Lorex LH034 Eco Blackbox3 4-Ch 500GB HDD DVR with 2x Wireless Outdoor Cameras
See all Lorex items

Lorex LH034 Eco Blackbox3 4-Ch 500GB HDD DVR with 2x Wireless Outdoor Cameras, H.264 Video Compression, 135' Night Vision Range, 500' Wireless Range

SKU: LRXLH03GC2W
(1)

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

2015-07-13T21:00:00

Rated 4 out of 5

A Pretty Impressive System for the Price

I'm pretty pleased with this system, now that I have had it in operation for over a week. It seems to be a well-engineered system for the most part, and I have managed to configure all aspects, including remote access on my LG G4 smartphone, along with motion alarm emails. The latter was more involved only because I needed to set up a DDNS account just to have the email service, whereas I was using Lorex Stratus for remote access. Interference on the 2.4 Ghz band is not too bad since most of my computer networking is 5 Ghz. I did, however, need to set up a separate 5 Ghz bridge for the DVR to connect it to my router, since I was too far from the router to run an Ethernet cable. This solution cost me some extra money but I knew I would need it, so no surprise. My only criticism is the number of false motion alarms caused by rapid changes in contrast, particularly in early morning as the sun is rising, with long shadows and clouds blowing across the sun. If I decrease sensitivity to mitigate this problem, I miss a person walking across a grass lawn wearing clothing that is similar in tonality to the grass (even though it is a different color). For the price, though, this is a pretty amazing system!

Charles R.

Lorex LH034 Specifications

  • DVR: Operating System

    Linux (embedded)

  • DVR: Pentaplex

    Simultaneous View, Record, Playback, Backup & Remote Monitoring

  • DVR: Number of Channels

    4

  • DVR: Video IN

    4 x 1Vp-p, CVBS, 75Ohms, BNC

  • DVR: Video OUT

    1 x BNC

  • DVR: VGA OUT

    Yes

  • DVR: HDMI

    Yes

  • DVR: Audio IN

    2 Line in(RCA), G.711

  • DVR: Audio OUT

    1 line OUT (RCA), G.711

  • DVR: USB Port

    1 at the back, 1 at the front

  • DVR: Alarm IN

    Without Alarm

  • DVR: Video Output Resolution

    800x600, 1024x768, 1280x1024, 1440x900, HDMI (1920 x 1800)

  • DVR: PTZ control

    RS-485 Pelco D & P Protocol

  • DVR: Live Display

    1, 4

  • DVR: Live Display Speed

    120 NTSC, 100 PAL

  • DVR: OSD

    ON/OFF

  • DVR: System Navigation

    USB Mouse, IR Remote Controller

  • DVR: Motion Area Setting

    Adjustable grid (30x44) NTSC
    Adjustable grid (36x44) PAL

  • DVR: Sensitivity levels

    8

  • DVR: Firmware Upgrade

    Automatic over the Internet & via USB device and Network

  • DVR: User Authority

    By user group

  • DVR: Time Synchronization

    Auto time sync by NTP server

  • DVR: Video Compression

    H.264

  • DVR: Audio Compression

    G.711

  • DVR: Recording Resolution Setting

    Per camera for different resolutions

  • DVR: Recording Quality Control

    3 levels

  • DVR: Recording Schedule

    By hour, by day, by recording mode, by motion, by ch

  • DVR: Pre Recording

    Max: 10 Secs

  • DVR: Post Recording

    Max: 5 Minutes

  • DVR: Reliability

    Watch-Dog, Auto-recovery after power failure

  • DVR: Covert Video

    Yes

  • DVR: Playback Channel

    1-4 Adjustable

  • DVR: Playback Speed

    Variable Max 16x

  • DVR: Playback Players

    Backup Player

  • DVR: Search

    By time & event

  • DVR: Log Search

    Up to 100,000 lines for system, configuration changes, motion/alarm detected, account, record and storage

  • DVR: Audio Play

    Yes

  • DVR: Storage

    500GB

  • DVR: Maximum Capacity

    up to 4TB

  • DVR: Backup Media

    USB Flash Drive & HDD

  • DVR: Backup File Format

    H.264 file (AVI generator included)

