Lynx Technik AG yellobrik OBD 1810 3GB Bi-directional SDI/Fiber Transceiver with LC/PC Simplex Fiber Connectors, Up to 10km Max Distance, Pair

The OBD 1810 is a bidirectional Fiber Optic to SDI transmitter and receiver which uses a single fiber link supplied in a compact self contained package. It is a convenient and cost effective solution to combat the restrictions involved with the distribution of uncompressed broadcast quality video signals over long distances. The OBD 1810 modules are supplied in pairs, one Type A and one Type B which work together in a WDM closed loop application.

Each module has an electrical SDI in and SDI out connection and uses a single fiber link between the two. Each channel is fully independent and can have different standards and formats of SDI video. The modules auto-detect and re-clock any 270Mbit, 1.5Gbit and 3Gbit SDI source prior to conversion. The modules are fully compatible with 3Gbit Level A and Level B formats.
