaby Obscura 16mm Pancake Lens Features

  • A pinhole is not, technically, a lens but is a clear, round hole in a thin piece of material, usually metal
  • A pinhole sieve is a field of pinholes with the center pinhole being the largest and increasingly smaller pinholes radiating away from the center
  • A zone plate is a series of clear circular rings surrounding a center hole with each of the clear zones equaling the area of the pinhole in the center resulting in increasingly thinner zones as you move away from the center of the zone plate
  • Anti-reflective glass

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Unique 16mm Pin Hole Pancake Lens for artistic, vintage-style photography
  • Compatible with Micro Four Thirds mirrorless cameras for wide-angle shots
  • Durable, high-resolution photolithography process with anti-reflective coating
  • Three imaging options: Pinhole, Zone Plate, and Pinhole Sieve for creative control
  • Easy-to-clean glass that withstands regular maintenance without damage
  • Curved field of focus with zone plate for sharp central imagery and dreamy periphery

What's in the box:

  • Lensbaby Mirrorless 16mm Pin Hole Pancake Lens
  • Lensbaby 1 Year Limited Warranty