  • DVR: Cloud Connection

    Lorex Stratus Connectivity

  • DVR: Supported Operating Systems

    Windows, Mac OS

  • DVR: Remote Software

    Client Software (PC) & Safari (Mac)

  • DVR: Email notification

    Text with snapshot

  • DVR: Instant Smart Phone/Tablet Support

    iPad, iPhone android

  • DVR: DDNS

    Free Lorex DDNS

  • DVR: System Configuration

    Full setup configuration over network

  • DVR: Ports

    Programmable by User

  • DVR: Network Protocol

    TCP/IP / DHCP / UDP / DDNS / PPPoE

  • DVR: Network Interface

    10/100-Base-TX, RJ-45

  • DVR: Network Speed Control

    48Kb - 8MB/sec.

  • DVR: Power Consumption

    Approx. 10 watts (no HDD included)

  • DVR: Supply Voltage

    100VAC-240VAC, 12VDC, 2A, 50/60Hz

  • DVR: Operating temperature

    32 deg. - 104 deg. F /0 deg. - 40 deg. C

  • DVR: Humidity

    10-90% NC

  • Frequency Range

    TX: 2.400 GHz to 2.480 GHz

  • TX Power

    16 dBm

  • Unobstructed Effective Range

    Indoor: 165.0' (50.2 m)
    Outdoor: 500.0' (152.4 m)

  • Data Rate

    4 Mb/s

  • Modulation

    GFSK

  • Spread Spectrum

    FHSS

  • Operating Temperature Range

    14 to 122 deg. F (-10 to 50 deg. C)

  • Camera: Image Sensor

    1/4" Color CMOS

  • Camera: Effective Pixels (H x V)

    640 x 480

  • Camera: Image Compression

    MPEG4

  • Camera: Image Resolution

    VGA (640 x 480)

  • Camera: Lens

    3.6 mm, F2.0

  • Camera: Field of View

    Diagonal: 55deg.

  • Camera: AGC (Automatic Gain Control)

    On

  • Camera: Power Requirement

    9 VDC +/-5%

  • Camera: Power Consumption

    With IR LEDs: 430 mA (maximum)
    Without IR LEDs: 220 mA (maximum)

  • Camera: IR LED Qty. / Type

    24 pieces, 850 nm

  • Camera: Night Vision Range

    Total Darkness: 90.0' (27.4 m)
    Typical Outdoor Night-Time Ambient Lighting: 135.0' (41.1 m)

  • Camera: IR LED

    CdS Drive, built-in auto IR LED turn On/Off circuit

  • Camera: Environmental Rating

    IP66

  • Receiver: Receiving Frequency Range

    2.4 GHz to 2.48 GHz

  • Receiver: RX Sensitivity

    -81 dBm

  • Receiver: Demodulation

    GFSK

  • Receiver: Data Rate

    4 Mb/s

  • Receiver: Supported Resolution

    VGA (640 x 480), up to 25 fps

  • Receiver: Termination

    BNC video

  • Receiver: Power Requirements

    9 VDC +/-5%

  • Receiver: Power Consumption

    270 mA (maximum)

  • Receiver: Operating Temperature Range

    14 to 122 deg. F (-10 to 50 deg. C)

  • Dimensions (W x D x H)

    DVR: 11.80 x 8.60 x 1.90" (29.97 x 21.84 x 4.82cm)
    Camera (with Antenna and Sunshade): 79 x 203 x 117mm (3.11 x 7.99 x 4.60")
    Receiver (with Antenna Attached): 53 x 137 x 86mm (2.08 x 5.39 x 3.38")

  • Weight

    DVR: 1kg (2.20lbs)
    Camera: 0.3kg (0.66lbs)
    Receiver: 0.1kg (0.22lbs)

  • UPC Code

    695529002606

About Lorex LH034

The Lorex LH034 Eco Blackbox3 4-Ch 500GB HDD DVR with 2x Wireless Outdoor Cameras provides you with a feature-rich analog DVR and two versatile outdoor-rated day/night wireless bullet cameras to give you the basic tools you need to set up a comprehensive surveillance system. The DVR's 500GB installed HDD can be upgraded later to as much as 4TB and the audio-in and out ports allow you to integrate it into a PA system with external microphones and speakers wired to it.

