Lumens Media Processor LC200 CaptureVision Station with 2x VC-A61P 4K UHD IP PTZ Cameras, White

SKU: LMLC200B61PW MFR: LC200BUNDLE61PW
Earn VIP Reward Points

Key Features

  • Create engaging live streams with dual 4K UHD IP PTZ cameras for superior video quality.
  • Enjoy versatile compatibility; this station supports HDMI, Ethernet, and more for easy integration.
  • Experience reliable connectivity with stable streaming protocols like RTSP, RTMP, and MPEG-TS.
  • User-friendly interface ensures easy setup and operation, perfect for both beginners and pros.
  • Record and store up to 1TB of high-quality video, with external storage options via USB 3.0.
  • Mix multiple video sources with PIP and PBP layouts for dynamic and professional productions.
See More Product Details
Special Order?Estimated to Ship: 08/20/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$189.99

3 Year

$219.99

4 Year

$279.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Lumens LC200 Specifications

LC200: Video Input

LC200: Video Input

Jump to...
  • Number/signal

    4 HDMI digital video

  • Connection

    4 female HDMI type-A

  • Resolution Range

    480i-1080p 60fps

LC200: Video Processing

Jump to...
  • Video Compression

    H.264/AVC 4:2:0 8bit color

    Encoding profile: High, Main, Baseline

  • Bitrate

    200 kbps to 10 Mbps

LC200: Video Output

Jump to...
  • Number/Signal

    3 H.264/AVC digital video over Ethernet
    2 HDMI digital video

  • Scaled Resolution

    1080p

  • Frame Rate

    30 / 60 fps

LC200: Recording and Storage

Jump to...
  • Internal Storage

    1TB HDD

  • External Storage

    1 USB 3.0 port in front panel

  • File Type

    H.264 and AAC in an MP4 container, JPEG

  • Resolution

    480p, 720p, 1080p

  • Frame Rate Max.

    1080p 60/30 fps

LC200: Audio Input

Jump to...
  • Number/signal

    4 Line In/MIC In (stereo, 3.5mm phone jack)
    4 stereo, digital de-embedded audio from HDMI

LC200: Audio Processing

Jump to...
  • Compression

    AAC-LC

LC200: Audio Output

Jump to...
  • Number/Signal

    1 stereo, unbalanced 3.5mm phone jack
    2 stereo, digital de-embedded audio from HDMI

LC200: Communication

Jump to...
  • USB

    2 rear panel USB 2.0 type A
    Supports USB mouse, keyboard

  • Serial Control

    RS-232 /RS-485 port

LC200: Ethernet

Jump to...
  • Ethernet host port

    1 female RJ-45
    10/100/1000 Base-T high/full duplex

  • Streaming Protocol

    Pull: RTSP
    Push: RTMP / RTMPS / MPEG-TS
    TCP, UDP, HTTP DHCP Client

LC200: Functions

Jump to...
  • Scenes switch

    Yes, preset for layout, background, and overlay

  • Layout switch

    Yes,( Single, PIP, PBP, 3 and 4 windows layouts)

  • Background switch

    Yes

  • Overlay

    Yes

  • File backup

    FTP / Copy to USB Flash Drive

LC200 CaptureVision Station

Jump to...
  • Power supply

    DC In , 12V / 2A

LC200: General

Jump to...
  • Power consumption

    24W

  • Dimensions (L x W x H)

    4.82 x 16.9 x 1.74" (122.5 x 431 x 44.3mm) Standard 1u rack

  • Weight

    2.64 lbs (1.2Kg)

VC-A61P 4K UHD IP PTZ Camera

Jump to...
  • Color

    White

  • Sensor

    1/2.5" 8MP CMOS

  • Video Format

    Resolution: 4K/1080p/720p
    Frame Rate : 59.94/50/29.97/25

  • Video Output (HD) Interface

    3G-SDI, HDMI, Ethernet

  • Optical Zoom

    30x

  • Horizontal Viewing Angle

    68 Degree

  • Panning Angle

    +170 Degree - -170 Degree

  • Panning Speed

    300 Degree /sec

  • Tilting Angle

    +90 - -30 Degree

  • Tilting Speed

    300 Degree /sec

  • Aperture

    F1.6 - F3.4

  • Focal Length

    4.6mm - 135mm

  • Shutter Speed

    1/1 - 1/10,000 sec

  • Minimum Object Distance

    1.5m (Wide/Tele)

  • Video S/N Ratio

    > 50dB

  • Minimum Illumination

    0.1 lux (F1.6, 50IRE, 30fps)

  • Focus System

    Auto, Manual

  • Gain Control

    Auto, manual

  • White Balance

    Auto, manual

  • Exposure Control

    Auto, manual

  • WDR

    Yes

  • 3D NR

    Yes

  • Image Flip

    Yes

  • Preset Positions

    256

  • Multiple Video Stream

    H.265 4K 30fps
    H.264 1080p 60fps
    H.264 640x360 30fps

  • Audio Compression Format

    G.711 / AAC

  • Camera Control Interface

    RS-232 / RS-422 / Ethernet

  • Camera Control Protocol

    VISCA / PELCO D / ONVIF

  • Tally Light

    Yes

  • PoE

    PoE+ (IEEE802.3at)

  • Video Stream

    RTSP / RTMP / MPEG-TS / SRT

  • Video Compression

    H.265 / H.264

  • Audio Input

    Line In/MIC In , Phone Jack 3.5mm x1

  • Audio Output

    Ethernet / SDI / HDMI

  • IR pass-through

    Yes

  • IR receiver

    Yes

  • IR remote control

    Yes

  • DC In

    12V +/- 20%

  • Power consumption

    16W

  • Dimensions

    6.9 x 7.3 x 7.3" (174 x 186 x 187mm)

  • Weight

    4.4 lbs (2kg)

About Lumens LC200

How can you elevate your video conferencing and live streaming experience The answer lies in the sleek and modern Media Processor LC200 CaptureVision Station, complete with 2x VC-A61P 4K UHD IP PTZ Cameras. This high-tech, sophisticated system is designed by Lumens, a reputable brand known for its superior audio and video equipment.

