About Link Electronics CP804B

Oversee your audio and video operations with precision and ease using the 8x4 X-Y AFV Control Panel with Audio/Video Breakaway Buttons. This 1RU unit is versatile, capable of functioning as either a local or remote control panel, depending on your specific needs.

For remote control operations, pair it with the optional CR100 cradle assembly. This assembly comes equipped with a built-in 115V/230V input power supply and an Ethernet interface for seamless connectivity.

The control panel is designed for easy installation on a coax-based 10Base2 Ethernet network, supporting up to 32 panels and a total cable length of 300 feet. If your setup requires longer distances or more panels, you can effortlessly expand the panel network to 256 panels using standard Ethernet LAN 'Hub' units.

Operating the X-Y panel is straightforward. Begin by selecting your desired destination (output). Once the output is selected, the source (input) buttons will tally, allowing you to choose the desired input for that destination. Locked outputs are conveniently indicated by the output lamp flashing when a locked output is selected.

The CP804A and CP804B panels, as depicted, utilize a common set of switches for both audio and video (AFV) operations. This type of panel is ideal when AFV is the standard mode of operation.

These 1RU panels, the CP804A and CP804B, can also function as remote control panels for the router when combined with the optional CR100 cradle assembly. Enhance your audio and video control with the 8x4 X-Y AFV Control Panel with Audio/Video Breakaway Buttons.

Link Electronics CP804B Features

  • Versatile 8x4 X-Y AFV Control Panel with Audio/Video Breakaway Buttons for precision control
  • Can be used as either local or remote control panel, offering flexibility in operation
  • Supports easy installation on a coax-based 10Base2 Ethernet network
  • Capable of expanding to support up to 256 panels with standard Ethernet LAN 'Hub' units
  • Straightforward operation with clear indication of locked outputs
  • CP804A and CP804B panels feature common set of switches for both audio and video operations

Warranty Information

This product has a limited warranty of 120 months.