This a full pentaplex DVR that allows you to view, record, playback, backup and remotely access the system simultaneously so you never have to stop recording to work with the system. Multiple recording modes, H.264 video and G.711 audio compression and adjustable frame rates allow the user to tailor the surveillance coverage to their needs and optimize the available HDD space. When connected to the Internet, the DVR is accessible remotely via most web browsers and on mobile devices with a free app installed.

Complementing the DVR are two wireless bullet cameras, with a wireless receiver that get plugged into the DVR. Each camera is IP66 outdoor-rated to be weather and dustproof so you can feel confident installing them inside or out. The 1/4" image sensor and 4.6mm f/2 fixed lens captures 480TVL resolution images with a 57deg. field of view. 24 IR LEDs with an effective night vision range of 135' and an automatic IR cut filter give these cameras 24 hour surveillance capabilities.

Utilizing interference reduction and signal guard technologies ensures signal quality and strength with automatic reconnection between the camera and receiver. Transmission ranges of up to 165' indoor and 500' outdoor allow these cameras to be placed in areas where running cables is impossible or impracticable.

Lorex LH034 Features

  • DVR: Tablet / smartphone viewing and playback
  • DVR: Lorex Stratus Connectivity - 3 step setup
  • DVR: Superior 960H Resolution - 34% more detailed and true-to-life images
  • DVR: PTZ cameras supported (RS485) remotely control through App
  • DVR: Accurate time stamps with NTP & Daylight Savings Time
  • DVR: Instant email alerts with snap shot attachment
  • DVR: Continuous, scheduled and motion recording
  • DVR: Advanced mobile apps with live viewing, playback, video recording and snap shot
  • DVR: PC and Mac compatible
  • DVR: H.264 video compression
  • DVR: 3 video outputs (HDMI, VGA and BNC) to connect multiple monitors
  • DVR: Pentaplex operation - view, record, playback, back up & remotely control the system simultaneously
  • DVR: Automatic firmware upgrade over the Internet ensures your system is secure and up to date
  • Camera: Real-Time (up to 30fps) wireless video with MPEG-4 compression @ 640x480 (VGA) resolution
  • Camera: Extended bandwidth delivers smooth high frame rate video
  • Camera: SignalGuard Technology continuously monitors the wireless signal and automatically reconnects upon detecting low signal strength
  • Camera: Next generation adaptive Frequency Hopping Spread Spectrum (FHSS) technology greatly reduces signal interference
  • Camera: Auto-mechanical infrared camera filter achieves accurate color reproduction in varying lighting conditions
  • Camera: 2 channel receiver for separate wireless video channels to your DVR minimizes cable clutter
  • Camera: Long Range night vision range up to 135' (41m)
  • Camera: Simple installation. No video cable required
  • Camera: Weatherproof camera and power connectors for outdoor or indoor installation
  • Camera: Easily connects to any surveillance DVR (BNC)
  • Camera: High gain antennas provide up to 500' (152m) outdoor wireless range
  • Camera: Vandal resistant camera design with cable pass-through mounting bracket

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • DVR: Tablet / smartphone viewing and playback
  • DVR: Lorex Stratus Connectivity - 3 step setup
  • Superior 960H Resolution
  • PTZ cameras supported remotely through App
  • Accurate time stamps w NTP & Daylight Savings Time
  • DVR: Instant email alerts with snap shot attachment

What's in the box:

  • Lorex LH034 Eco Blackbox3 4-Ch 500GB HDD DVR
  • LW2232PK2B Two-Camera Indoor/Outdoor Wireless Surveillance System
  • HDMI Cable
  • IR Remote Control
  • Power Adapter
  • USB Mouse
  • Ethernet Cable
  • Lorex 1 Year Limited Warranty
