LG VSM5J-H 55" 2x2 Full HD IPS Video Wall Display with Peerless Mount

SKU: LOC55VM5JW4P MFR: 55VSM5JW-4P
Earn VIP Reward Points

Key Features

  • Experience seamless video walls with LG's 55" display, boasting a super-narrow 0.44mm bezel.
  • Create stunning visuals with the LG VSM5J-H's Full HD IPS panel, perfect for vibrant content.
  • Enjoy 24/7 reliability with this commercial monitor, designed for continuous operation in any setting.
  • Manage content easily with the embedded webOS 4.1, offering intuitive control and flexibility.
  • This LG video wall display offers versatile connectivity with HDMI, DP, and DVI-D inputs.
  • Rely on LG's exceptional image quality and color accuracy for impactful presentations and displays.
See More Product Details
Special Order?Estimated to Ship: 08/22/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

LG VSM5J-H Specifications

Panel
  • Screen Size

    55" (139.7cm)

  • Panel Technology

    IPS

  • Back Light Type

    Direct

  • Aspect Ratio

    16:9

  • Native Resolution

    1,920 x 1,080 (FHD)

  • Refresh Rate

    60Hz

  • Brightness

    500nit (Typ.)

  • Contrast Ratio

    1,100:1

  • Dynamic CR

    500,000:1

  • Color Gamut

    NTSC 72%

  • Viewing Angle (H x V)

    178 x 178

  • Color Depth

    10bit, 1.07Billion colors

  • Response Time

    8ms (G to G)

  • Surface Treatment (Haze)

    28%

  • Life time

    60,000Hrs (Typ.)/50,000Hrs (Min.)

  • Operation Hours (Hours/Day)

    24/7

  • Portrait/Landscape

    Yes/Yes

Connectivity

Jump to...
  • Input - Digital - HDMI

    2x Yes, HDCP2.2

  • Input - Digital - DP

    1x Yes, HDCP2.2

  • Input - Digital - DVI-D

    1x Yes, HDCP1.4

  • Input - Audio In

    1x Yes

  • Input - RS232C IN

    1x Yes

  • Input - RJ45(LAN)

    1x Yes

  • Input - IR IN

    1x Yes

  • Input - USB

    1x USB2.0 Type A

  • Output - DP Out

    1x Yes, Input: HDMI/DVI/DP

  • Output - Audio Out

    1x Yes

  • Output - RS232C OUT

    1x Yes

  • Output - RJ45(LAN)

    1x Yes

Key Features

Jump to...
  • HW - Internal Memory

    8GB

  • HW - Sensor - Temperature Sensor

    Yes

  • HW - Sensor - BLU Sensor

    Yes

  • HW - Sensor - Acceleration (Gyro) Sensor

    Yes

  • HW - Local Key Operation

    Yes

  • SW - webOS ver.

    webOS 4.1

  • SW - Embedded CMS

    Yes (Local Contents Scheduling)

  • SW - Embedded CMS - Group Manager

    Yes

  • SW - USB Plug & Play

    Yes

  • SW - Fail over

    Yes

  • SW - Background Image - No Signal Image

    Yes

  • SW - Sync Mode - RS-232C Sync

    Yes

  • SW - Sync Mode - Local Network Sync

    Yes

  • SW - Video Tag

    4x Yes

  • SW - Play via URL

    Yes

  • SW - Rotation - Screen Rotation

    Yes

  • SW - Rotation - External Input Rotation

    Yes

  • SW - Gapless Playback

    Yes

  • SW - Tile Mode Setting

    Yes (Max. 15 x 15)

  • SW - Setting Data Cloning

    Yes

  • SW - SNMP

    Yes

  • SW - ISM Method

    Yes

  • SW - Auto Set ID

    Yes

  • SW - Status Mailing

    Yes

  • SW - Control Manager

    Yes

  • SW - 3rd Party Compatibility

    Yes (Crestron Inside)

  • SW - Power - Smart Energy Saving

    Yes

  • SW - Power - PM mode

    Yes

  • SW - Power - Wake on LAN

    Yes

  • SW - Power - Network Ready

    Yes

  • SW - HDMI-CEC

    Yes

  • SW - SI Server Setting

    Yes

  • SW - webRTC

    Yes

  • SW - Pro:Idiom

    Yes

  • SW - W/B Setting by Gray scale

    Yes

  • SW - Scan Inversion

    Yes

Environment Conditions

Jump to...
  • Operation Temperature

    32 Degree F to 104 Degree F (0 Degree C to 40 Degree C)

  • Operation Humidity

    10% to 80%

  • Power Supply

    AC 100-240 V-, 50/60 Hz

  • Power Type

    Built-In Power

Power Consumption

Jump to...
  • Type

    200W (TBD)

  • Maximum

    250W (TBD)

  • BTU (British Thermal Unit)

    682BTU (TBD)

  • Smart Energy Saving

    105W (TBD)

  • DPM

    0.5W

  • Power off

    0.5W

Certification

Jump to...
  • Safety

    CB/NRTL

  • EMC

    FCC Class "B"/CE/KC

  • ErP/Energy Star

    Yes (EU Only)/Yes (Energy Star 8.0)

