About Leader LT450
After meticulous engineering, the LT450 Multiformat Pattern Generator emerges as a sophisticated and advanced tool, essential for professionals in the video production industry. This high-tech instrument is compatible with Digital Television (DTV) and boasts a comprehensive suite of outputs, including analog component, composite, and digital (HDMI), catering to a broad spectrum of video testing needs.
The LT450 stands out with its professional-grade features, such as the ability to set component outputs to either RGB or Y, Pb, Pr, providing users with the flexibility to match their specific testing requirements. The on/off control of each channel further enhances its versatility, allowing for precise signal customization.
In addition to its core capabilities, the LT450 offers separate composite and sync outputs, ensuring compatibility with a wide array of equipment. The inclusion of individual level controls for sync and video signals is a testament to the generator's innovative design, offering invaluable assistance to technicians testing for sync sensitivity and other critical video parameters.
The LT450 is not just a pattern generator; it is a comprehensive solution for generating a variety of essential test patterns. Users can select from popular patterns such as monoscope, color bar, ramp, crosshatch, multiburst, and character. Each pattern can be modified with variations like on/off control of RGB, signal inversion, and aspect ratio changes, making the LT450 a truly adaptable device for any testing scenario.
For those seeking even more functionality, the LT450 can be customized with additional outputs such as DVI-I and HDMI, along with analog options like a SCART connector, ensuring that it meets the evolving demands of the industry.
Choose the Leader LT450 Multiformat Pattern Generator for its user-friendly interface and its wide range of innovative features. It is the ideal choice for professionals who require a reliable, versatile, and high-quality pattern generator from a brand synonymous with excellence in video production technology.
Leader LT450 Features
- With the formats available on the LT 450, you can test most video displays, including television sets, PC monitors, and projectors. The LT 450 supports19 component output formats, 8 composite output formats, and 5 PC monitor formats
- The LT 450 is equipped with an HDMI connector, which is a digital interface used in household televisions and set-top boxes. It can be used to check HDCP compliant copyright protection functions and to make simple checks on the CEC and DDC functions (pass/fail results can be displayed on screen)
- Simple checks can be made simultaneously on up to seven outputs (when option units are installed)
- Analog and digital component outputs can be switched between G, B, R and Y, PB, PR signal formats
- Equipped with an S connector for Y/C separation signal output. An ID signal is superimposed on the C signal
- Equipped with a JEITA CP-4120 D5 output. Supports ID signals (lines 1, 2, and 3)
- Equipped with a mini D-sub 15-pin connector, which is an analog interface for PC monitors
- Equipped with a DVI-I connector, which is a digital interface for PC monitors. It can be used to check HDCP-compliant copyright protection functions and to make simple checks on the DDC function
- Equipped with sync signal connectors that transmit CS (trilevel or binary), HD, and VD signals. Analog audio output
- The frequency (400Hz or 1kHz) can be set and the output can be turned off separately for left and right channels
- You can make any test pattern into a simple motion picture pattern by scrolling it vertically, horizontally, or diagonally
- The video signal level and the analog sync signal level can be adjusted separately in the range of 0 to 100%
- Supports closed captions. Teletext (VBI), CGMS, and WSS will be supported in the future
- Remote control via RS232C
- The LT 450 can be remotely controlled from a PC
- Up to 100 panel settings can be stored and re-called