The LC200 CaptureVision is a 4-in-1 media processor that supports recording, switching, mixing, and live streaming at 1080p. This stand-alone device allows you to mix four video sources, record, stream, and live-switch simultaneously, making it the perfect core system for your video project.

The LC200 supports Full HD 1080p video and audio recording, delivering high-definition images and crystal-clear audio. It's ideal for lecture capture, conference recording, and event streaming. The system supports popular streaming platforms and content management systems such as YouTube, Facebook, Kaltura, and Panopto.

The LC200 can capture up to 4 video sources through multiple inputs, including HDMI inputs, Lumens IP cameras, NDI|HX cameras, and RTSP streams. It also features four line-in/MIC-in inputs, providing a complete audiovisual experience for your viewers. The programmed video can be directly displayed on an HDMI display without any intermediary device.

The user-friendly Multi-View director and advanced Scenes Switching function allow users to control their recording and streaming content. With just one click, you can roll out user-defined scenes that contain PBP PIP layout, title/logo overlays, and pleasing background, generating a professional video while streaming.

The LC200 comes with a built-in 1TB hard drive that can store up to 500 hours of video. You also have options to upload your recordings to an external USB device or the FTP server.

The Lumens VC-A61P UHD Pan/Tilt/Zoom (PTZ) IP camera is equipped with a professional 1/2.5" image sensor with 4K Ultra HD output at 30fps. The power is supplied through 12V input or the Power over Ethernet (PoE+), providing an economical and easy solution. The superior 30x optical zoom lens, excellent white balance, and exposure mode deliver a clear image even in low light or extreme contrast of brightness and darkness in a room.

The VC-A61P has different interfaces such as Ethernet, HDMI, and 3G-SDI. It supports live broadcasting with H.264/H.265 format. These features not only allow for simultaneous image outputs, but they also result in the best image quality and are compatible with all types of video equipment. The camera covers a wide shooting angle and achieves high-speed, quiet, and precise positioning with smooth PTZ operations.

With its 4K UHD ultra-clear video quality, you can enjoy detailed, crystal-clear views even in low light. The VC-A61P comes equipped with HDMI, 3G-SDI, and Ethernet multiple output interfaces that can ease your installation. With triple stream technology, the VC-A61P provides H.265/H.264 multiple streams that are tailored for your network environment.

In conclusion, the Media Processor LC200 CaptureVision Station with 2x VC-A61P 4K UHD IP PTZ Cameras is a stylish and high-tech solution for your video conferencing and live streaming needs.

Lumens LC200 Features

  • LC200 CaptureVision Station Features
  • Supports 1080p 60/30fps recording
  • Supports 4 HDMI Inputs and IP video sources including Lumens IP Cameras, NDI|HX Camera, and standard RTSP streams
  • Supports HDMI-embedded audio or analog stereo audio with 4 channels Audio Input mixing and gain control
  • Flexible scaling and window processing, supports PIP, PBP and up to 4 windows layout and mixing
  • Advanced Scenes Switch
  • Built-in 1TB HDD storage
  • VC-A61P 4K UHD IP PTZ Camera Features
  • 4K UHD 30fps and 1080P 60fps video signal output format
  • 30x optical zoom, 68 degrees Horizontal Field of View
  • Triple stream video, output format H.264 / H.265
  • Supports PoE (Power over Ethernet) using network cables to supply power
  • Ethernet, HDMI and 3G-SDI synchronous image outputs
  • Audio input supports AAC / G.711 encoding with 44.1K / 48K sampling frequency
  • Free Lumens VMS software for controlling the cameras remotely from a local area network

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Create engaging live streams with dual 4K UHD IP PTZ cameras for superior video quality.
  • Enjoy versatile compatibility; this station supports HDMI, Ethernet, and more for easy integration.
  • Experience reliable connectivity with stable streaming protocols like RTSP, RTMP, and MPEG-TS.
  • User-friendly interface ensures easy setup and operation, perfect for both beginners and pros.
  • Record and store up to 1TB of high-quality video, with external storage options via USB 3.0.
  • Mix multiple video sources with PIP and PBP layouts for dynamic and professional productions.

What's in the box:

  • Media Processor LC200 CaptureVision Station
  • 2x VC-A61P 4K UHD IP PTZ Cameras (White)
  • Remote Control
  • 2x Power Adapter
  • 2x Power Cord
  • 2x RS-232/RS-485 Connectors
  • 2x Mounting Metal Plates
  • 4x M3x6 Flat Head Screws
  • RS-422 Connector
  • Metal Plate A
  • Metal Plate B
  • M3 Screws
  • Quick Installation Guide
  • Lumens 5 Year Limited Warranty
