Link Electronics DigiFlex 1650 Audio Distribution Amplifier with 1014 Rear Cell, Terminal Block Connection, 1x8 Mono or 1x4 Stereo Outputs

SKU: LE16501014 MFR: 1650/1014
Earn VIP Reward Points

Key Features

  • Distribute audio signals flawlessly with this Link Electronics distribution amplifier.
  • Achieve pristine sound quality with >100dB S/N ratio, perfect for critical listening.
  • Easily manage audio levels with resistive trim, optimizing your sound distribution setup.
  • This audio distribution amplifier supports both mono (1x8) and stereo (1x4) configurations.
  • Experience minimal distortion (<0.01% THD) for clear, professional-grade audio output.
  • Ensure reliable audio signal splitting with impedance of 66Ohms on each output channel.
See More Product Details
Special Order?Estimated to Ship: 08/15/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$39.99

2 Year

$69.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Link Electronics DigiFlex 1650 Specifications

  • Input Channels

    1

  • Input: Impedance

    20KOhms, +/-2% Balanced

  • Input: Max. Level

    20 dBu, Differential

  • Input: Common Mode Range

    +/-10 Volts

  • Input: Common Mode Rejection

    >85 dB at 60Hz

  • Output: Channels

    2

  • Output: Impedance

    66Ohms

  • Output: Max. Level

    Load = 4 x 150Ohms

  • Output: Number of Outputs per Channel

    4x

  • Gain Range

    -inf to +8DB

  • S/N Ratio

    >100dB A WTD +8dBu 0 Gain

  • Frequency Response

    +/-0.2dB, 20Hz to 20KHz

  • Total Harmonic Distortion

    <0.01% +8dBu 0 Gain
    Load = 4 x 150Ohms

  • Crosstalk

    90dB, 20Hz to 20KHz

  • DC Offset

    <10mV

  • Quiescent Drain Current

    +/-100mA

  • Monitor Switch

    Places signal on Frame Buss

  • Temperature Range

    0 to 50 deg. C / 32 to 122 deg. F

  • Internal Adjustments

    Audio Level: Resistive Trim
    Common Mode Adjustment: Resistive Trim

  • Dimensions (H x W x L)

    3.2 x 1 x 10" / 8.13 x 2.54 x 25.40cm

  • Weight

    8oz / 226.80g

About Link Electronics DigiFlex 1650

Link's DigiFlex 1650/1651 Stereo Audio Distribution Amplifier takes advantage of the latest in Operational Amplifier technology. The front end is high-impedance, balanced, with high common mode rejection. The output amplifier is capable of driving low impedance (150Ohm) loads and is compensated for load capacitance of up to 10,000pF. Its wide bandwidth (>120KHz) will allow for the distribution of SMPTE Time Code or BTSC Baseband Stereo. Ultra low-noise components (including metal-oxide resistors) are used throughout the audio signal path.

Both the input buffer and output driver offer noise figures of <7nV/Hz1/2. In addition, extreme care has been taken in the printed circuit board design to reduce noise and improve channel isolation. The 1650 and 1651 are identical with one exception: the 1651 has logarithmic bar graph level meters for the left and right channel signal indication. The Link 1650/1651 has a unique signal presence indicator on the rear panel. The rear panel module with build-out resistors and fixed terminal blocks is the model 1014. Plug-in terminal blocks are available on the 1021 Rear Cell. The front panel features a DC power supply monitor LED.

The Link 1650/1651 is designed to reside in Link's DigiFlex 1000 frame. This rugged 2RU frame can house up to 11 modules. An audio buss runs the full length of the frame to allow monitoring of any of the resident audio distribution amplifiers by a single monitoring amplifier, model 1626. A switch on the front of the module places the audio signal on the frame buss. The versatile DigiFlex 1000 frame can also accommodate AES/EBU Digital Audio distribution (using the DigiFlex 1652) as well as Analog and Digital Video distribution. Backed by Link's 10-year warranty, the 1650/651 will provide years of outstanding performance.

Link Electronics DigiFlex 1650 Features

  • Low Noise
  • Eight Mono Outputs or
  • Four Stereo Outputs
  • Signal Presence LED
  • 11 Modules per Frame
  • >100dB S/N Ratio
  • A/B Buss Monitoring

Warranty Information

This product has a limited warranty of 120 months.

Key Features

  • Distribute audio signals flawlessly with this Link Electronics distribution amplifier.
  • Achieve pristine sound quality with >100dB S/N ratio, perfect for critical listening.
  • Easily manage audio levels with resistive trim, optimizing your sound distribution setup.
  • This audio distribution amplifier supports both mono (1x8) and stereo (1x4) configurations.
  • Experience minimal distortion (<0.01% THD) for clear, professional-grade audio output.
  • Ensure reliable audio signal splitting with impedance of 66Ohms on each output channel.

What's in the box:

  • Link ELectronics DigiFlex 1650 1x8 Mono or 1x4 Stereo Audio Distribution Amplifier
  • Rack Card
  • 1014 Rear Cell
  • Link Electronics 10 Year Limited Warranty