OPS Compatibility

Jump to...
  • OPS type compatible

    Yes (Piggyback)

Software Compatibility

Jump to...
  • SuperSign CMS

    Yes

  • SuperSign Control/Control+

    Yes/Yes

  • SuperSign WB

    Yes

  • SuperSign Media Editor

    Yes

  • LG Connected Care

    Yes

Language

Jump to...
  • OSD

    English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portuguese(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portuguese(Europe), Dutch, Czech, Greek, Turkish, Arabic

Special Feature

Jump to...
  • Smart Calibration

    Yes

Mechanical

Jump to...
  • Bezel Color

    Black

  • Bezel Width

    Even bezel: 0.44mm

  • Handle

    Yes

  • VESA Standard Mount Interface

    600 x 400mm

  • Dimensions (W x H x D)

    Monitor: 47.65 x 26.81 x 3.4" (1210.51 x 681.22 x 86.5mm)

  • Weight

    Head: 37.03 lbs (16.8kg)

  • UPC Code

    195174031889

About LG VSM5J-H

Groundbreaking 0.44mm Even Bezel
The unprecedented razor-thin bezel - 0.44 mm EVEN BEZEL and 0.88 mm BEZEL TO BEZEL - which has been verified by Nemko, makes content look like the actual original image by depicting a subject perfectly true to form, without any distortions. Seamlessly assembled on a large video wall screen, the VSM5J series will provide an even more immersive experience to viewers.

Higher Viewing Angle
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VSM5J series is high enough to display vivid colors throughout the screen with no distortion.

Wide Viewing Angle
It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VSM5J series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.

Uniform Color Expression
Poor uniformity around bezel boundaries can give the corners a darker appearance, which doesn't look good on a large screen. However, the VSM5J series has enhanced uniformity, even within the four corners of the display, to deliver vivid and consistent color throughout the screen.

Image Gap Reduction
The VSM5J series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.

Smart Calibration
Smart Calibration is a solution that enables error-free calibration while dramatically reducing time and costs compared to existing sensor calibration methods. It analyzes not only the color property differences within each individual display but also the property differences between the connected displays, eliminating the need for any additional manual color adjustments. Because it can be done in a matter of minutes with just the click of a remote control, this process is so simple. In addition, calibration can be set to automatically occur at regular intervals and brightness can be adjusted based on the surrounding environment, allowing you to always deliver optimum image quality.

Clear View with Non-glare Panel
Viewers can be annoyed by unnecessary light reflection when watching a screen under bright conditions. The VSM5J series has resolved such inconveniences by increasing the level of haze to 28%, which enhanced visibility and text readability.

High Performance and Great Scalability
Thanks to its built-in SoC and webOS smart signage platform, the VSM5J series can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a web-based platform and offers SDK (Software Development Kit), it is even easier for SIs to build and optimize their web apps.

Flexible Content Creation
Four different videos can be played simultaneously via web apps, and various animation effects, such as scaling or rotating, are added to content using CSS (Cascading Style Sheets) transition effects. Real-time streaming is also available, providing the flexibility to organize and diversify content free from capacity limits.

Intuitive Menu Structure
The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.

Dedicated GUI for Portrait Orientation
The conventional GUI (Graphic User Interface) was designed based on landscape-oriented consumer TV usage, so OSD (On Screen Display) wasn't well-suited for screens in portrait mode. The OSD of the VSM5J series, however, consists of a long range menu with bigger font sizes and a 9:16 ratio, creating a comfortable and efficient business environment.

Daisy Chain Capability
A LAN daisy chain allows you to control and monitor video walls and even update their firmwares at once. Also, through UHD daisy chain using HDMI and DisplayPort, you can easily set up a UHD video wall without the need of DisplayPort MST or Matrox graphics card.

Real-Time LG Connected Care
Maintenance is easy and fast with the optional LG Connected Care service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.

LG VSM5J-H Features

  • 500 cd/sq. m Brightness Typ.
  • 0.44mm (Even) Bezel
  • 86.5mm Depth
  • Interface: HDMI(2)/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
  • Smart Calibration

Key Features

  • Experience seamless video walls with LG's 55" display, boasting a super-narrow 0.44mm bezel.
  • Create stunning visuals with the LG VSM5J-H's Full HD IPS panel, perfect for vibrant content.
  • Enjoy 24/7 reliability with this commercial monitor, designed for continuous operation in any setting.
  • Manage content easily with the embedded webOS 4.1, offering intuitive control and flexibility.
  • This LG video wall display offers versatile connectivity with HDMI, DP, and DVI-D inputs.
  • Rely on LG's exceptional image quality and color accuracy for impactful presentations and displays.

What's in the box:

  • LG VSM5J-H 55" 2x2 Full HD IPS Video Wall Display
  • Peerless Mount
  • Remote Control with Batteries
  • Power Cord
  • RS232C Cable
  • LAN Cable
  • DP Cable
  • IR Receiver
  • Screws
  • Guide Bracket
  • User Manual
  • LG 3 Year Limited Warranty
